Vision ZD2106IN-7 Installation & Operation Manual

Product Description and Specification:

Specification:
Protocol: Z-Wave™ (ZGM130S)
Frequency Range:
8 6 5 . 2 2 M H z (ZD2106IN-7)
8 6 8 . 1 0 M H z (ZD2106MY-7)
8 6 8 . 4 2 M H z (ZD2106EU-7)
8 6 9 . 0 0 M H z (ZD2106RU-7)
9 0 8 . 4 2 M H z (ZD2106US-7)
9 1 6 . 0 0 M H z (ZD2106IL-7)
919~923 M H z (ZD2106KR-7)
9 1 9 . 8 0 M H z (ZD2106HK-7)
922~926 M H z (ZD2106JP-7)
9 2 1 . 4 2 M H z (ZD2106BR-7)
Operating Range: Up to 100 feet line of sight
Operating Temp.: -15°C~ 60°C (5°F ~140°F)
Battery: CR2 * 1PC
Z-Wave Command Classes:
COMMAND_CLASS_ASSOCIATION_GRP_INFO_V3
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_BATTERY
COMMAND_CLASS_DEVICE_RESET_LOCALLY
COMMAND_CLASS_FIRMWARE_UPDATE_MD_V5
COMMAND_CLASS_INDICATOR_V3
COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2
COMMAND_CLASS_NOTIFICATION_V8
COMMAND_CLASS_POWERLEVEL
COMMAND_CLASS_SECURITY
COMMAND_CLASS_SECURITY_2
COMMAND_CLASS_SUPERVISION
COMMAND_CLASS_TRANSPORT_SERVICE_V2
COMMAND_CLASS_VERSION_V3
COMMAND_CLASS_WAKE_UP_V2
COMMAND_CLASS_ZWAVEPLUS V2_INFO
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V4
Notification V8 Type
Notification Type
Event
Basic Set:
Reed Switch

Introduction

Thanks for choosing the Vision's wireless door/window
sensor of the home security device. This sensor is a
Z-Wave™ PLUS V2 enabled device (interoperable,
two-way RF mesh networking technology) and is fully
compatible with any Z-Wave™ enabled network and it's security
framework. Every mains powered Z-Wave PLUS V2 enabled device acts
as a signal repeater and multiple devices result in more possible
transmission routes which helps eliminate "RF dead-spots"
Z-Wave™ PLUS V2 enabled devices displaying the Z-Wave™ PLUS V2
logo can also be used with it regardless of the manufacturer, and ours can
also be used in other manufacturer's Z-Wave™ PLUS V2 enabled
networks. Monitors door and window. Sends Z wave signal when door or
window opening or closing. Lower power consumption, longer operating
distance and battery life. Improving RF communication. When the device
is secure included into Z-Wave network, above communication will be
encrypted. ZD2106 supports SECURITY S0 / SECURITY S2
UNAUTHENTICATED / SECURITY S2 AUTHENTICATED.

Limited Warranty

Vision Guarantees that every wireless door/window sensor is free from
physical defects in material and workmanship under normal use for one
year from the date of purchase. If the product proves defective during this
one-year warranty period, Vision will replace it free of charge. Vision
does not issue any refunds. This warranty is extended to the original end
user purchase only and is not transferable. This warranty does not apply
to: (1) damage to units caused by accident, dropping or abuse in
handling, or any negligent use; (2) units which have been subject to
unauthorized repair, taken apart, or otherwise modified; (3) units not used
in accordance with instruction; (4) damages exceeding the cost of the
product; (5) transit damage, initial installation costs, removal cost, or
reinstallation cost. For information on additional devices, please visit us
at www.visionsecurity.com.tw
Package Content
1pc ZD 2106-7 Door Sensor
1pc Magnet
1pc CR2032 Lithium Battery
1pc Accessory Pack
1pc Installation & Operation manual
FCC Freq./ Date rate spec. :
908.42MHz for 9.6 kbps
908.40MHz for 40 kbps
916.00MHz for 100 kbps
Z-Wave S2 Support Command Classes :
COMMAND_CLASS_ASSOCIATION_GRP_INFO_V3
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_BATTERY
COMMAND_CLASS_DEVICE_RESET_LOCALLY
COMMAND_CLASS_FIRMWARE_UPDATE_MD_V5
COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2
COMMAND_CLASS_NOTIFICATION_V8
COMMAND_CLASS_POWERLEVEL
COMMAND_CLASS_SUPERVISION
COMMAND_CLASS_VERSION_V3
COMMAND_CLASS_WAKE_UP_V2
SWITCH TYPE STATUS
Reed Switch 0x06
Tamper
0x07
Switch
Close:0x07
Reed Switch
Open:0X16
Tamper Close:0x00
Switch Open:0X03
Open Close
0xFF 0x00
ZD 20106-7 V0 1081219
Installation & Operation Manual
Door/ Window Sensor
ZD2106IN-7
ZD2106MY-7
ZD2106EU-7
ZD2106RU-7
ZD2106US-7
Z D 2 1 0 6 I L - 7
ZD2106KR-7
ZD2106HK-7
ZD2106JP-7
ZD2106BR-7
