Data
Projector
Operating Instructions
Before operating the unit, please read this manual and supplied Quick Reference Manual
thoroughly and retain it for future reference.
VPL-FHZ75/FHZ70
Not all models are available in all countries and area. Please check
with your local Sony Authorized Dealer.
© 2019 Sony Corporation
5-002-992-13 (1)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VPL-FHZ75 and is the answer not in the manual?

Questions and answers

Related Manuals for Sony VPL-FHZ75

Summary of Contents for Sony VPL-FHZ75

  • Page 1 Before operating the unit, please read this manual and supplied Quick Reference Manual thoroughly and retain it for future reference. VPL-FHZ75/FHZ70 Not all models are available in all countries and area. Please check with your local Sony Authorized Dealer. © 2019 Sony Corporation...

  • Page 2: Table Of Contents

    Table of Contents Turning Off the Power ....22 Overview Using Convenient Functions .... 22 Location and Function of Controls ..4 Enlarging a Part of the Image Main Unit ........4 (Digital Zoom Function) ..22 Terminals ........5 Projecting Images with Two Pictures Simultaneously (Two- Remote Commander and Control...
  • Page 3 Setting the Control Protocol of the Projector ......46 Others Indicators ......... 49 Messages List ........51 Troubleshooting ....... 52 Cleaning the Air Filter ..... 55 Replacing the Projection Lens ..56 Removing ........56 Attaching ........57 Specifications ........58 Projection Distance and Lens Shift Range ...........

  • Page 4: Location And Function Of Controls

    B Overview Location and Function of Controls Main Unit a Lens (page 56) l Control panel (page 6) b Front panel m Antitheft lock Connects to an optional antitheft cable c Side cover (page 55) manufactured by Kensington. For details, visit the Kensington’s web d Ventilation holes (intake) site.

  • Page 5: Terminals

    Terminals h AUDIO OUT Input (page 8) Audio: Audio output terminal (AUDIO) a INPUT A Note Video: RGB/YP input terminal These terminals output projected images or (RGB/YP audio. As for images, the signal input from Audio: Audio input terminal (AUDIO) INPUT A is output from OUTPUT A, and the b INPUT B signal input from INPUT B is output from...

  • Page 6: Remote Commander And Control Panel

    Remote Commander and Control Panel Remote Commander Select the VIDEO (VIDEO IN) signal with the INPUT key. The E, F, and G keys are not used with this projector. c TWIN (Twin Picture) key Simultaneously projects images from two input signals on the screen as a main picture and subpicture (page 22).
  • Page 7 j MUTING key • If there is any obstruction between the Remote Commander and the remote Mutes the audio output. Press again to control receiver on the projector, the restore the previous volume. projector may not be able to receive k BLANK key signals from the Remote Commander.

  • Page 8: Connecting The Projector

    B Preparation Connecting the Projector Notes • Turn off all equipment before making any connections. • Use the proper cables for each connection. • Insert the cable plugs firmly; Loose connections may reduce performance of picture signals or cause a malfunction. When pulling out a cable, be sure to grip it by the plug, not the cable itself. •...

  • Page 9: Connecting Video Equipment

    Notes • Use HDMI-compatible equipment which has the HDMI Logo. • Use a high speed HDMI cable(s) on which the cable type logo is specified. (Sony products are recommended.) • The HDMI terminal of this projector is not compatible with DSD (Direct Stream Digital) signal or CEC (Consumer Electronics Control) signal.
  • Page 10 Notes • Use HDMI-compatible equipment which has the HDMI Logo. • Use a high speed HDMI cable(s) on which the cable type logo is specified. (Sony products are recommended.) • The HDMI terminal of this projector is not compatible with DSD (Direct Stream Digital) signal or...

  • Page 11: Connecting An External Monitor And Audio Equipment

    To fix the HDMI cable Fix the cable to the cable tie holders at the sides of the terminals using a commercially available cable tie, as shown in the illustration. Use a cable tie of less than 1.9 mm × 3.8 mm in thickness. Cable tie (commercially available) Cable tie holders Connecting an External Monitor and Audio Equipment...

  • Page 12: Connecting Network Equipment

    OUTPUT B Display equipment DVI-D input DVI-D cable (not terminal supplied) Note This terminal outputs projected images. The images are output when a computer signal is input from the DVI-D input terminal (INPUT B). However, if the signal input from INPUT B is protected by HDCP, the signal is not output to OUTPUT B.

