OWNER'S MANUAL
MINI WASHER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
FH8G5XDNK3
MFL68881088
Copyright © 2017 LG Electronics Inc. All Rights Reserved.
www.LGSIGNATURE.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIGNATURE FH8G5XDNK3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG SIGNATURE FH8G5XDNK3

Summary of Contents for LG SIGNATURE FH8G5XDNK3

  • Page 1 Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. FH8G5XDNK3 www.LGSIGNATURE.com MFL68881088 Copyright © 2017 LG Electronics Inc. All Rights Reserved.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS This manual may contain images or content different from the model you purchased. This manual is subject to revision by the manufacturer. SAFETY INSTRUCTIONS ............4 IMPORTANT SAFETY INSTRUCTIONS ............ 4 Disposal of Your Old Appliance ..............9 INSTALLATION ..............10 Parts ......................

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. This symbol is displayed to indicate matters and operations that can cause risk.
  • Page 5 Installation •Never attempt to operate the appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug. •This appliance should only be installed and transported by two or more people holding the appliance securely. •Do not install the appliance in a damp and dusty place.
  • Page 6 •If the power cord is damaged or the hole of the socket outlet is loose, do not use the power cord and contact an authorized service centre. •This appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the appliance, in such a way that a full opening of the appliance door is restricted.
  • Page 7 Improper use can cause fire or explosion. •In case of flood, disconnect the power plug and contact the LG Electronics customer information centre. •Do not push down the drawer excessively, when the appliance...
  • Page 8 •Do not touch the door during a high temperature programme. •Do not use flammable gas and combustible substances (benzene, gasoline, thinner, petroleum, alcohol, etc.) near the appliance. •If the drain hose or inlet hose is frozen during winter, use it only after thawing.

  • Page 9: Disposal Of Your Old Appliance

    Toll Free No. 1800-315-9999 / 1800-180-9999 for details. All collection centre and pick up facilities are done by third parties with LG Electronics India Pvt. Ltd. Merely as a facilitator. For more detailed information ,...

  • Page 10: Installation

    INSTALLATION Parts Door Power Plug Drum Water Drain Hose Stacking Switch Leveling Feet Control Panel Unlock Button Drawer Remote Sensor Water Supply Hose...

  • Page 11: Accessories

    Accessories Water supply hose Connecting Water drain hose Water supply hose Water drain hose (for cold water) supply hose connector connector Anti-slip sheets Detergent Brackets (front) Brackets (back) Spanner (2 EA) measuring (2 EA) (2 EA) * Screws Cable ties Band clamp Stacking holder Remote control...

  • Page 12: Installation Place Requirements

    Installation Place • Do not install the appliance in rooms where freezing temperatures may occur. Frozen Requirements hoses may burst under pressure. The reliability of the electronic control unit may be Location impaired at temperatures below freezing point. • Ensure that when the appliance is installed, it 135 cm is easily accessible for an engineer in the 123 cm...

  • Page 13: Stacking Mini Washer

    Stacking Mini Washer Assemble the bracket (front) and stacking holder at the bottom of Main Washer. Stacking holder • First assemble the stacking holder using 2 type A screws included in the accessory box, then each bracket using 7 type A Brackets (front) screws included in the accessory box.
  • Page 14 Turn the top cover about 180 degrees. Securely attach the two appliances at the corners using 14 type A screws. • Cover the upper hole with the top cover and install 4 type B screws to fix it in • First, insert screws on each side. Then place.

  • Page 15: Connecting The Supply Hose

    Connecting the Supply Hose Connecting Hose to Water Tap • Water supply pressure must be between 0.1 Connecting Screw-Type Hose to Tap MPa and 0.8 MPa (1.0‒8.0 kgf/cm with Thread • Do not overtighten the water supply hose. Screw the hose connector onto the water •...
  • Page 16 Push the adapter onto the end of the tap so Remove the guide plate if the tap is too that the rubber seal forms a watertight large to fit the adapter. connection. Tighten the four fixing screws. Guide plate Push the supply hose vertically upwards so that the rubber seal within the hose can Push the adapter onto the end of the tap so adhere completely to the tap and then...

  • Page 17: Installing The Drain Hose

    Installing the Drain Hose Connecting Hose to Two Washing Machines • The drain hose should not be placed higher than 100 cm above the floor. Water in the Connect the water supply hose connector to appliance may not drain or may drain slowly. the water supply hose of the front-loading washing machine.

  • Page 18: Leveling The Appliance

    Leveling the Appliance Using the Drain Hose Connector If the floor is uneven, turn the adjustable feet as Connect the drain hose of Main Washer required (Do not insert pieces of wood etc. and Mini Washer to the drain connector. under the feet).
  • Page 19 • Push or rock the top edges of the appliance gently to make sure that the appliance does not rock. If the appliance rocks, level the appliance again. NOTE • You can obtain anti-slip sheets from the LG Service Centre.

  • Page 20: Operation

    OPERATION Using the Application Select Mini Washer on the quick circle display of Main Washer, then Choose the desired washing programme. Sort laundry and load items. • The options are selected by default • Sort laundry by fabric type, soil level, functions automatically.

