Core Aerators
CA0540, CA0548 & CA0556
30006
Table of Contents
!
Read the Operator's Manual entirely. When you see this symbol,
the subsequent instructions and warnings are serious - follow
without exception. Your life and the lives of others depend on it!
Cover photo may show optional equipment not supplied
with standard unit.
For an Operator's Manual and Decal Kit in French
Language, please see your Land Pride dealer.
325-108M
Operator's Manual
Printed 2/12/21
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Land Pride CA0548
Summary of Contents for Land Pride CA0548
- Page 1 Your life and the lives of others depend on it! Cover photo may show optional equipment not supplied with standard unit. For an Operator’s Manual and Decal Kit in French Language, please see your Land Pride dealer. Printed 2/12/21...
-
Page 2: Machine Identification
Serial Number Machine Height Machine Length Machine Width Machine Weight Delivery Date First Operation Accessories Dealer Contact Information Name: Street: City/State: Telephone: Email: California Proposition 65 WARNING: Cancer and reproductive harm - www.P65Warnings.ca.gov CA0540, CA0548 & CA0556 Core Aerators 325-108M 2/12/21... - Page 3 Land Pride assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Land Pride reserves the right to revise and improve its products as it sees fit. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future.
- Page 4 Land Pride products. App on your smart phone, open the App, Refer to Parts Manual QR point your phone on the QR code and Locator on this page for take a picture. detailed instructions. CA0540, CA0548 & CA0556 Core Aerators 325-108M 2/12/21...
-
Page 5: Important Safety Information
Important Safety Information Important Safety Information Listed below are common practices that may or may not be applicable to the products described in this manual. Safety at All Times Look for the Safety Alert Symbol Careful operation is you best The SAFETY ALERT SYMBOL indicates there is a assurance against an accident. -
Page 6: Transport Safely
Replace parts on this implement correct tools and equipment. follow all shutdown procedures with genuine Land Pride parts only. Always properly match the wheel before leaving the operator’s seat to Do not alter this implement in a way size to the properly sized tire. -
Page 7: Avoid High Pressure Fluids
Use Seat Belt and ROPS Keep Riders Off Lights and Devices Machinery Land Pride recommends the use of a CAB or roll-over-protective- Slow moving tractors, and Never carry riders on the tractor or structures (ROPS) and seat belt self-propelled equipment can implement. - Page 8 Important Safety Information Listed below are common practices that may or may not be applicable to the products described in this manual. Avoid crystalline Silica Be aware of and follow OSHA If possible, change into disposable (or other local, State, or Federal) or washable work clothes at the (quartz) Dust guidelines for exposure to airborne...
- Page 9 Important Safety Information This page left blank intentionally. 2/12/21...
-
Page 10: Safety Labels
Spray soapy water onto the cleaned area. all damaged or missing labels. Order new labels from your Peel backing from label and press label firmly onto the nearest Land Pride dealer. To find your nearest dealer, surface. visit our dealer locator at www.landpride.com. -
Page 11: Using This Manual
Table of Contents Introduction Introduction Owner Assistance Land Pride welcomes you to the growing family of new product owners. This Core Aerator has been designed The dealer should complete the Online Warranty with care and built by skilled workers using quality Registration at the time of purchase. -
Page 12: Tractor Requirements
Figure 1-3. 30010 5. Repeat steps 1 to 4 until all spoons and grease zerks Gang Assembly of Eight Spoons are assembled to the gang spools. Figure 1-3 CA0540, CA0548 & CA0556 Core Aerators 325-108M 2/12/21... - Page 13 CA0540 Rotor Shaft Assembly 4. Install gang assembly (#2B), 1" flat washer (#6), spacer (#4), and second flat washer (#6) on the rotor These instructions are for the 40" Aerator. See “CA0548 shaft. Rotor Shaft Assembly” on page 10 for 48" Aerator and 5.
- Page 14 (#6) on rotor shaft (#5). 4. Install gang assembly (#2B), 1" flat washer (#6), center support (#3), and second flat washer (#6) on the rotor shaft. Direction of Rotation 30009 CA0548 Rotor Shaft Assembly Figure 1-5 CA0540, CA0548 & CA0556 Core Aerators 325-108M 2/12/21...
- Page 15 Rotor Shaft Assembly” on page 9 for 48" Aerator and 6. Install gang assembly (#2D), 1" flat washer (#6), “CA0548 Rotor Shaft Assembly” on page 10 for 48" spacer (#4), and second flat washer (#6) on the rotor Aerator.
