- Page 1 4-692-529-11(1) Television Parts and Controls Connecting TV to the Internet Operating Instructions Watching TV Navigating through Home Menu Viewing Pictures from Connected Equipment Additional Information KD-65X7007E / 55X7007E / 49X7007E / 43X7007E...
-
Page 2: Table Of Contents
Table of Contents Safety Information ..... 3 Navigating through Home Precautions ......6 Menu All Apps . -
Page 3: Safety Information
• Install the TV so that the TV's Table-Top Stand does not protrudes out from the TV stand (not supplied). If the Table-Top Thank you for choosing this Sony product. Stand protrudes out from the TV stand, it may cause TV set to... - Page 4 Use only Sony supplied AC power cords (mains lead), not those of other brands. Insert the plug fully into the AC power outlet (mains socket).
- Page 5 TV. Ask your dealer or Sony service centre to have it checked by Situations: qualified service personnel.
-
Page 6: Precautions
Caution about handling the remote control Precautions • Observe the correct polarity when inserting batteries. • Do not use different types of batteries together or mix old and Viewing the TV new batteries. • View the TV in moderate light, as viewing the TV in poor light or •... -
Page 7: Parts And Controls
(Sensors/LED indicator) • Receives signals from the remote control. Parts and Controls Do not put anything over the sensor. Doing so may affect its function. • Lights up in amber when the [Sleep Timer] or [On Timer] is set (page 24), or the TV is in Photo Frame Mode (page 16). -
Page 8: Remote Control
EXIT Return to the previous screen or exit from Remote Control the menu. When an Interactive Application service is available, press to exit from the The remote control shape, location, availability service. and function of remote control button may vary depending on your region/country/TV model. - Page 9 +/– (Volume) (Text) (Only on limited region/ country/TV model) Adjust the volume. In text mode, displays Text broadcast. AUDIO Each time you press , the display changes Select the sound of multilingual source or cyclically as follows: dual sound for the program currently being Text ...
-
Page 10: Connecting Tv To The Internet
Type 1: Secured network with Wi-Fi Connecting TV to the Internet Protected Setup™ (WPS) The WPS standard makes security of a wireless Setting up the Internet home network as straightforward as pressing the WPS button on the wireless LAN router. Connection Before setting up a wireless LAN, check the location of the WPS button on the router and... -
Page 11: Type 2: Secured Network Without Wi-Fi Protected Setup™ (Wps)
Type 2: Secured network without Wi-Fi Type 3: Unsecured network with any Protected Setup™ (WPS) type of wireless LAN router To set up a wireless LAN, SSID (wireless network To set up a wireless LAN, SSID (wireless network name) and security key (WEP or WPA key) will be name) will be required. -
Page 12: Preparing A Wired Network
Privacy Policy When you use the following functions to Internet connect to the Internet, certain information will be sent to Sony Corporation’s global servers, Modem which is considered to be personal information, with and requires your agreement in order for service router providers to use it. -
Page 13: Watching Tv
Changing the Viewing Style Watching TV Press on the TV or the remote control Changing the Wide Mode to turn on the TV. Press repeatedly to select the wide Press ANT/DIGITAL/ANALOG to switch mode. between Cable and Antenna channels. [Wide Zoom]* [Normal] Press the number buttons or CH/PROG... -
Page 14: Setting Scene Select
Setting Scene Select Press OPTIONS. Press then to select [Scene Select]. When you select the desired scene option, the optimum picture and sound quality for selected scene are automatically set. The options you can select may vary. Unavailable options are greyed out. -
Page 15: Navigating Through Home Menu
Photo Sharing Plus Navigating through Home Menu Connect, view and save favorite photos on TV using your devices (e.g. smartphones or tablets). The HOME button allows you to access a variety of TV settings and features. HOME [All Apps] [Photo Sharing Plus] Note •... -
Page 16: Using The Tv As A Photo Frame Mode
Using the TV as a Photo Frame Mode Listening to FM Radio Photo Frame Mode displays the clock and HOME [All Apps] [FM Radio] calendar at the same time as displaying a Note photo, and listening to music or FM radio. •... -
Page 17: Favorites
Press then to select [Favorites]. You can enjoy photo/music/video files stored in a Sony digital still camera/camcorder/ smartphone (depending on models)* through a USB cable or USB storage device on your TV. Connect a supported USB device to the * Device needs to be in Media transfer mode (MTP). - Page 18 HE-AAC, Dolby Digital (2ch), The data on the USB device may be damaged. Dolby Digital Plus (2ch), DTS, • Sony will not be held liable for any damage to, or loss DTS 2.0 of, data on the recording media due to a malfunction of any connected devices or the TV.
-
Page 19: Playback Photo/Music/Video Via Home
Playback Photo/Music/Video via Home Settings Network You can enjoy various content (e.g. photo/ Preferences music/video files) stored on DLNA Certified™ media servers. The home network feature Note allows you to enjoy network content in other • The options you can adjust vary depending on the rooms. -
Page 20: Sound Adjustments
Mastered in 4K Sound Adjustments Optimises picture quality for Blu-ray Discs ClearAudio+ mastered in 4K. Applies to 1080/24p Let you enjoy the best sound quality by the signals only. combination of a well-balanced digital signal processing technology. Random noise reduction Reduce repetitive random noise. - Page 21 Stereo: Select for stereo reception when Auto Wide viewing a program broadcast in Automatically changes the wide mode stereo. according to the input signal from an Auto SAP: Select to automatically switch external equipment. the TV to second audio programs when a signal is received.
