Char-Broil Commercial 463257010 Product Manual

Commercial series gas grill

Table of Contents

Quick Links

The following are trademarks registered by W.C. Bradley Co. in the U.S. Patent and Trademark Office: Caldera®; Charcoal2Go®; Char-Broil®; America's Legendary

Barbeque Company®; American Gourmet®; Bandera®; Brush Hawg®; CB 940®; Char-Diamonds®; Char-Broil Charcoal/Gas®; Everybody Grills®; Everybody

Outside®; FastStart®; Grill 2 Go®; Grill 2 Go® Express®; Grill Lovers®; Infrared Grilling That's All About U®; Keepers of the Flame®; New Braunfels Smoker

Company®; Patio Bistro®; Patio Caddie®; Patio Kitchen®; Pro-Sear®; RED®; Quantum®; Santa Fe®; Sear and Grill®; Sierra®; Signature Series®; Sure2Burn®;

The Big Easy®; Trentino®; U®; Wild West Tradition®; and the following marks:

The following are trademarks of W.C. Bradley Co.: Advantage Series™; Auto-Clean™;Chef Tested™; Commercial Series™; Designer Series™;; Diamond Flame™;

Double Chef™; Fireball™; Firenzy™; FlavorMaster™;Front Avenue™; Grill 2 Go® Advantage™; Hog and Yard Bird™; H20 Smoker™; Infrared. Grilling's Juicy Little

Secret™; Incredible Taste. Infallible Results™; Infrared Inside™; Insure™; Let's Grill Something Together™; Lev-Alert™; Longhorn™; Magneto™; Precision

Flame™; Quick2Burn™; QuickSet™; Ready When You Are™; Season, Set, And Savor™; Sizzle On The Grill™; Signature Series™; SureFire™; The Minute

Grill™;Torchfork™; Universal Grill Parts™; You Bring the Party™

Protected under one or more of the following U.S. Patents: 5,421,319; 5,458,309; 5,579,755; 5,996,573; 6,135,104; 6,279,566; 6,331,108; 6,484,900; 6,526,876; 6,595,197; 6,640,799; 6,640,803; 6,729,873; 6,739,473; 6,749,424; 6,792,935; 6,951,213; 7,047,590;

7,516,693; D364,535; D372,637; D373,701; D377,735; D383,035; D397,910; D405,643; D406,005; D406,009 ; D413,043; D413,229; D414,982; D415,388; D416,164; D416,441; D417,587; D417,588; D422,516; D423,274; D423,876; D428,303; D430,772; D435,396;

D436,004; D438,059; D438,060; D438,427; D439,110; D442,505; D443,179; D443,354; D443,464; D447,384; D447,385; D447,909; D448,610; D448,614; D448,615; D448,616; D448,975; D449,492; D450,544; D451,759; D454,028; D454,031; D455,205; D455,206;

D456,202; D456,222; D456,223; D457,789; D458,520; D458,760; D458,802; D459,088; D459,148 D459,149; D459,161; D459,163; D459,586; D459,943; D460,312; D460,313; D460,318; D461,359; D465,123; D465,693; D466,307; D466,439; D466,752; D473,414;

D474,371; D477,498; D477,501; D477,504; D477,506; D477,746; D478,471; D478,472; D480,914; D491,410; D494,009; D494,413; D498,523; D500,359; D504,048; D530,098; D535,000; Canada:D97,504;D99,355; D102,037; D104,200;D108,377; 2,315,567;

IMPORTANT: Fill out the product record information below.

Serial Number

Date Purchased

TEC™ is a trademark of Tec Infrared Grills.

Printed in China

PRODUCT GUIDE

MODEL 463257010

See rating label on grill for serial number.

For support and to register your

grill, please visit us at

www.charbroil.com

If you have questions or need

assistance during assembly,

please call 1-800-241-7548.

Estimated assembly time: 30 minutes

07/09/09 • G515-001-050801

Table of Contents

Troubleshooting

Need help?

Do you have a question about the Commercial 463257010 and is the answer not in the manual?

