INSTALLATION AND USER MANUAL Model: MVW102BSS * Important: Read the complete manual carefully before installation and save this manual* For accuracy, measurements and rough openings should be done based on the actual hood.
INTRODUCTION Thank you for choosing this cooker hood. This instruction manual is designed to provide you with all required instructions related to the installation, use, maintenance, and warranty of the appliance. Please read this instruction manual carefully before installation and operating your range hood. This range hood is made from high quality materials and has a streamlined design.
Page 4
7. Ducted fans must always be vented to the outdoors. 8. To reduce the risk of fire, use only metal ductwork. 9. This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current.
Page 5
4. ONLY USE AN EXTINGUISHER IF: • You know you have a Class ABC extinguisher and you already know how to operate it. • The fire is small and contained in the area where it started. • The fire department is being called. •...
2. TOOLS AND PARTS REQUIREMENTS Parts Supplied Required tools: Part Photo Electrical drill or ratchet driver 1/2” drill bit for drilling pilot holes Bracket for 1pcs 1 ¼” drill bit for drilling electrical wiring body access hole. Bracket for 1pcs Screwdrivers: Philips &...
Page 7
This appliance has been designed for use in both ducted and recirculating modes, follow the appropriate installation method. (For recirculation mode a kit is required – not included. Contact Chambers® to determine if a kit is available for your hood.)
Page 8
7. For models with LED Panel Lighting, do not install the range hood less than 30 inches from the cooking surface (Fig C.) to avoid potential safety hazards. 4. INSTALLATION (EXTERIOR VENTILATION): When the range hood is in operation, the negative pressure in the room must not exceed 4 Pa (4×10 Bar) Drill 3x8mm holes to accommodate the body bracket.
Page 9
Screw Holes on wall (4mm x 30mm) Screw plug Wall bracket Lift the cooker hood and hang it onto the wall bracket hooks. After hanging the hood on the bracket, remove the filters, mark the 2 safety screw holes inside the hood. After marking the holes, remove the hood and drill two holes where you have marked them.
Page 10
4. Fix the one-way-valve (air damper) to the air outlet of the cooker hood. If it hasn’t been factory installed. Then attach the exhaust pipe to the one-way- valve as shown below. Exhaust pipe Cooker hood 5. CHIMNEY INSTALLATION Place the upper chimney into the lower chimney. Before attaching the bracket to the chimney, decide and mark the location of lower chimney bracket screw holes for fixing the lower chimney bracket to the wall.
Page 11
Mark and drill 2 holes to accommodate the upper chimney bracket. Screw and tighten the upper chimney bracket to the wall with 2 screws (ST4x30) and 2 wall plugs. Slide the upper chimney up to the correct height and affix it to the upper chimney bracket via 2 x ST4x8mm screws.
6. INSTALLATION (RECIRCULATING) If you cannot vent your range hood externally, an exhaust pipe is not required. A recirculating kit can be used to clean the air and trap odors. 1. To install the activated carbon filter, the grease filters should be removed first.
7. OPERATION Invisible Touch Controls On/Off button Used for turning the fan On/Off. When plugged in, press this button for 3 seconds and all buttons will light up and the range hood will function. STANDBY MODE When the range hood is first plugged in, the symbol will flash slowly, it is in STANDBY MODE.
8. TEMPERATURE CONTROL INTELLIGENT MODE The default setting for the heat sensor is “ACTIVE” 1. When the heat sensor is in ACTIVE mode you will not need to press any buttons to activate the fan unless you wish to. 2. In ACTIVE mode, when the cooking temperature reaches the high limit threshold, the buzzer will sound, the fan will be turned on at medium speed, and the lights will turn on.
9. MAINTENANCE Before cleaning, switch the unit off and disconnect the electrical supply. I. Regular Cleaning Use a soft cloth moistened with hand-warm mildly soapy water or household cleaning detergent. Never use metal pads, chemical, abrasive material or stiff brush to clean the unit.
10. TROUBLESHOOTING Fault Cause Solution The fan blade is jammed. Lights are on, but Turn off unit. Repair by qualified service the fan does not personnel only. work The motor is damaged. Turn off unit. Repair by qualified service personnel only. Both lights and Light bulb is burnt out.
11. ENVIRONMENTAL PROTECTION Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
This warranty covers parts and labor from a Chambers® authorized company, up to a maximum of one (1) hour. Proof of payment to the service company is required.
Page 19
⚫ Service calls to instruct how to use the appliance ⚫ Expenses for travel and transportation if your appliance is in a remote area where service by an authorized Chambers® servicer is not available. The cost of repair or replacement under these exclusions shall be borne by the customer and agreed to before a servicer is dispatched.