  • Page 13: Connecting To Hdbaset™ Equipment

    Notes for connecting this unit and the HDBaseT transmitter • Ask a professional or Sony dealer to perform wiring. If wiring is not correct, the transmission characteristics of the cable will not be achieved, and image or sound may break up or you may experience unstable performance.
  • Page 14 • The transmittable distance of the cable is 100 m (approx. 328 feet) maximum. If it exceeds 100 m (approx. 328 feet), it may cause the image or the sound to break up, or cause a multifunction in LAN communication. Do not use the HDBaseT transmitter beyond the transmittable distance.

  • Page 15: Attaching The Terminal Cover

    Attaching the terminal cover Example of the cable layout in the cover You can attach the supplied terminal cover to prevent dust from entering the terminals to maintain a neat appearance. Fit one shaft on the side of the terminal cover into the hole on the bottom, then fit the other shaft by bending the cover slightly.

  • Page 16: Projecting/Adjusting An Image

    B Projecting/Adjusting an Image Projecting an Image The size of a projected image depends on the distance between the projector and screen. Install the projector so that the projected image fits the screen size. For details on projection distances “Projection Distance and Lens Shift Range” (page 65) and projected image sizes, see Input select window Wall outlet...

  • Page 17: Adjusting The Focus, Size, And Position Of The Projected Image

    Adjusting the Focus, Size, and Position of the Projected Image Focus Size (Zoom) Position (Lens shift) When attaching the Electric When attaching the Electric Press the LENS SHIFT/SHIFT focus lens zoom lens key on the projector or the Press the FOCUS key on the Press the ZOOM key on the Remote Commander then press the V/v/B/b key to adjust the...

  • Page 18: Correcting For Trapezoidal Distortion Of The Projected Image (Keystone Adjustment)

    Adjust the value using B/b. Adjusting the tilt of the projector The higher the setting, the narrower the with the front feet (adjustable) top of the projected image. The lower When the projector is installed on an uneven the setting, the narrower the bottom of surface, you can adjust using the front feet the projected image.

  • Page 19: Correcting Image Twist (Warp Correction Feature)

    Adjust the value using B/b. Select “Warping.” The higher the setting, the narrower the The guide is displayed. right side of the projected image. The lower the setting, the narrower the left side of the projected image. When correcting the corner(s) of Increase the setting the image Move x using V/v/B/b to select the...
  • Page 20 When correcting deflection on the When correcting deflection on the left/right sides of the image top/bottom sides of the image Move x using V/v/B/b to select the Move x using V/v/B/b to select the side you want to correct. side you want to correct. Press the ENTER key.

  • Page 21: Blending Projections From Multiple Projectors On A Screen

    (page 36) In this case, space the projectors farther apart and/or install deflection partitioning between them. Enable the Edge Blending function. For more details, consult with qualified Sony In “Blend Settings,” set “Edge personnel. Blending” to “On” for each blending position.

  • Page 22: Turning Off The Power

    Turning Off the Power Using Convenient Functions Press the ?/1 key on the main unit or the 1 key on the Remote Commander. The projector starts shutdown and turns off. Enlarging a Part of the Image For long-term use, turn off the projector (Digital Zoom Function) when not in use.

  • Page 23: Setting The Energy-Saving Mode (Eco Mode)

    Press the ECO MODE key to display the ECO Mode menu. One picture display ECO Mode User Back TWIN key Press the V/v key or ECO MODE key to select “ECO” or “User” mode. Two pictures display ECO: Sets each mode to the optimum energy-saving value.

  • Page 24: Using A Menu

    B Adjustments and Settings Using a Menu To return to the selection screen of the Using a Menu setting items, press the B key or the RETURN key. Also, to reset the setting value of an item to its factory preset value, press the RESET key during Note setting or adjusting.

