    4-732-885-11(1) Television Operating Instructions HOME Help Guide KD-65X7000F / 55X7077F / 55X7000F / 49X7077F / 49X7000F / 43X7000F...
  • Page 2: Table Of Contents

    Introduction Table of Contents Thank you for choosing this Sony product. Before operating the TV, please read this manual thoroughly and retain it for future reference. Note • Before operating the TV, please read the “Safety Information” (page 3). • Instructions about “Installing the TV to the Wall” are included within this TV’s instructions manual.
  • Page 3: Safety Information

    Safety Information installations. • For safety reasons, it is strongly recommended that you use WARNING Sony accessories, including: Wall-Mount Bracket: SU-WL450 Caution • Be sure to use the screws supplied with the Wall-Mount Bracket when attaching the Wall-Mount Bracket to the TV set. The Risk of explosion if the battery is replaced by an incorrect type.
  • Page 4 AC power outlet (mains socket). (not supplied) • Use only Sony supplied AC power cords (mains lead), not those of other brands. • Insert the plug fully into the AC power outlet (mains socket).
  • Page 5: Precautions

    (candles, etc.). The TV set shall not be Ask your dealer or Sony service centre to have it checked by exposed to dripping or splashing and no objects filled with qualified service personnel.
  • Page 6 Wireless Function of the unit • Do not operate this unit near medical equipment (pacemaker, etc.), as this may result in the malfunction of the medical equipment. • Although this unit transmits/receives scrambled signals, be careful of unauthorised interception. We cannot be responsible for any trouble as a result.
  • Page 7: Parts And Controls

     (Sensors/LED indicator) • Receives signals from the remote control. Parts and Controls Do not put anything over the sensor. Doing so may affect its function. • Lights up in amber when the [Sleep Timer]* or [On Timer]* is set, or the TV is in Photo Frame Mode*.
  • Page 8: Remote Control

     Number buttons Remote Control • Select channels. For channel numbers 10 and above, enter the next digit quickly. • In text mode, enter the three digit page number to select the page. The remote control shape, location, availability and function of remote control ...
  • Page 9   +/– (Volume) Return to TV: Select this option to return to the TV Adjusts the volume. programme.  AUDIO   (Text) Select the sound of multilingual source or In text mode, displays Text broadcast. dual sound for the programme currently Each time you press , the display changes being viewed (Depend on programme cyclically as follows:...
  • Page 10: Connecting Tv To The Internet

    Connecting TV to the Internet Watching TV Setting up the Internet Press  on the TV or the remote control Connection to turn on the TV. To use the network features of your TV it needs Press DIGITAL/ANALOG to switch to be connected to the Internet.
  • Page 11: Equipment

    Viewing Pictures from Connected Equipment Connection Diagram You can connect a wide range of optional equipment to your TV. Note • Depending on TV model, connecting a large USB device may interfere with other connected devices beside it. • When connecting a large USB device, connect only 1 USB jack. Headphone/ HDMI Device Audio...
  • Page 12: Additional Information

    To Customers: For product protection and safety reasons, Sony strongly recommends that installation of your TV be performed by Sony dealers or licensed contractors. Do not attempt to install it yourself. To Sony Dealers and Contractors: Provide full attention to safety during the installation, periodic maintenance and examination of this product.
  • Page 13 Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV. Refer to the following table on installing the TV to the wall. See page 18-19 (Specifications) for the TV’s weight. Standard mounting Slim mounting Screen centre point...
  • Page 14 Standard mounting KD-65/55X7000F, KD-55X7077F Pulley  Screw (+PSW 6 x 20)  Spacer (60 mm)  Screw (+PSW 6 x 50)  Belt  KD-49X7077F, KD-49/43X7000F   Screw (+PSW 6 x 50) Screw (+PSW 6 x 20)  Pulley ...
  • Page 15 Slim mounting Note • You cannot use some of the terminals on the rear of the TV when using this mounting style. KD-65/55X7000F, KD-55X7077F Pulley  Spacer (20 mm)  Screw (+PSW 6 x 20)  Belt  KD-49X7077F, KD-49/43X7000F ...
  • Page 16 Connect necessary cables to the TV. Note • You cannot access to any terminal after installing the TV to the wall. To detach the Table-Top Stand from the TV. KD-65/55X7000F, KD-55X7077F Install the TV to the Base. Refer to “5” of Installation Guide and “Installing the TV to the Wall”...
  • Page 17: Troubleshooting

    Check if the [Duration]* is activated by [On Timer]* If the problem persists, contact your dealer or or [Photo Frame Settings]*. Sony service centre with the number of times  Check if the [Idle TV Standby]* is activated. the LED indicator flashes red (interval time is Some input sources cannot be selected three seconds).
  • Page 18: Specifications

    Audio: Two channel linear PCM: 32/44.1/48 kHz 16/20/ Specifications 24 bits, Dolby Digital, Dolby Digital Plus, DTS ARC (Audio Return Channel) (HDMI IN 3 only) System Two channel linear PCM: 48 kHz 16 bits, Dolby Panel system Digital, Dolby Digital Plus, DTS LCD (Liquid Crystal Display) Panel, LED backlight DIGITAL AUDIO OUT (OPTICAL) TV system...
  • Page 19 Screen size (measured diagonally) (approx.) Mass (Approx.) KD-65X7000F: 65 inches / 163.9 cm with Table-Top Stand KD-55X7077F / KD-55X7000F: 55 inches / 138.8 cm KD-65X7000F: 21.4 kg KD-49X7077F / KD-49X7000F: 49 inches / KD-55X7077F / KD-55X7000F: 17.4 kg 123.2 cm KD-49X7077F / KD-49X7000F: 12.6 kg KD-43X7000F: 43 inches / 108.0 cm KD-43X7000F: 10.4 kg...
  • Page 20: Trademark Information

    HDMI and HDR videos of built-in Netflix DTS Digital Surround is a trademark of DTS, and YouTube App only. (See Sony support Inc. © DTS, Inc. All Rights Reserved. website for more information). • TUXERA is a registered trademark of Tuxera •...
  • Page 24 Help Guide Customer Support and Contact: © 2018 Sony Visual Products Inc. Printed in Malaysia...
