USER MANUAL
ENGLISH
Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes
to read this comprehensive manual carefully
before installing and switching on the monitor.
Please keep this manual in a safe place for
your future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProLite XB24B3HSU and is the answer not in the manual?

Questions and answers

Related Manuals for Iiyama ProLite XB24B3HSU

Summary of Contents for Iiyama ProLite XB24B3HSU

  • Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read this comprehensive manual carefully before installing and switching on the monitor. Please keep this manual in a safe place for...
  • Page 3 IIYAMA CORPORATION: Wijkermeerstraat 8, 2131 HA Hoofddorp, The Netherlands Model No. : PL2483H We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com You can access the Web page of diff...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS FOR YOUR SAFETY ................1 SAFETY PRECAUTIONS..............1 SPECIAL NOTES ON LCD MONITORS .........3 CUSTOMER SERVICE ..............3 CLEANING ..................3 BEFORE YOU OPERATE THE MONITOR ..........4 FEATURES..................4 CHECKING THE CONTENTS OF THE PACKAGE ......4 INSTALLATION ................5 FITTING AND REMOVAL OF BASE : ProLite XB2483HSU ...7 FITTING AND REMOVAL OF BASE : ProLite X2483HSU ....8 CONTROLS AND CONNECTORS : ProLite XB2483HSU ....9 CONTROLS AND CONNECTORS : ProLite X2483HSU ....10...

  • Page 5: For Your Safety

    Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fi re, electric shock or damage.
  • Page 6 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.

  • Page 7: Special Notes On Lcd Monitors

     If you drop any materials or liquids such as water into the monitor when cleaning, WARNING unplug the power cable immediately and contact your dealer or iiyama service center.  For safety reasons, turn off the power switch and unplug the monitor before you CAUTION clean it.

  • Page 8: Before You Operate The Monitor

    CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama offi ce.

  • Page 9: Installation

    INSTALLATION WARNING  Before installation, make sure the wall, ceiling or desktop arm is strong enough to hold the necessary weight of the display and the mount. < WALL MOUNTING > WARNING  When you use with the wall mounting, in consideration of thickness of the mounting stage, tighten the M4 Screw with washer which “L”...
  • Page 10 < ROTATING THE DISPLAY > ● ProLite XB2483HSU The monitor is designed to be compatible with both landscape and portrait modes. Video card for portrait display will be required for rotating the image on the screen. Available Not Available Power Indicator Landscape Power Indicator Portrait...

  • Page 11: Fitting And Removal Of Base : Prolite Xb2483Hsu

    FITTING AND REMOVAL OF BASE : ProLite XB2483HSU  Put the monitor on a stable surface. The monitor may cause injury or damage if it CAUTION falls or is dropped.  Do not give a strong impact to the monitor. It may cause damage. ...

  • Page 12: Fitting And Removal Of Base : Prolite X2483Hsu

    FITTING AND REMOVAL OF BASE : ProLite X2483HSU  Put the monitor on a stable surface. The monitor may cause injury or damage if it CAUTION falls or is dropped.  Do not give a strong impact to the monitor. It may cause damage. ...

  • Page 13: Controls And Connectors : Prolite Xb2483Hsu

    CONTROLS AND CONNECTORS : ProLite XB2483HSU <Front> <Back> Power Indicator Blue: Normal operation NOTE Orange: Power Management Power Switch ( Menu / Select Button (ENTER) Scroll Up / Volume Button ( Scroll Down / ECO Mode Button ( Exit Button (EXIT) Auto Button (INPUT) Speakers USB Downstream Connector (...

  • Page 14: Controls And Connectors : Prolite X2483Hsu

    CONTROLS AND CONNECTORS : ProLite X2483HSU <Front> <Back> Power Indicator NOTE Blue: Normal operation Orange: Power Management Power Switch ( Menu / Select Button (ENTER) Scroll Up / Volume Button ( Scroll Down / ECO Mode Button ( Exit Button (EXIT) Auto Button (INPUT) Speakers USB Downstream Connector (...

  • Page 15: Connecting Your Monitor : Prolite Xb2483Hsu

    An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce.

  • Page 16: Connecting Your Monitor : Prolite X2483Hsu

    An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce.

  • Page 17: Computer Setting

    COMPUTER SETTING  Signal Timing Change to the desired signal timing listed on page 32: COMPLIANT TIMING. ADJUSTING THE VIEWING ANGLE : ProLite X2483HSU  For optimal viewing it is recommended to look at the full face of the monitor. ...

  • Page 18: Adjusting The Height And The Viewing Angle : Prolite Xb2483Hsu

    ADJUSTING THE HEIGHT AND THE VIEWING ANGLE : ProLite XB2483HSU  For optimal viewing it is recommended to position yourself directly opposite to the full face of the monitor, then adjust the monitor’s height and angle to your own preference. 130mm ...

  • Page 19: Operating The Monitor

    OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 32. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 23 for SCREEN ADJUSTMENTS.