  • Page 25: Projection Setting Menu

    Projection Setting Menu The Projection Setting menu is used for optimum settings appropriate to the installation location and picture adjustments for input signals. Setting items Description Intelligent On/Off: When you set to “On,” you can optimize the picture settings, light Setting settings, and system cooling performance (fan rotation speed) by selecting the installation location from "Location"...
  • Page 26 Setting items Description Light Settings Dynamic On/Off: Brightness is adjusted automatically according to image content. Dark Control images are projected with brightness adjusted, leading to energy-saving. Bright images are projected brightly, without adjusting brightness. Light Adjusts brightness of the light source. Output Standard: The image becomes brighter, and power consumption becomes Mode...
  • Page 27 Setting items Description Color On: Adjusts the hue, saturation, and brightness for the selected color. Repeat Correction steps 1 and 2 described below to specify the target color. 1 Press V/v to select “Color Select,” then press B/b to select the color you want to adjust among “Red,”...

  • Page 28: The Screen Menu

    The Screen Menu For adjusting the size, position, and aspect ratio of the projected image for each input signal. Setting items Description Aspect Changes the aspect ratio of the projected image (page 30). When the Full 1: Displays the image to fit the maximum projected image size without computer changing the aspect ratio of the input signal.
  • Page 29 *2: Available when a video signal is input from the RGB/YP input terminal (INPUT A), DVI-D input terminal, HDMI input terminal, and HDBaseT terminal. *3: Available when “Aspect” is “Zoom” and “Screen Aspect” is 16:10 or 16:9. *4: Available when a computer signal is input from the RGB/YP input terminal (INPUT A).
  • Page 30 Aspect *1: If you select “Normal,” the image is Input signal Recommended projected in the same resolution as the setting value and input signal without changing the aspect projected image ratio of the original image. *1 *2 (4:3) (Full 1) *2: If you select “Full 2,”...

  • Page 31: The Function Menu

    The Function Menu The Function menu is used for setting various functions of the projector. Setting items Description Audio Output Vol. The higher the setting, the higher an audio level output from the audio output terminal. The lower the setting, the lower the audio level. Smart APA On/Off: When set to “On,”...

  • Page 32: The Operation Menu

    *1: When “All Off” is selected, warning message for high temperature is not displayed. *2: Note that Sony is not liable for failure of the unit or any accident caused by selecting “All Off.” *3: You will not be able to use the projector if you forget your password. If you call qualified Sony personnel because you have forgotten the password, you will be asked to verify the projector’s...
  • Page 33 identity has been confirmed, we will provide you with the password.

  • Page 34: The Connection/Power Menu

    The Connection/Power Menu The Connection/Power menu is used for setting for the connections and power. Setting items Description Network Setting IPv4 Setting IP Address Setup Auto(DHCP): The IP address is assigned automatically from the DHCP server such as a router. Manual: To specify the IP Address manually.
  • Page 35 Setting items Description *8 *9 With Static Signal Light Dimming : If an image does not change for about 10 seconds, light output is gradually reduced (approximately 10% to ) from that set in the Light Output Mode. This setting provides a convenient way to reduce power consumption.

  • Page 36: The Installation Menu

    The Installation Menu The Installation menu is used for installing the projector. Setting items Description Screen Fitting Adjusts the distortion of the projected image that occurs due to installation conditions or when a portion of the image spreads beyond the screen. Warping: Select an adjustment point and move it vertically/horizontally to adjust the image distortion.
  • Page 37 Setting items Description Blend Configure the Edge Blending setting for the top, bottom, right, and left of Settings the screen respectively. Left/Right/Top/Bottom: Set the Edge Blending effect for each position. Edge Blending: Set “On” to set “Blending Range” or “Blend Start Pos.” Blending Range: Set the width where images are overlapped.
  • Page 38 Setting items Description Blanking This feature allows you to adjust the displayable region within the four directions of the projection surface. Select the edge to adjust from “Left,” “Right,” “Top,” and “Bottom” using the V/v keys. Adjust the amount of blanking using the B/b keys. Panel Alignment This feature allows you to adjust the gaps in the color of characters or the picture.
  • Page 39 *9: When the projected image is displayed smaller than the entire projection surface using the Aspect or Screen Aspect setting, blanking may not be applied. *10:Depending on the adjustment value of “Panel Alignment,” the color and resolution may be changed.

  • Page 40: The Information Menu

    The Information Menu The Information menu enables you to confirm various information on the projector, such as the total usage hours of a light. Items Description Model Name Displays the model name. Serial No. Displays the serial number. fH / fV (horizontal Displays the horizontal frequency/vertical frequency/signal type of the frequency/vertical current input signal.

