Vision ZD2106IN-7 Installation & Operation Manual

Operation

1. Opening/Closing the door/window to separate the magnet from the sensor or
remove the rear will send signal to any association nodes accordding to the
Status/Signal table (Notification V8 Type) and the LED will flash once; ZD2106 will
send signal according the status / signal table (Notification V8 Type) after closing
the cover back.
2. Normal operation, the LED will not light.
If the cover of sensor is removed, the LED will flash once and send "Wake Up
3.
Notification" after 10 seconds.

Federal Communications Commission Statement

This equipment has been followed to comply with Part 15 of the FCC Rules. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try and correct the interference by one of the following measures:
-Reorient or relocate the receiving antenna,
-Increase the separation between the equipment and receiver,
-Connect the equipment into and outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause
undesirable operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.

Limited Warranty

Vision Guarantees that every wireless door/window sensor is free from physical defects
in material and workmanship under normal use for one year from the date of purchase. If
the product proves defective during this one-year warranty period, Vision will replace it
free of charge. Vision does not issue any refunds. This warranty is extended to the
original end user purchase only and is not transferable. This warranty does not apply to:
(1) damage to units caused by accident, dropping or abuse in handling, or any negligent
use; (2) units which have been subject to unauthorized repair, taken apart, or otherwise
modified; (3) units not used in accordance with instruction; (4) damages exceeding the
cost of the product; (5) transit damage, initial installation costs, removal cost, or
reinstallation cost. For information on addtional devices, please visit us at
www.visionsecurity.com.tw
ZD2106-7 V0 1090417
Installation & Operation Manual
ZD2106IN-7
ZD2106TH-7
ZD2106EU-7
ZD2106RU-7
ZD2106US-7
ZD2106IL-7
ZD2106KR-7
ZD2106HK-7
ZD2106JP-7
ZD2106BR-7
Door/ Window Sensor