  • Page 20: Adjustment Menu Contents

    ADJUSTMENT MENU CONTENTS Picture Adjust * Adjustment Item Problem / Option Button to Press Too dull Contrast * Too intense Too dark 1,2,4 Brightness * Too bright Off / +1 / +2 Overdrive It will improve the gray level response time of the LCD panel. A higher level results in a faster response time.
  • Page 21 Input Select Adjustment Item Problem / Option Button to Press Select the Analog input. HDMI Select the Digital (HDMI) input. Input Select Direct Select the Digital (DisplayPort) input. DisplayPort Search for an available input source and select Auto automatically. Input source is fi xed, not selected automatically when VGA, HDMI and DisplayPort which NOTE are selected.
  • Page 22 Color Adjust Adjustment Item Problem / Option Button to Press Cool * Bluish white Normal * Greenish white Warm * Reddish white Too weak User Color * Green Too strong Blue Return to a state set by color adjustment except Off...
  • Page 23 Image Adjust Adjustment Item Problem / Option Button to Press Adjust H. / V. Position, Clock and Phase automatically. Auto Adjust * Direct Too left H. Position * Too right Too low V. Position * Too high Too narrow Clock * Too wide Phase * To correct fl...
  • Page 24 OSD is too high You can set the OSD display duration time between OSD Time Out 5 and 30 seconds. iiyama Logo does not display when the monitor is Off turned on. Opening Logo iiyama Logo displayed when the monitor is turned on.
  • Page 25 Display Information Displays information regarding the current input signal coming from the graphic card in your computer. Display Information 1 9 2 0 x 1 0 8 0 @ 6 0 H z See your graphic card user guide for more information about changing the NOTE resolution and refresh.
  • Page 26 ● Lock Mode <OSD Menu> 1. The OSD lock will be activated by pressing the front button ENTER for about 10 seconds. If you try to access the OSD by pressing any of the buttons, message "OSD Locked" will appear on the screen.

  • Page 27: Screen Adjustments

    If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Adjust, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http://www.iiyama. com).
  • Page 28 Press the AUTO Button. (Auto Adjust) Adjust the image manually by following procedure below when the screen has a fl icker or blur, or the picture does not fi t in the display area after performing the Auto Adjust. Adjust the V.Position so that the top and bottom of the picture frame will fi t to the display area.
  • Page 29 Adjust the Phase to correct horizontal wavy noise, fl icker or blur in the zebra pattern. NOTE  In case the strong fl icker or blurs remain on a part of the screen, repeat steps because the Pixel Clock may not be adjusted correctly. ...

  • Page 30: Power Management Feature

    POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There is a power management step the monitor takes as described below.

  • Page 31: Trouble Shooting

    MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem...

  • Page 32: Recycling Information

    A strange noise is The Audio Cable is properly connected. heard. RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com for monitor recycling. 28 TROUBLE SHOOTING / RECYCLING INFORMATION...

  • Page 33: Appendix

    APPENDIX Design and specifi cations are subject to change without prior notice. SPECIFICATIONS : ProLite XB2483HSU Size Category 24" Panel technology AMVA Size Diagonal: 23.8" (60.5cm) Pixel pitch 0.275mm H × 0.275mm V Brightness 250cd/m (Typical) Panel Contrast ratio 3000 : 1 (Typical), Adv. Contrast Function Available Viewable angle Right / Left : 89 °...

  • Page 34: Specifications : Prolite X2483Hsu

    SPECIFICATIONS : ProLite X2483HSU Size Category 24" Panel technology AMVA Size Diagonal: 23.8" (60.5cm) Pixel pitch 0.275mm H × 0.275mm V Brightness 250cd/m (Typical) Panel Contrast ratio 3000 : 1 (Typical), Adv. Contrast Function Available Viewable angle Right / Left : 89 ° each, Up / Down : 89 ° each (Typical) Response time 4ms (Gray to Gray) Display Colors...

  • Page 35: Dimensions : Prolite Xb2483Hsu

    DIMENSIONS : ProLite XB2483HSU 552.5mm/21.8” 56.5mm/2.2” 528.5mm/20.8” 240.0mm/9.4” ) : Maximum adjustment range DIMENSIONS : ProLite X2483HSU 552.5mm/21.8” 56.5mm/2.2” 528.5mm/20.8” 238.0mm/9.4” APPENDIX 31...

  • Page 36: Compliant Timing

    COMPLIANT TIMING Horizontal Vertical Video Mode Dot Clock Frequency Frequency 640 × 480 31.469kHz 59.940Hz 25.175MHz 800 × 600 37.879kHz 60.317Hz 40.000MHz 1024 × 768 48.363kHz 60.004Hz 65.000MHz 1280 × 1024 63.981kHz 60.020Hz 108.000MHz 1440 × 900 55.935kHz 59.887Hz 106.500MHz 1680 ×...