  • Page 41: Using Network Features

    B Network Using Network Displaying the Control Window of the Projector with Features a Web Browser Connection to the network allows you to Connect the LAN cable (page 12). perform the following: • Checking the current status of the Set the network settings for the projector.

  • Page 42: Confirming The Settings For The Projector

    The default password “Projector” cannot be set as a new password. Note If you forget your password, consult with qualified Sony personnel. Page Switching buttons The password will be reset with your permission. Setting the access limitation You can limit a user for accessing any particular page.

  • Page 43: Using The E-Mail Report Function

    Using the e-mail Report Function Set the e-mail report function on the Setup page. Entered values will not be applied unless you click on [Apply]. Notes • The e-mail report function is not available on the network where Outbound Port25 Blocking is used and cannot connect to the SMTP server.
  • Page 44 Set the mail account for sending e- Confirm the content of the e-mail mail reports. report. Mail Address: Enter the e-mail address. When you click on [View], the content Outgoing Mail Server (SMTP): Enter of the e-mail report are displayed. the address of outgoing mail server (SMTP).

  • Page 45: Configure The Network Settings

    Network button LAN Network setting area Configure the Network Set the items for Internet protocol. Settings (a) IPv4/IPv6 address You can configure the network settings for Obtain an IP address automatically the projector in “Network Setting” of the (DHCP): Automatically provides the Connection/Power menu.

  • Page 46: Setting The Control Protocol Of The Projector

    Setting the Control Protocol input. The factory default setting is of the Projector “SONY.” To avoid unwanted access to the projector from other computers, Change the settings for the control protocol changing the community name of the on the Setup page.
  • Page 47 Only four default password, refer to the PJ Link alphanumeric characters can be input. specifications. The factory default setting is “SONY.” Click on [PJ Control API] to display To avoid unwanted access to the the PJ Control API page.
  • Page 48 Start PJ Control API Service: Set PJ Resetting the network settings Control API to enabled or disabled. Reset the network settings to their factory -Requires Authentication: Set the defaults. authentication for PJ Control API to enabled or disabled. -PSK(Pre-Shared Key): Input the PSK (Pre-Shared Key) for authentication.

  • Page 49: Indicators

    B Others Indicators You can check the projector status or abnormality by checking the lighting/flashing status of the ON/STANDBY indicator and WARNING indicator on the front. If the indicators flash in red, address the problem in accordance with “Warning indicators and remedies” (page 50). ON/STANDBY WARNING indicator...
  • Page 50 If the indicators flash in a manner other than described above, unplug the AC power cord and make sure the ON/STANDBY indicator turns off, then plug the AC power cord into the wall outlet and turn on the projector. If the problem still persists, consult with qualified Sony personnel.

  • Page 51: Messages List

    Although “Constant Brightness” is selected, the brightness that cannot be maintained. is set cannot be maintained due to the lifetime of the light source. Consult with qualified Sony personnel. Filter cleaning will start. The filter will be automatically cleaned after the projector is turned off.

  • Page 52: Troubleshooting

    Troubleshooting Before asking to have the projector repaired, try to diagnose the problem, following the instructions below. Symptom Remedy Page The power is not turned Check if the AC power cord is firmly connected. – When the “Control Key Lock” is set to “On,” you cannot turn on the projector using the ?/1 key on the projector.
  • Page 53 Symptom Remedy Page Edges of the image are If you use the lens shift function with a setting outside the cut off or dark. recommended range, edges of the image may be cut off or appear dark. Use a setting within the normal range for the lens shift function.
  • Page 54 Symptom Remedy Page The projector suddenly Turn the power off and then on again to check the operating – restarted. status. If the symptom occurs frequently, consult with qualified Sony personnel.

  • Page 55: Cleaning The Air Filter

    For details on a new air filter, consult with qualified Sony personnel. Caution Loosen the screws (four) and pull out If you continue to use the projector even...

  • Page 56: Replacing The Projection Lens

    Clean the air filter with a vacuum Replacing the cleaner. Projection Lens Replace the air filter and attach the filter cover. When attaching the filter cover, fit the Notes two tabs on the right into place, turn the • Avoid removing/attaching the lens with the filter cover using the right side as an projector installed suspended from a ceiling.

