Table of Contents

Introduction

Specifications

Theory of Operation
Installation
Front Panel
Rear Panel
Relay (1 of 8) and BCD Output Voltage
Maintenance
Lightning Protection
Technical Support
Warranty
Introduction
Congratulations on your purchase of the CC-8A Control Console. Its unique design features both 1-
of-8 and BCD control. This allows it to be used with existing 1-of-8 systems like the DX
Engineering DXE-RR8-HP remote 8 port RF switch, or BCD systems like the DXE-RFS-2P and
DXE-FVC-1. Its universal nature allows operation with any 1-of-8 or BCD system of compatible
voltage. We know you are anxious to get started but before you install the CC-8A, take a few
minutes to read this brief user guide and familiarize yourself with the installation, operation and
safety procedures. We are confident that you will find this control console easy to use and that it
will reward you with years of faithful service.
This unit is RoHS (Reduction of Hazardous Substances) compliant. The components, including the
solder used are all lead free. If you decide to do any modifications or internal repairs, you
should use only lead free solder and lead free soldering tools. Lead free solder melts
approximately 100 degrees (F) higher than the old leaded solder, so you may need to
upgrade your current soldering system.
Specifications
LED (Light Emitting Diode) Brightness
Switching Positions
Power Required
Output Control Voltage
DC Output Protection
Output format
Eight
+ 12 Vdc (nominal) 1 to 1.5 A
+ 12 Vdc (nominal)
Fully Adjustable
Internal automatic reset fuse
Standard 1-of-8 and BCD
2
2
2
3
3
3
4
6
7
7
8
8
