OWNER'S MANUAL
LED LCD MONITOR
Please read this manual carefully before operating
your set and retain it for future reference.
LED LCD MONITOR MODEL
E1642C
E1942C
E2042C
E2242C
www.lg.com

Advertisement

loading

  Related Manuals for LG E1942C-BN

  Summary of Contents for LG E1942C-BN

  • Page 1 OWNER’S MANUAL LED LCD MONITOR Please read this manual carefully before operating your set and retain it for future reference. LED LCD MONITOR MODEL E1642C E1942C E2042C E2242C www.lg.com...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS CONTENTS ASSEMBLING AND PREPAR- Unpacking Parts and buttons Setting up the Monitor set - Attaching the Stand Base - Detaching the Stand Base - Mounting on a table - Using the cable holder - Mounting on a wall USING THE MONITOR SET Connecting to a PC - D-SUB connection CUSTOMIZING SETTINGS Customizing Settings - Menu Settings - P ICTURE - C OLOR - D ISPLAY - O THERS SUPER ENERGY SAVING Setting PICTURE MODE Setting TROUBLESHOOTING SPECIFICATIONS E1642C...
  • Page 3: Assembling And Preparing

    ASSEMBLING AND PREPARING Unpacking Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories. CD(Owner's Manual) / Card Power Cord ( Depending on the country ) Stand Body CAUTION Do not use any unapproved accessories to ensure the safety and product life span. Any damages or injuries by using unapproved accessories are not covered by the warranty. NOTE The accessories supplied with your product may vary depending on the model. Product specifications or contents in this manual may be changed without prior notice due to upgrade of product functions. ASSEMBLING AND PREPARING D-SUB Cable AC-DC Adapter ( Depending on the country ) Stand Base AC-DC Adapter...
  • Page 4: Parts And Buttons

    ASSEMBLING AND PREPARING Parts and buttons Power Indicator Lighting On: Turned on Lighting Off: Turned off Button (See p.11) Connection panel (See p.9) (Power Button)
  • Page 5: Setting Up The Monitor Set

    Setting up the Monitor set Attaching the Stand Base Place the Monitor set with the screen side down on a flat and cushioned surface. CAUTION Lay a foam mat or soft protective cloth on the surface to protect the screen from damage. Attach the Stand Body to the monitor set. Attach the Stand Base. Tighten the screw to the right with a coin. Stand Body Stand Base ASSEMBLING AND PREPARING Detaching the Stand Base Place the Monitor set with the screen side down on a flat and cushioned surface. Pull out the Stand Body and Stand Base from the monitor set. Turn the screw to the left with a coin. Pull out the Stand Base. Stand Body Stand Base Stand Body Stand Base CAUTION This illustration depicts the general model of connection. Your monitor may differ from the items shown in the picture. Do not carry the product upside down holding only the stand base. The product may fall and get damaged or injure your foot.
  • Page 6: Mounting On A Table

    ASSEMBLING AND PREPARING Mounting on a table Lift and tilt the Monitor set into its upright position on a table. Leave a 10 cm (minimum) space from the wall for proper ventilation. 10 cm 10 cm Connect the AC-DC Adapter and Power Cord to a wall outlet. Press (Power) button on the bottom switch panel to turn the power on. CAUTION Unplug the power cord before moving the Monitor to another location. Otherwise electric shock may occur. 10 cm 10 cm Using the cable holder Cable holder...
  • Page 7 WARNING When you adjust the angle, do not hold the bottom of the Monitor set frame as shown on the following illustration, as may injure your fingers. Do not touch or press the screen when adjusting the angle of the monitor. Do not hold this set like below picture.Monitor screen can detach from stand base and injure your body. NOTE Tilt from +20 to -5 degrees up or down to adjust the angle of the Monitor set to suit your view. Front Rear ASSEMBLING AND PREPARING Using the Kensington security system The Kensington security system connector is located at the back of the Monitor set. For more information of installation and using, refer to the manual supplied with the Kensington security system or visit http://www.kensington.com . Connect the Kensington security system cable between the Monitor set and a table. NOTE The Kensington security system is optional. You can obtain it from most electronics stores.
  • Page 8: Mounting On A Wall

    Setup Guide. 10 cm 10 cm 10 cm If you intend to mount the Monitor set to a wall, attach Wall mounting interface (optional parts) to the back of the set. When you install the Monitor set using a wall mounting interface (optional parts), attach it carefully so it will not drop. Please, Use the screw and wall mount interface in accordance with VESA Standards. If you use screw longer than standard, the monitor might be damaged internally. If you use improper screw, the product might be damaged and drop from mounted position. In this case, LG Electronics is not responsible for it. VESA compatible. Please use VESA standard as below. 784.8 mm (30.9 inch) and under * Wall Mount Pad Thickness : 2.6 mm * Screw : Φ 4.0 mm x Pitch 0.7 mm x Length 10 mm 787.4 mm (31.0 inch) and above * Please use VESA standard wall mount pad and screws. Model VESA (A x B) Standard screw Number of screws CAUTION Disconnect the power cord first, and then 10 cm move or install the Monitor set. Otherwise...
  • Page 9: Using The Monitor Set

