Introduction Table of Contents Thank you for choosing this Sony product. Before operating the TV, please read this manual thoroughly and retain it for future reference. Note • Before operating the TV, please read the “Safety Information” (page 2). • Instructions about “Installing the TV to the Wall” are included within this TV’s instructions manual.
Page 3
• Only qualified service personnel should carry out wall-mount installations. • For safety reasons, it is strongly recommended that you use Sony accessories, including: Wall-Mount Bracket: SU-WL450 • Be sure to use the screws supplied with the Wall-Mount Bracket when attaching the Wall-Mount Bracket to the TV set. The supplied screws are designed as indicated by illustration when measured from the attaching surface of the Wall-Mount Bracket.
Page 4
AC power cord (mains lead) with the plug that fits into the AC power outlet (mains socket). M6 screw • Use only Sony supplied AC power cords (mains lead), not those (not supplied) of other brands.
If the following problems occur... Turn off the TV set and unplug the AC power cord (mains lead) immediately if any of the following problems occur. Ask your dealer or Sony service centre to have it checked by qualified service personnel.
Page 6
You may contact our company’s toll free number in India for assistance. Toll Free: 1800-103-7799 Visit: www.sony.co.in for product recycling Reduction in the Use of Hazardous Substances in Electrical & Electronic Equipment (Applicable in Republic of India)
(Sensors/LED indicator) • Receives signals from the remote control. Parts and Controls Do not put anything over the sensor. Doing so may affect its function. • Lights up in amber when the [Sleep Timer]* or [On Timer]* is set, or the TV is in Photo Frame Mode*.
SYNC MENU Remote Control Press to display the BRAVIA Sync Menu and then select connected HDMI equipment from [Device Selection]. The following options can be selected from The remote control shape, location, BRAVIA Sync Menu. availability and function of remote control Device Control: buttons may vary depending on your Use the [Device Control] to operate...
Page 9
SLEEP NETFLIX (Only on limited region/ country/TV model) Press repeatedly until the TV displays the time in minutes ([Off]/[15 min]/[30 min]/ Accesses the “NETFLIX” online service. [45 min]/[60 min]/[90 min]/[120 min]) that you want the TV to remain on before Exit Text mode, or switches to a TV display shutting off.
Connecting TV to the Internet Watching TV Setting up the Internet Press on the TV or the remote control Connection to turn on the TV. To use the network features of your TV it needs Press the number buttons or PROG +/– to be connected to the Internet.
Viewing Pictures from Connected Equipment Connection Diagram You can connect a wide range of optional equipment to your TV. Note • Depending on TV model, connecting a large USB device may interfere with other connected devices beside it. • When connecting a large USB device, connect only 1 USB jack. Headphone/ HDMI Device Audio...
To Customers: For product protection and safety reasons, Sony strongly recommends that installation of your TV be performed by Sony dealers or licensed contractors. Do not attempt to install it yourself. To Sony Dealers and Contractors: Provide full attention to safety during the installation, periodic maintenance and examination of this product.
Page 13
Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV. Refer to the following table on installing the TV to the wall. See page 18-19 (Specifications) for the TV’s weight. Standard mounting Slim mounting Screen centre point...
Page 14
Standard mounting KD-55X7002F Pulley Screw (+PSW 6 x 20) Spacer (60 mm) Screw (+PSW 6 x 50) Belt KD-49/43X7002F Screw (+PSW 6 x 50) Screw (+PSW 6 x 20) Pulley Spacer (60 mm) Soft cloth ...
Page 15
Slim mounting Note • You cannot use some of the terminals on the rear of the TV when using this mounting style. KD-55X7002F Pulley Spacer (20 mm) Screw (+PSW 6 x 20) Belt KD-49/43X7002F Screw (+PSW 6 x 20) ...
Page 16
Connect necessary cables to the TV. Note • You cannot access to any terminal after installing the TV to the wall. To detach the Table-Top Stand from the TV. KD-55X7002F Install the TV to the Base. Refer to “5” of Installation Guide and “Installing the TV to the Wall”...
Check if the [Duration]* is activated by [On Timer]* If the problem persists, contact your dealer or or [Photo Frame Settings]*. Sony service centre with the number of times Check if the [Idle TV Standby]* is activated. the LED indicator flashes red (interval time is Some input sources cannot be selected three seconds).
Audio: Two channel linear PCM: 32/44.1/48 kHz 16/20/ Specifications 24 bits, Dolby Digital, Dolby Digital Plus, DTS ARC (Audio Return Channel) (HDMI IN 3 only) System Two channel linear PCM: 48 kHz 16 bits, Dolby Digital, Dolby Digital Plus, DTS Panel system DIGITAL AUDIO OUT (OPTICAL) LCD (Liquid Crystal Display) Panel, LED backlight...
Page 19
Association. (Only on limited region/country/TV • “PlayStation” is a registered trademark and model) “PS4” is a trademark of Sony Interactive • Compatible with all HDR PS4 Game titles Entertainment Inc. via HDMI and HDR videos of built-in Netflix • For DTS patents, see and YouTube App only.