  • Page 57: Attaching

    projection lens counterclockwise to pull out the lens straight. Note LENS RELEASE When attaching the projection lens, do not Projection lens button press the LENS RELEASE button. Attaching Fully insert the projection lens with the index on the lens facing toward the top surface of the main unit.

  • Page 58: Specifications

    Light source Laser diode Projected image 40 inches to 600 inches (1.02 m to 15.24 m) size Light output VPL-FHZ75: 6,500 lm (when “Light Output Mode” is set to “Standard”) VPL-FHZ70: 5,500 lm (when “Light Output Mode” is set to “Standard”)
  • Page 59 –10 °C to +60 °C (14 °F to +140 °F)/ 20% to 80% (no temperature/ condensation) Storage humidity Power required VPL-FHZ75: AC 100 V to 240 V, 5.4 A to 2.2 A, 50/60 Hz VPL-FHZ70: AC 100 V to 240 V, 4.9 A to 2.0 A, 50/60 Hz Power...
  • Page 60 Item Description Mass Approx. 16 kg (34 lb) Supplied See “Checking the Supplied Accessories” in the supplied accessories Quick Reference Manual. Optional Projection Lens VPLL-3007: Manual focus, Projected *2 *3 *4 accessories image size: 60" to 300" (1.52 m to 7.62 m), Maximum external dimensions (W ×...
  • Page 61 *1: For details, refer to “Acceptable Input Signals” on page 63. *2: Not all optional accessories are available in all countries and area. Please check with your local Sony Authorized Dealer. *3: Information on accessories in this manual is current as of April 2019.
  • Page 62 RGB input terminal (Mini D-sub 15- Pin assignment pin, female) DVI-D terminal (DVI-D, female) Video input Power supply T.M.D.S. +5 V Power (red) R input for DDC Data2– Video input T.M.D.S. Ground (return (green) G Data2+ for +5 V) Video input T.M.D.S.
  • Page 63 HDMI terminal (HDMI, female) Input terminal fH [kHz]/ INPUT B/ Resolution fV [Hz] INPUT A INPUT C/ INPUT D 800 × 600 35.2/56 – T.M.D.S. T.M.D.S. 37.9/60 Data2+ Clock Shield 48.1/72 – T.M.D.S. T.M.D.S. Data2 Shield Clock– 46.9/75 – T.M.D.S. 53.7/85 –...
  • Page 64 Video signal Input terminal INPUT B/ Signal fV [Hz] VIDEO INPUT A INPUT C/ INPUT D NTSC – – PAL/ – – SECAM 480i – 576i – 480p – 576p – 1080i – 1080i – 720p – 720p – 1080p –...

  • Page 65: Projection Distance And Lens Shift Range

    Projection Distance and Lens Shift Range The projection distance refers to the distance between the front of the lens and the projected surface. Projection distance L Front of the lens Projected image The lens shift range represents the distance in percent (%) by which the lens can be shifted from the center of the projected image.
  • Page 66 Projection distance Unit: m (inches) Projection image size Projection distance L Diagonal Width × Height Standard lens VPLL-3007 VPLL-Z3009 80" (2.03 m) 1.72 × 1.08 2.36 – 3.86 1.09 1.44 – 1.69 (68 × 42) (93 – 152) (43) (57 – 66) 100"...
  • Page 67 Lens shift range x Standard lens = 70 – 2.187 × (HS or HS ) [%] – = 5 – 0.156 × (HS or HS ) [%] – – = 32 – 0.457 × VS = 32 – 6.400 × VS –...

  • Page 68: Dimensions

    Dimensions Front Unit: mm (inches) 460 (18 Center of the lens 230 (9 Bottom Unit: mm (inches) 515 (20 425 (16 406.1 (16) 283.6 (11 133 (5 69 (2 ø24 ( 13 ( Holes for ceiling mount (M5, Depth 8 (...

  • Page 69: About Trademarks

    About Trademarks • Adobe Acrobat is a trademark of Adobe Systems Incorporated. • Kensington is a registered trademark of Kensington Technology Group. • Internet Explorer is registered trademarks of Microsoft Corporation in the United States and/or other countries. • Safari is a registered trademark of Apple Corporation in the United States and/or other countries.
  • Page 70 Sony Corporation...
