FRONT AND REAR PANELS

1. EDID Dip Switches
2. Power Indicator LED
3. Output Status LED
ON display is connected and powered on
OFF display is not connected or it is powered off
FLASHING problem with EDID handshake
4. HDMI Inputs. Connect PC or BlueRay.
5. HDMI Outputs. Connect display or projector.
6. 5V 2A Power input
2
1
4
4 5
3 2
6
