Wind Direction | Wind Speed | Rain
Features
• Wind direction
• Wind speed
• Rainfall
• Solar Panel for extended
battery life
• Replaceable directional vane
• Replaceable wind cups
• Self-emptying rain sensor
• Updates every 30 seconds
Multi-sensor
Wind
cups
Batteries
3-AA
Rain funnel
(collector)
Model: TX233RW
DC: 111116
Directional
Vane
Red LED
Light
Drain holes for
multi sensor
Drain vents for rain
sensor
Reset
button
RESET
Advertisement
Related Manuals for La Crosse Technology TX233RW
Summary of Contents for La Crosse Technology TX233RW
- Page 1 • Solar Panel for extended RESET battery life • Replaceable directional vane Drain holes for • Replaceable wind cups multi sensor • Self-emptying rain sensor • Updates every 30 seconds Rain funnel (collector) Drain vents for rain sensor Model: TX233RW DC: 111116...
- Page 2 Power • Requires 3-AA batteries for operation. • Solar panel extends battery life but cannot operate multi-sensor alone. Replace Wind Cups 1. Loosen the screw on side of cups 2. Remove cups 3. Install new cups 4. Tighten screw on flat side of stem Replace Directional Vane 1.
- Page 3 • Dimensions: 13.62” W x 13” H x 5.16” D in (345.95 x 330.20 x 131.06 mm) Warranty and Support La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product relating to manufacturing defects in materials & workmanship.
