- Page 1 FAUCET SPECIFICATIONS Pull-Down Spray Kitchen Faucet Model VG02012 MODEL VG02012 FEATURES PACKING LIST DIMENSIONS MODEL # HOLE FAUCET SPRAYER DIAMETER HEIGHT REACH VG02012 1 3/8" 16 3/4" 8 7/8" 8 7/8" 1 3/8" NOTE: All faucets are compliant to CEC 2016 regulations.
- Page 2 1 1/4" 3 1/4" 8 7/8" 2 1/4" SIDE VIEW 1 3/8" SPRAY HOSE FRONT VIEW VG02012 THE MEASUREMENTS IN INCHES ARE ROUNDED TO THE NEAREST 3/8"...
- Page 3 Doing so will remove the ability for the product to meet certain low flow standards. Please talk to your local or statewide plumbing enforcement agency prior to modifying. Vigo is not responsible for any alterations and the affects that may come with altering the product post sale and highly advises that the client only install the product that meets the needs of their local plumbing code.
- Page 4 VIEW THE CONNECTIONS AT THE MALE AND FEMALE FLEXIBLE If you have any questions please contact the Vigo Technical Support HOSE CONNECTIONS. IF LEAKS ARE DETECTED, REFER BACK TO THE INSTRUCTIONS AND ADJUST ACCORDINGLY.
- Page 5 5.A - Remove and clean aerator. 5.B - Contact Vigo Technical Support for replacement. PARTS LIST - For any parts needed but not shown, please contact Vigo Technical Support PART PART # FINISH SUPPLY DATE INDICATOR (INTERNAL USE ONLY)
- Page 6 VIGO or an authorized VIGO dealer, through the lifetime of the original owner or end-user. VIGO warrants the cartridge component of the Product to be free from defects in workmanship and materials under normal use and service for a period of five (5) years from the initial date of purchase by the owner, contractor, or builder, from VIGO or an authorized VIGO dealer.