  • Page 21: Sorting Laundry

    Sorting Laundry Caring before loading. • Do not wash 'memory wire' on female Look for a care label on your clothes. inner wear (such as a brassiere) as it may damage other clothes or the washing • This will tell you about the fabric content machine and create noise.

  • Page 22: Using The Door And Drawer

    • If power failure occurs during product Closing the Door and Drawer operation, the door cannot be opened. Provide the power again or contact the LG service Push the O marked down on the door until centre. it clicks.

  • Page 23: Adding Cleaning Products

    Adding Cleaning Products Adding Detergent Measure the detergent with the detergent Detergent Dosage dispenser and pour it into the tub. • Detergent should be used according to the instruction of the detergent manufacturer and selected according to type, colour, soiling of the fabric and washing temperature.
  • Page 24 Adding Softeners NOTE • Do not pour fabric softener directly on the clothes. Adding Fabric Softener • The softener can also be diluted with water CASE 1. When the machine chimes: and added directly into the drum. Do not pour Press Start/Pause to pause the cycle.

  • Page 25: Control Panel

    Control Panel You can operate the machine by selecting from the control panel on Main Washer, Mini Washer or the remote control. Control Panel on Main Washer Display Programme Button • The display shows the cycle status and • Programmes are available according to estimated time remaining.
  • Page 26 Control Panel on Mini Washer Power Button Start/Pause Button • Press the Power button to turn the • The Start/Pause button is used to start washing machine on. the wash cycle or pause the wash cycle. • If a temporary stop of the wash cycle is Display needed, press the Unlock button on the •...

  • Page 27: Programme Table

    Programme Table Washing Programme Maximum Programme Description Note Load Use this programme to • To change the setting during wash lightly soiled normal Light Soil washing, change the setting after 2.0 kg items, except delicate pressing Start/Pause button. fabrics such as wool or silk. Use this programme to wash delicate items such as lingerie or sheer and...

  • Page 28: Option Programme

    Option Programme Tub Clean Use this option to keep the drum clean. For Rinse+ information on using Tub Clean, see the Cleaning the Washing Machine section. Use this option to increase the number of rinsing programmes. Child Lock Press the Power button. Use this option to disable the controls.

  • Page 29: Smart Functions

    Use this function if you need an accurate • The communication performance will improve diagnosis by an LG Electronics service centre and you can receive better service if you use when the product malfunctions or fails. Use this the home phone.

  • Page 30: Maintenance

    MAINTENANCE Cleaning the Interior WARNING • Unplug the washing machine before cleaning • Use a towel or soft cloth to wipe around the to avoid the risk of electric shock. Failure to washing machine door opening and door follow this warning may result in serious injury, glass.

  • Page 31: Cleaning The Drum

    Cleaning the Drum Cleaning the Water Inlet Filter Use the Tub Clean option to keep the drum • Turn off the stopclock if the washing machine clean. is to be left for any length of time (e.g. holiday), especially if there is no floor drain (gully) in the immediate vicinity.

  • Page 32: Cleaning The Lint Filter

    Insert the lower part of the filter into the drum and close the cap until you hear a click sound. NOTE • When the lint filter is damaged, contact LG service centre. • Do not operate the washing machine without the lint filter.
  • Page 33 How to Handle Freezing Step 3. When the Drain Pump is Frozen • icon may blink on the display when drain pump problems occur, take the following Step 1. When the Door is Frozen measures. • Thaw out the door using a hot water cloth. Pour 15 ℓ...

  • Page 34: Troubleshooting

    TROUBLESHOOTING The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the appliance does not function properly or does not function at all, check the following before you call for service: Diagnosing Problems Symptoms Reason...
  • Page 35 Symptoms Reason Solution • Always wash dark colors separately from light colors and whites to prevent Clothes were not properly Staining discoloration. sorted. • Never wash heavily soiled items washed with lightly soiled items. Supply hose connection is • Check hoses and drain hose connectors loose at the tap, washing for leaks, cracks and splits.
  • Page 36 Symptoms Reason Solution Control panel has powered • This is normal. Press the Power button off due to inactivity. to turn the washing machine on. Washing machine is • Make sure cord is plugged securely into unplugged. a working outlet. Water supply is turned off.
  • Page 37 Symptoms Reason Solution • Make sure the inlet filters on the fill Filter clogged. valves are not clogged. Refer to the filter cleaning instructions. • Check that supply hoses are not kinked Supply hoses may be kinked. or clogged. • Make sure that the cold water tap is Insufficient water supply.

  • Page 38: Error Messages

    Error Messages Symptoms Reason Solution • Close the drawer and press Start/Pause button to start the cycle. Drawer is not closed • If the drawer is closed and the drawer properly. lock error message is displayed, call for service. • Open the drawer and make sure the latch area is free of clothing or other obstructions.
  • Page 39 • Mini Washer will not operate as a operated without a full-size standalone unit. It must be stacked under washing machine. an LG front-loading washing machine. • The stacking switch will not operate properly if the unit is not stacked under a Stacking switch is not matching LG Signature washer.
  • Page 40 Memo...
  • Page 41 Memo...
  • Page 42 Memo...
