OWNER'S MANUAL
LED LCD MONITOR
Please read this manual carefully before operating your set and
retain it for future reference.
LED LCD MONITOR MODEL
E1600S
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E1600S and is the answer not in the manual?

Questions and answers

Summary of Contents for LG E1600S

  • Page 1 OWNER’S MANUAL LED LCD MONITOR Please read this manual carefully before operating your set and retain it for future reference. LED LCD MONITOR MODEL E1600S www.lg.com...
  • Page 2: Important Precautions

    Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 3 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
  • Page 4: On Disposal (Only, Hg Lamp Used Lcd Monitor)

    Important Precautions On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.
  • Page 5 Accessories !!! Thank you for selecting LGE products !!! Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. User's Guide/Cards Power Cord (Depending on the country) 15-pin D-Sub Signal Cable (To set it up, this signal cable may be attached to this product before shipping out.)
  • Page 6: Connecting The Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices are turned off. Connecting and Disassembling the stand Place the monitor face down on the soft cloth. Assemble the Stand Base into the Stand Body in the correct direction. Stand Body Stand Base Turn the Stand Base Lock through 90˚...
  • Page 7 Connecting the Display Turn the Stand Base Lock through 90˚ to separate the Stand Base from the Stand Body. <Unlocked> If you can't release the Stand Base even the Locking Knob is at a release position, Please push the indicated knob down and retry it. Locking Knob Pull out the Stand Base to remove.
  • Page 8: Positioning Your Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display -After installation, adjust the angle as shown below. Adjust the position of the panel in various ways for maximum comfort. Tilt Range : -5˚...
  • Page 9: Connecting With The Pc

    Connecting the Display Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable and power cord in order, then tighten the screw of the signal cable.
  • Page 10: Control Panel Functions

    Control Panel Functions Front Panel Controls Button Use this button to enter 4:3 IN WIDE, PHOTO EFFECT menus. For more information, refer to page 13. MENU Button Use this button to enter or exit the On Screen Display. OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed.
  • Page 11: Power Button

    Control Panel Functions Use these buttons to select or adjust functions in the On Buttons Screen Display. Use this function to select optimal image conditions in accordance with the surrounding environment (Brightness, Image type). For more information, refer to page 14. AUTO/SET Use this button to enter a selection in the On Screen Display.
  • Page 12: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls.
  • Page 13: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub-menu Description 4:3 IN WIDE To adjust the image size NORMAL PHOTO To adjust the screen color mode EFFECT GAUSSIAN BLUR SEPIA...
  • Page 14 On Screen Display(OSD) Selection and Adjustment The following OSD screen will appear when you press the button on the front of the monitor. MENU : Exit : Move SET : Select Main menu Description To select the image size of the screen. 4:3 IN WIDE WIDE •...
  • Page 15 On Screen Display(OSD) Selection and Adjustment The following OSD screen will appear when you press the button on the front of the monitor.This feature lets you easily select the best desired image condition optimized to the environment (ambient illumination, image types etc).
  • Page 16 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears.
  • Page 17 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description PICTURE To adjust the brightness of the screen. BRIGHTNESS To adjust the contrast of the screen. CONTRAST Set your own gamma value. : -50 / 0 / 50 GAMMA On the monitor, high gamma values display whitish images and low gamma values display blackish images.
  • Page 18 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description TRACKING HORIZONTAL To move image left and right. To move image up and down. VERTICAL To minimize any vertical bars or CLOCK stripes visible on the screen background. The horizontal screen size will also change.
  • Page 19 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description SETUP LANGUAGE To choose the language in which the control names are displayed. To adjust position of the OSD window POSITION on the screen. WHITE If the output of the video card is different BALANCE the required specifications, the color level may deteriorate due to video signal...
  • Page 20: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the • Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator •...
  • Page 21: Display Image Is Incorrect

    Troubleshooting Display image is incorrect Display Position is • Press the AUTO/SET button to automatically incorrect. adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display.
  • Page 22 • Be sure to install the display driver from the display display driver? driver CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lg.com. • Make sure to check if the video card supports Plug&Play function.
  • Page 23: Specifications

    Specifications Display 39.49 cm (15.6 inch ) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 39.49 cm 0.252 mm x 0.252 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq. 56 Hz to 75 Hz (Automatic) Input Form Separate Sync.
  • Page 24: Preset Modes (Resolution)

    Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 720 x 400 31.468 640 x 480 31.469 640 x 480 37.500 800 x 600 37.879 800 x 600 46.875 832 x 624 49.725 1024 x 768 48.363 1024 x 768 60.123...
  • Page 25: Installing The Wall Mount Plate

    Installing the Wall mount plate This monitor satisfies the specifications of the Wall mount plate or the interchange device. Place the monitor face down on the soft cloth. Turn the Stand Base Lock through 90˚ to separate the Stand Base from the Stand Body.
  • Page 26 Wall mount plate. Please refer to the installation guide for more details, which is provided when Wall mount plate is purchased. LG recommends that wall mounting be performed by a qualified professional installer. Wall Mount pad < Screw Mounting Interface Dimension >...
  • Page 27 Make sure to read the Safety Precautions before using the product. Keep the OWNER’S MANUALCD) in an accessible place for furture reference. The model and serial number of the SET is ENERGY STAR is a set of power-saving located on the back and one side of the SET. guidelines issued by the U.S.Environmental Record it below should you ever need service.
