  • Page 1 Television Reference Guide KD-65X7500D / 55X7000D / 49X7000D...

  • Page 2: Table Of Contents

    Introduction Table of Contents Thank you for choosing this Sony product. Before operating the TV, please read this manual thoroughly and retain it for future reference. Note • Before operating the TV, please read the “Safety Information” (page 2). • Instructions about “Installing the TV to the Wall” are included within this TV’s instruction manual.
  • Page 3 • Never cover the ventilation holes or insert anything in the cabinet. • Leave space around the TV set as shown below. Screw • It is strongly recommended that you use a Sony Wall-Mount Wall-Mount Bracket Bracket in order to provide adequate air circulation. Installed on the wall TV’s rear cover...
  • Page 4 AC power cord (mains lead) with the plug that fits into the AC power outlet (mains socket).  Use only Sony supplied AC power cords (mains lead), not those of other brands.  Insert the plug fully into the AC power outlet (mains socket).

  • Page 5: Precautions

    Caution about handling the remote control Precautions • Observe the correct polarity when inserting batteries. • Do not use different types of batteries together or mix old and Viewing the TV new batteries. • View the TV in moderate light, as viewing the TV in poor light or •...

  • Page 6: Parts And Controls

    Parts and Controls Controls and Indicators  Remote Control sensor* / Light sensor* / Illumination LED The illumination LED lights up or blinks according to the status of the TV. • White When turning on the TV/picture off mode/software update, etc. •...

  • Page 7: Using Remote Control

    Using Remote Control Remote Control Parts Description The remote control shape, location, availability and function of remote control button may vary depending on your region/country/TV model.  /  (Text) (Input select/Text hold) In TV mode: Display and select the input Display text information.
  • Page 8  ACTION MENU  ////// Display a list of contextual functions. Operate media contents on TV and connected BRAVIA Sync-compatible device.  REC • Switch to a TV channel or input from other applications. Record the current programme with the USB •...

  • Page 9: Connection Diagram

    Connection Diagram For more information on connections, refer to the Help Guide (page 2). Headphone/ Home Audio System/ Subwoofer Digital still camera/ Camcorder/ USB storage media HDMI Device DVD player with HDMI component output Device Home Audio System with ARC/ HDMI Device HDMI Device VCR/Video game...
  • Page 10  AUDIO OUT* / < 12 mm • To listen to the TV's sound through the connected equipment, press HOME. < 21 mm Select [Settings]  [Sound]  [Headphone/Audio out] and then select the desired item.  USB 1/2, USB 3 (HDD REC)* •...

  • Page 11: Installing The Tv To The Wall

    Sufficient expertise is required for installing this product, especially to determine the strength of the wall for withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation.
  • Page 12 Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV. Refer to the following table on installing the TV to the wall. See page 16-17 (Specifications) for the TV’s weight.
  • Page 13 Attach the Attachment parts for Wall-Mount Bracket. Check the Attachment parts by referring to “1” of the Wall-Mount Bracket Installation Guide. Note • If using an electric screwdriver, set the torque at approximately 1.5 N·m {15 kgf·cm}. • Be sure to store the unused parts in a safe place for future use. Retain this manual for future reference. Standard mounting Pulley ...
  • Page 14 Pulley  Screw (+PSW 6 x 20)  Spacer (20 mm)  Screw (+PSW 6 x 20)  Belt  Connect necessary cables to the TV. Note • You cannot access to any terminal after installing the TV to the wall. Detach the Table-Top Stand from the TV.

  • Page 15: Troubleshooting

    TV. If the problem persists, contact your dealer or Sony service centre with the number of times the illumination LED flashes red (interval time is three seconds). Disconnect the AC power cord (mains lead), and inform your dealer or Sony service centre.

  • Page 16: Specifications

    The illumination LED is turned on.  Specifications If you do not wish to light up the illumination LED, you can turn it off. Press HOME, then select [Settings]  System [Illumination LED]  [Off]. Panel system LCD (Liquid Crystal Display) Panel, LED Backlight TV system Depend on your country/area selection Analogue: B/G, I, D/K, M...
  • Page 17 10BASE-T/100BASE-TX connector (Depending on the operating environment of the network, with Table-Top Stand connection speed may differ. 10BASE-T/ KD-65X7500D: 1,463 × 901 × 295 mm 100BASE-TX communication rate and KD-55X7000D: 1,245 × 770 × 235 mm communication quality are not guaranteed for KD-49X7000D: 1,107 ×...

  • Page 18: Trademark Information

    • Any functions related to Digital TV ( SIG, Inc. and any use of such marks by will only work in countries or areas where Sony Corporation is under license. Other DVB-T/DVB-T2 (MPEG-2 and H.264/MPEG- trademarks and trade names are those of 4 AVC) digital terrestrial signals are their respective owners.
  • Page 20 Help Guide Customer Support and Contact: ©2016 Sony Corporation Printed in Malaysia 4-585-026-11(1)