- Page 16 1/2"-13 x 1" GR5 cap screws (#5) and 1/2" hex nylock nuts (#7). Do not tighten nuts. 2. (CA0548 & CA0556 only.) Attach center supports (#2) to weight tray (#3) with 3/8"-16 x 1 GR5 cap screws (#4) and 3/8" hex nylock nut (#6).
-
Page 17: Wheel Assembly
(#12). Install hand grip (#12) on Figure 1-9 transport arm handle. 9. Repeat steps 1 to 8 for the right side. 10. Grease wheel bearings per Lubrication Points Instructions on page 19. 30008 Wheel Assembly Figure 1-8 2/12/21 CA0540, CA0548 & CA0556 Core Aerators 325-108M... -
Page 18: Start-Up Checklist
Never pull the Aerator behind a vehicle at high speeds. Do not use spoons to tear up asphalt or for anything High speeds can cause the tires to break resulting in loss of other than to aerate soil. control. CA0540, CA0548 & CA0556 Core Aerators 325-108M 2/12/21... -
Page 19: Tractor Hook-Up
Insert hitch pin keeper into the hitch pin between the top and lower hitch straps. 5. Be sure implement is clear of tractor and then drive tractor away from implement. 2/12/21 CA0540, CA0548 & CA0556 Core Aerators 325-108M... -
Page 20: Field Set-Up
2. Fully insert cotterless hitch pin (#1) in hole “B” . 3. Repeat Steps 1 and 2 for the other side. 30012 Wheels Set For Transporting Figure 2-1 30011 Wheels Set For Field Work Figure 2-2 CA0540, CA0548 & CA0556 Core Aerators 325-108M 2/12/21... - Page 21 By now you should have read your Operator’s Manual undisturbed thatch layer setting off a microbial action that and properly hitched up to your Land Pride 05 Series accelerates thatch breakdown. The vegetation portion of Core Aerator. If you haven’t, please do so now.
-
Page 22: Long Term Storage
4. Repaint parts where paint is worn or scratched to WARNING prevent rust. Ask your Land Pride dealer for aerosol To avoid serious injury or death: touch-up paint. Paint is also available in touch-up... -
Page 23: Lubrication Points
CA0556 = Seven places Type of Lubrication: multi-purpose grease lube Quantity = As Required 30012 Hours Wheel Bearing Two places (1- zerk per wheel) Type of Lubrication: multi-purpose grease lube Quantity = As Required 30013 2/12/21 CA0540, CA0548 & CA0556 Core Aerators 325-108M... -
Page 24: Section 4: Specifications & Capacities
4" Spoon Penetration 3" Depending on ground conditions and added weights. Plug size 1/2" Diameter Number of Gangs (Two spoon gangs per gang) Gang spacing 8" Hitch Pull type clevis hitch 30014 CA0540, CA0548 & CA0556 Core Aerators 325-108M 2/12/21... -
Page 25: Section 5: Features & Benefits
Offers optimum core pulling pattern & aeration. 4" Spoon spacing laterally 4.2 Aeration cores per sq. ft. Provides good aeration per square foot. Weight tray Additional weight can be easily added to the aerator. 2/12/21 CA0540, CA0548 & CA0556 Core Aerators 325-108M... -
Page 26: Section 6: Troubleshooting
There may not be enough moisture in the ground. Wait for rain or irrigate the area. The spoons may be clogged due to improper cleaning from the previous use. Refer to “Clean Spoons” on page 18. CA0540, CA0548 & CA0556 Core Aerators 325-108M 2/12/21... -
Page 27: Torque Values Chart For Common Bolt Sizes
Torque tolerance + 0%, -15% of torquing values. Unless otherwise specified use torque values listed above. Tire Inflation Chart Tire Size Inflation psi 10 x 3 1/4 x 4 24 psi. max. 2/12/21 CA0540, CA0548 & CA0556 Core Aerators 325-108M... - Page 28 Table of Contents Section 7: Torque & Tire Inflation Charts CA0540, CA0548 & CA0556 Core Aerators 325-108M 2/12/21...
-
Page 29: Warranty
This Warranty is limited to the repair or replacement of any defective part by Land Pride and the installation by the dealer of any such replacement part, and does not cover common wear items such as blades, belts, tines, etc. Land Pride reserves the right to inspect any equipment or parts which are claimed to have been defective in material or workmanship. - Page 30 Corporate Office: P.O. Box 5060 Salina, Kansas 67402-5060 USA www.landpride.com...
