USER MANUAL
ENGLISH
Thank you very much for choosing the
iiyama LCD monitor.
We recommend that you take a few
minutes to read carefully through
this brief but comprehensive manual
before installing and switching on the
monitor. Please keep this manual in a
safe place for your future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProLite XB2472HSUC and is the answer not in the manual?

Questions and answers

Summary of Contents for Iiyama ProLite XB2472HSUC

  • Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a...
  • Page 3 For displays with glossy bezels the user should consider the placement of the display as the bezel may cause disturbing refl ections from surrounding light and bright surfaces. We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com...
  • Page 4: Table Of Contents

    TABLE OF CONTENTS FOR YOUR SAFETY ................1 SAFETY PRECAUTIONS..............1 SPECIAL NOTES ON LCD MONITORS .........3 CUSTOMER SERVICE ..............3 CLEANING ..................3 BEFORE YOU OPERATE THE MONITOR ..........4 FEATURES..................4 CHECKING THE CONTENTS OF THE PACKAGE ......4 WALL MOUNTING ................5 FITTING AND REMOVAL OF BASE ..........6 CONTROLS AND CONNECTORS..........7 CONNECTING YOUR MONITOR ...........8 COMPUTER SETTING ..............9...
  • Page 5: For Your Safety

    Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fi re, electric shock or damage.
  • Page 6 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.
  • Page 7: Special Notes On Lcd Monitors

     If you have to return your unit for service and the original packaging has been discarded, NOTE please contact your dealer or iiyama service center for advice or replacement packaging. CLEANING  If you drop any materials or liquids such as water into the monitor when cleaning, WARNING unplug the power cable immediately and contact your dealer or iiyama service center.
  • Page 8: Before You Operate The Monitor

    CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama offi ce.
  • Page 9: Wall Mounting

    WALL MOUNTING  When you use with the wall mounting, in consideration of thickness of the mounting WARNING stage, tighten the M4 Screw with washer which “L” length is 10mm to fasten the monitor. Using the screw longer than this may cause electric shock or damage because it may contact with the electrical parts inside the monitor.
  • Page 10: Fitting And Removal Of Base

    FITTING AND REMOVAL OF BASE CAUTION  Put the monitor on a stable surface. The monitor may cause injury or damage if it falls or is dropped.  Do not give a strong impact to the monitor. It may cause damage. ...
  • Page 11: Controls And Connectors

    CONTROLS AND CONNECTORS <Front> <Back> Microphone Web Camera Web Camera Indicator Light indicating webcam is on. NOTE Power Indicator Blue: Normal operation NOTE Orange: Power Management Power Switch ( Menu Button (MENU) Scroll Up / Volume ( Scroll Down / ECO Mode ( Input select / Select Button (INPUT/EXIT) Speakers MIC Out connector...
  • Page 12: Connecting Your Monitor

    An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce.
  • Page 13: Computer Setting

     Audio / MIC connection MIC In Audio Audio Audio Cable for MIC Headphone Audio Cable Computer  Web Camera connectin 1. Connect the monitor to one of the PC's USB2.0 ports using the included USB cable. 2. PC will detect the Web Camera automatically. NOTE ...
  • Page 14: Adjusting The Height And The Viewing Angle

    ADJUSTING THE HEIGHT AND THE VIEWING ANGLE  For optimal viewing it is recommended to position yourself directly opposite to the full face of the monitor, then adjust the monitor’s height and angle to your own preference.  Hold the panel so that the monitor does not topple 130mm when you change the monitor’s height or angle.
  • Page 15: Operating The Monitor

    OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 26. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 19 for SCREEN ADJUSTMENTS.
  • Page 16: Adjustment Menu Contents

