- Page 1 WIRELESS R AIN STATI ON WITH INDOOR/OUTDOOR TEMP + HUMIDITY MODEL #: 724-1415BL DC: 032619 WIRELESS RAIN STATION Page | 1...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 3. Power Up 3. Button Functions 4. Basic Settings 6. Flower Icon 7. Rainfall Readings 7. Rain History 9. Reset Rain 10. Optional Backlight 10. Optional Auto Dim Backlight 11. Indoor & Outdoor Temperature/Humidity Readings 11. Low Battery Indicator 12. -
Page 3: Power Up
P OW E R U P 1. Insert 2-AA batteries into your TH Sensor. 2. Insert 2-AA batteries into your Rain Sensor. 3. Insert 2-AA batteries into your Rain Station Display. 4. Configure Basic Settings. Note: Use the USB Power Cord for constant backlight. Rain Station Thermo-Hygro (TH) Sensor Rain Sensor... -
Page 4: Basic Settings
For better programming instructions, please note these terms for button use: • Press: Press the designated button. • Hold: Hold the button for 3 seconds (or 5 seconds if resetting) then release the button. Note: For any function other than Factory Reset, be sure to press or hold only one button at a time. Note: If no buttons are pressed for 10 seconds your station will return to normal rain display. - Page 5 HOUR MINUTES YEAR MONTH DATE FAHRENHEIT/CELSIUS INCHES/MILLIMETERS AVERAGE/HIGH/LOW WIRELESS RAIN STATION Page | 5...
-
Page 6: Flower Icon
FLOW ER IC ON In most regions of the country, the AVERAGE Rainfall Setting will work just fine. However, if you’re in a region that has higher or lower than average rainfall per year, make sure to select the appropriate setting in the Settings Menu. -
Page 7: Rainfall Readings
RAI N FA L L R E AD INGS Your Rain Station provides a 24 hour reading as the default setting. This allows you to quickly see the rainfall total for the past day. However when new rain occurs, your station will temporarily switch to a Current Rain view so you can keep up on the latest storm total. - Page 8 Note: You can toggle through the past 11 months of rainfall history when you are in Month view. Press the HISTORY button to view MONTH Rainfall. Press and release the PLUS (+) button to toggle through the past monthly history readings. YEAR: Current year January 1-December 31 total.
-
Page 9: Reset Rain
RESET RAIN HISTORY When viewing Rain History, Hold the (-) MINUS button to reset the History readings individually. The reading will show dashes briefly then show zero. MONTH RAIN MONTH RAIN RESET 24 HOUR RAIN ALERT 1. Hold the HISTORY button 2 seconds to enter settings mode. 2. -
Page 10: Optional Backlight
Active Rain Alert: • When the armed alert value is reached, your station will beep 5 times each minute, until out of alert range. The flashing alert icon will indicate alert. • Press any button to stop the temp alert sound. •... -
Page 11: Indoor & Outdoor Temperature/Humidity Readings
AUTO DIM OFF AUTO DIM ON START AUTO DIM STOP AUTO DIM The AUTO DIM icon will show constantly when Auto Dim is set. INDOOR & OUTDOOR TEMPERATURE / HUMIDITY READINGS • Your station has both Outdoor Temperature/Humidity and Indoor Temperature/Humidity. •... -
Page 12: Search For Sensors
SEARCH FOR SENSORS • If either sensor loses connection, the station will show NO after 30 minutes of no reception. • The station will automatically search for 3 minutes every hour to try and reestablish the sensor connection. • To manually search for both sensors, hold the PLUS (+) button until the Reception Icon begins to flash. -
Page 13: Specifications
Dimensions: 7.14”L x 3.43”W 4.94”H (18.13 cm L x 8.72 cm W x 12.54 cm H) WA R R AN TY IN F O La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product relating to manufacturing defects in materials & workmanship.
Need help?
Do you have a question about the 724-1415BL and is the answer not in the manual?
Questions and answers
No it is not responding to my input, I **** trying to find ot if the Monitor is defective?
The provided context does not confirm whether the La Crosse Technology 724-1415BL Monitor is defective if it is not responding to input. However, you can try troubleshooting by checking the owner's manual for a "Search for Sensor" option, enabling a search, and pressing the TX button on the sensor. If interference is suspected, you can try relocating the device, increasing separation from other electronics, or using a different power outlet. If the issue persists, consulting technical support may be necessary.
This answer is automatically generated
How to clear rain fall on 724-1415BLv2
I have done the set up to replace my sensor. The sensor came on (light) and is now blinking about every 45-60 seconds. The main unit is not responding for the time it is clicking off minutes (presently at 12:14) the remote monitor is blank. The indoor indicates at temp of 76.3 F. The total display is very dim, it came on bright then it change to dim after about 60 seconds. How do I check to the to make sure it is working and not defective? Unit model is 588907. The new sensor is model TX141TH-BV3 HELP
