WARRANTY PART
REPLACEMENT GUIDE - LED WIRE
MODEL
463355220
463257520
463342620
463255020
463255721
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from those on your particular grill model. However, the method
of assembly remains the same.
XXXXXXXX • 03/02/21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 463355220 and is the answer not in the manual?

Questions and answers

Bob Bezokas
April 3, 2025

recommended rotisserie unit for grille

1 comments:
Mr. Anderson
May 14, 2025

The Char-Broil grill model 463355220 includes a dedicated rotisserie burner, but the motor and spit for the rotisserie are usually purchased separately.

This answer is automatically generated

Summary of Contents for Char-Broil 463355220

  • Page 1 WARRANTY PART REPLACEMENT GUIDE - LED WIRE MODEL 463355220 463257520 463342620 463255020 463255721 NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from those on your particular grill model. However, the method of assembly remains the same.
  • Page 2 Each step shows removal and replacement of parts. Follow the steps in order to remove parts, then reverse the steps to replace all parts. Remove / replace WARMING RACK, COOKING GRATES and EMITTERS. WARMING RACK COOKING GRATE EMITTER Remove / replace all burner HITCH PINS, CARRYOVER TUBES. Lift back end of burner up to disengage from valve and rest on back wall of firebox.
  • Page 3 For 463355220/ 463257520/ 463342620 Remove / replace SIDE BURNER GRATE. SIDEBURNER GRATE For 463255020/ 463255721 Remove / replace SIDE BURNER GRIDDLE and GRATE. SIDEBURNER GRIDDLE SIDEBURNER GRATE PAGE 3...
  • Page 4 NOTE: 463342620 and 463255020, no LED wire harness connection at side burner. SIDE BURNER SIDE BURNER LED WIRE WING NUT ELECTRODE HARNESS WIRE For 463355220/ 463257520 Remove / replace side burner CONTROL KNOB, BEZEL and SIDE BURNER VALVE. SIDE BURNER KNOB SIDE BURNER BEZEL SIDE BURNER VALVE PAGE 4...
  • Page 5 For 463342620/ 463255020/ 463255721 Remove / replace side burner CONTROL KNOB, BEZEL and SIDE BURNER VALVE. SIDE BURNER KNOB SIDE BURNER VALVE Remove / replace bottom two shelf mounting screws. Loosen / tighten top two shelf mounting screws. Lift shelf up and out to remove shelf.
  • Page 6 Remove / replace DOOR ASSEMBLY. PRESS APPUYEZ OPRIMA DOOR ASSEMBLY Remove / replace CONTROL PANEL. CONTROL PANEL PAGE 6...
  • Page 7 Remove / replace LED WIRE HARNESS. LED WIRE HARNESS REVERSE THE STEPS TO ASSEMBLE THE GRILL. NOTE: READ THE USE AND CARE GUIDE IN INSTRUCTION MANUAL PRIOR TO LIGHTING THE GRILL. PAGE 7...