Questions and answers

Summary of Contents for Char-Broil Commercial 463257010

Page 1 The following are trademarks registered by W.C. Bradley Co. in the U.S. Patent and Trademark Office: Caldera®; Charcoal2Go®; Char-Broil®; America's Legendary Barbeque Company®; American Gourmet®; Bandera®; Brush Hawg®; CB 940®; Char-Diamonds®; Char-Broil Charcoal/Gas®; Everybody Grills®; Everybody Outside®; FastStart®; Grill 2 Go®; Grill 2 Go® Express®; Grill Lovers®; Infrared Grilling That’s All About U®; Keepers of the Flame®; New Braunfels Smoker Company®;...
Page 2: Table Of Contents
TABLE OF CONTENTS For Your Safety ........2-3 Grilling Guide.
Page 3 WARNING CALIFORNIA PROPOSITION 65 1. Combustion by-products produced when using this product contain chemicals known to the State of California to cause cancer, birth defects, and other reproductive harm. 2. This product contains chemicals, including lead and lead compounds, known to the State of California to cause cancer, birth defects or other reproductive harm.
Page 4: Pre-Heating Grill
This aids in removing the oils used during manufacturing. Lava Rock / Briquettes This gas grill has been designed, engineered, and tested to be used with flame tamers or heat distribution plates to provide more even heating, improve the cleaning process, and reduce flare-ups.
Page 5 GRILLING GUIDE – Grilling 101 Outdoor grilling is really quite simple. You'll succeed with burgers, dogs, or steaks usually on your very first try. With experience, you will learn how to work with your grill, creating more imaginative meals all the time. This knowledge makes up the art of grilling.
Page 6 GRILLING GUIDE – Tips & Tricks Cooking on your new grill is a hands-on experience, and it is recommended to remain outside with your grill while cooking. Grilling can be affected by many external conditions. In cold weather, you will need more heat to reach an ideal cooking temperature, and grilling may take longer.
Page 7: Grilling Guide
GRILLING GUIDE – Cleaning Your Grill Why Clean? We've all heard the saying 'An ounce of prevention is worth a pound of cure'. This is great advice when it comes to keeping your grill clean. Routine Care Periodic cleaning of this grill is necessary, as grill fires can occur when grease and food debris collect in the bottom of the grill.
Page 8: Use And Care
USE AND CARE DANGER • NEVER store a spare LP cylinder under or near the appliance or in an enclosed area. • Never fill a cylinder beyond 80% full. • An over filled or improperly stored cylinder is a hazard due to possible gas release from the safety relief valve.
Page 9 LP Cylinder Exchange •Many retailers that sell grills offer you the option of replacing your empty LP cylinder through an exchange service. Use only those reputable exchange companies that inspect, precision fill, test and certify their cylinders. Exchange your cylinder only for an OPD safety feature-equipped cylinder as described in the "LP Cylinder"...
Page 10 Hold coupling nut and regulator as shown for proper connection to LP cylinder valve. 6.Turn the coupling nut clockwise and tighten to a full stop. The regulator will seal on the back-check feature in the LP cylinder valve, resulting in some resistance. An additional one-half to three-quarters turn is required to complete the connection.
Page 11 • Do not use charcoal or ceramic briquets in a gas grill. (Unless briquets are supplied with your grill.) • Use grill at least 3 ft. from any wall or surface.
Page 12: Match-Lighting
Ignitor Lighting (continued) 8. For grills equipped with ELECTRONIC IGNITION at each burner: Repeat steps 4 through 6 to light each burner. 9. Once each burner has ignited, turn knobs to desired setting. WARNING Turn controls and gas source or tank OFF when not in use.
Page 13: Spider Alert
CAUTION SPIDER ALERT! SPIDER AND WEBS INSIDE BURNER TUBE If you notice that your grill is getting hard to light or that the flame isn’t as strong as it should be, take the time to check and clean the venturi’s. VALVE CONTROL PANEL In some areas of the country, spiders or small insects have been...
Page 14: Limited Warranty
LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase*.
Page 15: Parts List