    ADJUSTMENT MENU CONTENTS Picture Picture Brightness Contrast Display H.Position Audio Settings V.Position Miscellaneous Phase Information Clock Color Temp 6500 Auto Adjust 1920 x 1080 60Hz Adjustment Item Problem / Option Button to Press Too dark 1,5,6 Brightness* Too bright Too dull Contrast * Too intense Too left...
  • Page 17 Adjust the Brightness when you are using the monitor in a dark room and feel the screen is too bright. See page 19 for SCREEN ADJUSTMENTS. Only Analog Input. For best results, use the Auto Adjust in conjunction with the adjustment pattern. See page 19 for SCREEN ADJUSTMENTS.
  • Page 18 Picture H.Position V.Position Display OSD Timeout Audio Settings Transparency Miscellaneous Information 1920 x 1080 60Hz Adjustment Item Problem / Option Button to Press OSD is too left H.Position OSD is too right OSD is too low V.Position OSD is too high You can set the OSD display duration time OSD Timeout between 5 and 30 seconds.
  • Page 19 Display Full Picture Display Mode i-Style Color Standard Display Adv. Contrast Audio Settings X-Res Technology Miscellaneous Sharpness Information Overdrive Gamma Blue Light Reducer 1920 x 1080 60Hz Adjustment Item Problem / Option Button to Press Expansion display Full Display Mode Aspect Expansion display of Aspect Displayed at the same magnifi...
  • Page 20 Audio Settings Picture Volume Mute Display Audio Input Line in Audio Settings Miscellaneous Information 1920 x 1080 60Hz Adjustment Item Problem / Option Button to Press Too soft Volume Direct Too loud Off Return the sound volume to the previous level. Mute Turn off...
  • Page 21 NOTE In Power Management Mode input switching is disabled. Input source is fi xed, not selected automatically when VGA, DVI and DisplayPort which are selected. iiyama Logo does not display when the monitor is Off turned on. Opening Logo iiyama Logo displayed when the monitor is turned on.
  • Page 22 Information Picture Display 1920 x 1080 Audio Settings H:67kHz V:60Hz Miscellaneous Auto Information SN: xxxxxxxxxxxxx 1920 x 1080 60Hz Adjustment Item Problem / Option Button to Press Displays information regarding the current input signal coming from the graphic card in your computer. Information NOTE See your graphic card user guide for more information...
  • Page 23: Screen Adjustments

    If the screen has a fl icker or blur, or the picture does not fi t in the display area after performing the Auto Image Adjust, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http:// www.iiyama.com).
  • Page 24 Press the AUTO Button. (Auto Adjust) Adjust the image manually by following procedure below when the screen has a fl icker or blur, or the picture does not fi t in the display area after performing the Auto Image Adjust. Adjust the V.Position so that the top and bottom of the picture frame will fi...
  • Page 25 Adjust the Phase to correct horizontal wavy noise, fl icker or blur in the zebra pattern. NOTE  In case the strong fl icker or blurs remain on a part of the screen, repeat steps because the Clock may not be adjusted correctly. If the fl icker or blurs still remain, set the refresh rate of computer to low (60Hz) and repeat steps from again.
  • Page 26: Power Management Feature

    POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of ENERGY ® STAR and VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer.
  • Page 27: Trouble Shooting

    MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem...
  • Page 28: Recycling Information

    A strange noise is  The Audio Cable is properly connected. heard. RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com/recycle for monitor recycling. 24 TROUBLE SHOOTING / RECYCLING INFORMATION...
  • Page 29: Appendix

    APPENDIX Design and specifi cations are subject to change without prior notice. SPECIFICATIONS Size Category 24" LCD Panel Panel technology VA Size Diagonal: 23.6" (59.8cm) Pixel pitch 0.2715mm H × 0.2715mm V Brightness 250cd/m (Typical) Contrast ratio 3000 : 1 (Typical) Viewable angle Right / Left: 89 degrees each, Up / Down: 89 degrees each (Typical) Response time...
  • Page 30: Dimensions

    DIMENSIONS 557.0mm/21.9” 60.5mm/2.4” 523.5mm/20.6” 250.0mm/9.8” ) : Maximum adjustment range COMPLIANT TIMING Dot Clock Horizontal Vertical Video Mode Frequency Frequency 31.469kHz 59.940Hz 25.175MHz 31.500MHz 37.500kHz 75.000Hz 640 × 480 37.861kHz 72.809Hz 31.500MHz 35.156kHz 56.250Hz 36.000MHz 37.879kHz 60.317Hz 40.000MHz SVGA 800 × 600 49.500MHz 46.875kHz 75.000Hz...