-
Page 22: Parental Lock
FM Radio Presets: Allows you to Show/Hide Channels manually tune and store each Allows you to show or hide channels that available channel one at a time. appear when you use the CH/PROG +/– Note buttons. • To enable this feature, access to FM Radio mode Press /... - Page 23 Media Server Troubleshooting Internet Lock Diagnoses whether the TV can connect Locks internet contents from being to each server on the home network. watched. Remote Start To view an internet contents, select This feature allow connected device in [Unblocked]. the home network to turn on the TV. Note •...
- Page 24 Time USB Auto Start Set Current Time. When USB device is connected to the USB port, select [On] to automatically view the Auto Startup thumbnail of the last played Photo/Music/ Starts the initial set-up procedure. This Video. option allows you to retune the TV after moving houses, or to search for new Closed Captions (CC) channels that have been launched by...
- Page 25 When set to [On], the following sound. functions are available. If the specific Digital Audio Out: Sets the audio signal Sony equipment that is compatible that is output by connecting using with BRAVIA Sync Control is digital audio output (optical) cable or connected, this setting is applied to HDMI cable.
-
Page 26: Customer Support
Note feature. • Software update via the internet may vary depending on your region/country/TV model. • To update the software, please visit Sony support Customer Support website. Provides information of your TV’s model, software, and others. For details, see page... -
Page 27: Viewing Pictures From Connected Equipment
Viewing Pictures from Connected Equipment Connection Diagram You can connect a wide range of optional equipment to your TV. Note • Depending on TV model, connecting a large USB device may interfere with other connected devices beside it. • When connecting a large USB device, connect only 1 USB jack. Headphone/Home Audio System/Subwoofer HDMI Device... - Page 28 Picture Quality • AV composite cable • HDMI cable • Antenna (aerial) cable Standard definition (SD) videos have picture signals with a High definition (HD) videos have picture signals vertical resolution of 480 (NTSC) or 576 (PAL/SECAM) lines. with a vertical resolution of 720 or 1,080 lines. (For 4K vertical resolution: 2,160 lines)
-
Page 29: Using Audio And Video Equipment
. Then, select [Yes] in the supports speed of 18 Gbps bearing the HDMI logo. confirmation display. (Recommended SONY Cable). • When connecting mono equipment, connect the To display registration notification when audio cable to the L (mono) jack. -
Page 30: Additional Information
Sufficient expertise is required for installing this product, especially to determine the strength of the wall for withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation. - Page 31 Remove the screws from the rear of the TV KD-65X7007E To detach the Table-Top Stand from the TV KD-55X7007E KD-49/43X7007E...
- Page 32 Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV. Refer to the following table on installing the TV to the wall. See page 41-42 (Specifications) for the TV’s weight.
- Page 33 Pulley Screw (+PSW 6 x 20) Spacer (60 mm) Screw (+PSW 6 x 50) Belt KD-55X7007E Screw (+PSW 6 x 50) Screw (+PSW 6 x 20) Pulley Spacer (60 mm) Belt ...
- Page 34 Screw (+PSW 6 x 20) Pulley Spacer (60 mm) Belt Soft cloth Slim mounting Note • You cannot use some of the terminals on the rear of the TV when using this mounting style. KD-65X7007E KD-55X7007E KD-49/43X7007E...
- Page 35 KD-65X7007E Pulley Spacer (20 mm) Screw (+PSW 6 x 20) Belt KD-55X7007E Screw (+PSW 6 x 20) Screw (+PSW 6 x 20) Pulley Spacer (20 mm) Belt Soft cloth...
- Page 36 KD-49/43X7007E Screw (+PSW 6 x 20) Pulley Screw (+PSW 6 x 20) Spacer (20 mm) Belt Soft cloth Connect necessary cables to the TV. Note • You cannot access to any terminal after installing the TV to the wall. To detach the Table-Top Stand from the TV.
- Page 37 Install the TV to the Base. Refer to “5” of Installation Guide and “Installing the TV to the Wall” of Operating Instructions supplied with the Wall-Mount Bracket. Model Name KD- Hook Location 65X7007E 55X7007E 49X7007E 43X7007E Refer to the instructions supplied with the Wall-Mount Bracket for your model to install the TV on the wall.
-
Page 38: Troubleshooting
The picture of a display unit is composed of If the problem persists, contact your dealer or pixels. Tiny black points and/or bright points Sony service centre with the number of times (pixels) on the screen do not indicate a the LED indicator flashes red (interval time is malfunction. -
Page 39: Channels
Screen mirroring function using providers. wireless LAN. Keep the TV or Sony Screen mirroring compatible devices (Xperia) away from Good picture quality but no sound on the such devices, or turn them off if possible. -
Page 40: General
Reconfigure your network settings. General If the LAN cable is connected to an active server and the TV has acquired an IP address, check your The TV turns off automatically (the TV enters DLNA Certified™ media server’s connections and standby mode) configurations. -
Page 41: Specifications
3840 × 2160p (24, 25, 30, 50, 60 Hz), 1080p (30, KD-65X7007E: 65 inches / 163.9 cm 50, 60 Hz), 1080/24p, 1080i (50, 60 Hz), 720p (30, KD-55X7007E: 55 inches / 138.8 cm 50, 60 Hz), 720/24p, 576p, 576i, 480p, 480i KD-49X7007E: 49 inches / 123.2 cm * HDMI IN 2 and HDMI IN 3 support High-Quality HDMI KD-43X7007E: 43 inches / 108.0 cm... -
Page 42: Trademark Information
• The terms HDMI and HDMI High-Definition KD-65X7007E: 1,454 × 905 × 266 mm Multimedia Interface, and the HDMI Logo KD-55X7007E: 1,238 × 775 × 252 mm are trademarks or registered trademarks of KD-49X7007E: 1,102 × 694 × 252 mm HDMI Licensing LLC in the United States KD-43X7007E: 971 ×... - Page 44 Customer Support and Contact: © 2017 Sony Corporation Printed in Malaysia...