PARTS LIST Key Qty Description 1 BOTTOM SHELF 1 TANK SCREW, F/ BOTTOM SHELF 2 CASTER, LOCKING 2 CASTER, FIXED CART LEFT SIDE PANEL, BLACK, LCS 500 1 GROMMET, F/ REGULATOR HOLE CART RIGHT SIDE PANEL, BLACK, LCS 500 CART LOWER BACK PANEL, BLACK, LCS 500 FRO B N R T ACE LEFT RAIL, F/ LCS 500 GREASE...
Page 16: Parts Diagram
PARTS DIAGRAM...
Page 17: Assembly
ASSEMBLY Attach the two locking casters at the rear of the bottom shelf and the two fixed casters at the front. Use the provided caster wrench to fully tighten casters. Locking caster Bottom shelf Attach side panels to bottom shelf using three 1/4-20x1/2”...
Page 18 Place lower back panel between side panels at rear of bottom shelf. Secure lower back panel to side panels using two 1/4-20x1/2” screws, 7mm lock washers, and 7mm flat washers on each side. Lower back panel 1/4-20x1/2” screw 7mm lock washer 7mm flat washer This step requires two people to lift and position grill head...
Page 19 On back of grill, place upper back panel between side panels and above lower back panel. Secure upper back panel, in lower holes, using one 1/4-20x1½” screw, 7mm lock washer, and 7mm flat washer on each side. Do not fully tighten screws until side shelf installation is complete in later steps.
Page 20 Insert flange on left side shelf into side shelf brackets on side of firebox. Attach left side shelf using four 1/4-20x3/4” screws, 7mm lock washers, 7mm flat washers, 1/4” nuts, shown A. Attach rear of shelf using one Attach front of shelf and fascia using one #8x3/8” self-tapping screw and large Fully tighten lower screws on upper back panel.
Page 21 Insert sideburner burner into left shelf. shelf, shown A. Secure burner to sideburner drip pan with one Wing nut, shown B. Make sure burner tube engages sideburner valve, shown C. Wing nut Under sideburner shelf, attach sideburner ignitor wire to electrode, shown A. Place sideburner grate onto sideburner shelf, aligning grate legs with holes in shelf, shown B.
Page 22 Insert front brace under control panel and between cart side panels. Make sure door hinge pins are on the top side and facing the front. Secure using two 1/4-20x1½” screws, 7mm lock washers, and 7mm flat washers on each side. NOTE: MAKE SURE THAT THE FRONT BRACE IS MOUNTED IN THE MOST DOWNWARD POSITION WHEN ASSEMBLED TO CART.
Page 23 Insert hinge pin on bottom of doors into hole in bottom shelf. Press upper hinge pin in front brace, align hinge hole on top of door, and release hinge pin into door. Release the cap and nut from electronic ignition module. Attach electronic ignition module and heat shield to the cart right side panel with the nut and cap, shown A.
Page 24 Install flame tamers by sliding one end of each flame tamer into slots at front of firebox and resting opposite end on pins in back of firebox. Note: Some parts omitted for clarity of illustration Place cooking grates onto the firebox as shown. Insert the two wire ends at rear of warming rack into holes in back of firebox.
Page 25 LP CYLINDER IS SOLD SEPARATELY. Fill and leak check the cylinder before attaching to grill and regulator (see Use & Care section). Once cylinder has been filled and leak checked, place cylinder into hole in bottom shelf. Make sure cylinder valve is facing front of grill.
Page 26 Unscrew electronic ignition cap on cart right side panel. Insert AA battery into ignitor, negative (—) end first. Replace the cap. AA Battery Electronic Ignition Cap –...
Page 27: Troubleshooting
EMERGENCIES: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Emergencies Possible Cause Gas leaking from • Damaged hose. cracked/cut/burned hose. Gas leaking from LP • Mechanical failure due to rusting or cylinder.
Page 28 Troubleshooting (continued) Problem Possible Cause Burner(s) will not light ELECTRONIC IGNITION: using ignitor. • No spark, no ignition noise. (See Electronic Ignition Troubleshooting also) • No spark, some ignition noise. • Sparks, but not at electrode or at full strength. Burner(s) will not •...
Page 29: Troubleshooting - Electronic Ignition
Troubleshooting - Electronic Ignition Problem (Ignition) Possible Cause SECTION I No sparks appear at • Battery not installed any electrodes when properly. Electronic Ignition Button is pressed; no noise can • Dead battery. be heard from spark module. • Button assembly not installed properly.
Page 30 NOTES...
Page 31: Registration Card
Warranty Registration Department P.O. Box 1240 Columbus, GA 31902-1240...