    USING THE MONITOR SET Connecting to a PC Your Monitor set supports Plug & Play*. *Plug & Play: A PC recognizes a connected device that users connect to a PC and turn on, without device configuration or user intervention. D-SUB connection Transmits analog video from your PC to the Monitor set. Connect the PC and the Monitor set with the supplied D-sub 15 pin signal cable as shown in the following illustrations. NOTE When using a D-Sub signal input cable connector for Macintosh Mac adapter For Apple Macintosh use, a separate plug adapter is needed to change the 15 pin high density (3 row) D-SUB VGA connector on the supplied cable to a 15 pin 2 row connector. USING THE MONITOR SET...
  • Page 10 USING THE MONITOR SET CAUTION Connect the signal input cable and tighten it by turning the screws clockwise. Do not press the screen with your finger for a long time as this may result in temporary distortion on the screen. Avoid displaying a fixed image on the screen for a long period of time to prevent image burn. Use a screensaver if possible. NOTE When you want to use two PC in our Monitor, please connect the signal cable(D-SUB) respectively in Monitor set. If you turn the Monitor set on while it is cold, the screen may flicker. This is normal. Some red, green, or blue spots may appear on the screen. This is normal. Self Image Setting Function Press the power button on the bottom panel to turn the power on. When monitor power is turned on, the "Self Image Setting" Function is executed automatically. (Only supported in Analog Mode) NOTE "Self Image Setting" Function. This function provides the user with optimal display settings.When the user connects the monitor for the first time, this function automatically adjusts the display to optimal settings for individual input signals.(Only supported in Analog Mode) ‘AUTO’ Function. When you encounter problems such as blurry screen, blurred letters, screen flicker or tilted screen while using the device or after changing screen resolution, press the AUTO function button to improve resolution.
  • Page 11: Customizing Settings

    CUSTOMIZING SETTINGS Press the desired button on the bottom of the Monitor set. Change the value of the menu item by pressing the buttons on the bottom of the Monitor set. To return to the upper menu or set other menu items, use the up arrow ( Select EXIT to leave the OSD menu. Button Accesses the main menus.(See p.12) OSD LOCKED/ UNLOCKED Use this button to enter SUPER ENERGY SAVING menu.For more information.(See p.17) (SUPER ENERGY SAVING) Use this button to enter CUSTOM, TEXT, PHOTO, CINEMA, GAME menus.(See p.18) When adjusting your display settings, always press the AUTO button on the MONITOR SETUP OSD. (Only supported in Analog Mode) The best display mode E1642C / E1942C : 1366 x 768 EXIT Exit the OSD(On Screen Display). Turns the power on or off. (Power Button) Power Indicator CUSTOMIZING SETTINGS ) button. Monitor set Buttons Description This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds. The message "OSD LOCKED" should appear. You can unlock the OSD controls at any time by pushing the MENU button for several seconds. The message "OSD UNLOCKED" should appear. E2042C : 1600 x 900 E2242C : 1920 x 1080 The power indicator stays red if the display is running properly (On Mode). If the display is in Sleep Mode, the power indicator blinks red.
  • Page 12: Customizing Settings Menu Settings

    CUSTOMIZING SETTINGS Customizing Settings Menu Settings Press MENU button on the bottom of the Monitor set to display the MENU OSD. Set the options by pressing the ◄ or ► or ▼ buttons. Select the "NEXT MENU" button to enter the more option settings. Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. Each option is explained below. MENU BRIGHTNESS To adjust the brightness, contrast of the screen CONTRAST WIDE/ORIGINAL WIDE Switch to full screen mode according to input image signal. ORIGINAL Change the input image signal ratio to original. * This function works only if input resolution is lower than Monitor set ratio (16:9). RESET Restore all factory default settings. Press the MENU > NEXT MENU PICTURE SHARPNESS COLOR GAMMA COLOR TEMP DISPLAY HORIZONTAL VERTICAL CLOCK PHASE OTHERS LANGUAGE POWER INDICATOR WHITE BALANCE Analog: D-SUB(Analog signal) input.
  • Page 13: Picture

    PICTURE Press MENU button on the bottom of the Monitor set to display the MENU OSD. Select the "NEXT MENU" button to enter the more option settings. Enter to PICTURE by pressing the ▼ button. Set the options by pressing the ◄ or ► or ▼ buttons. Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. Each option is explained below. MENU > NEXT MENU > PICTURE SHARPNESS Description To adjust the clearness of the screen. CUSTOMIZING SETTINGS...
  • Page 14: Color

    CUSTOMIZING SETTINGS COLOR Press MENU button on the bottom of the Monitor set to display the MENU OSD. Select the "NEXT MENU" button to enter the more option settings. Select COLOR by pressing the ► button. Enter to COLOR by pressing the ▼ button. Set the options by pressing the ◄ or ► or ▼ buttons. Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. Each option is explained below. MENU > NEXT MENU > COLOR GAMMA COLOR TEMP Description Set your own gamma value. : GAMMA 0, GAMMA 1, GAMMA 2 on the monitor, high gamma values display whitish images and low gamma values display blackish images. CUSTOM • RED:Set your own red color levels. • GREEN: Set your own green color levels. • BLUE:Set your own blue color levels. Select the screen color. WARM: Set the screen to warm color temperature (more red). MEDIUM: Set the screen to medium color temperature. COOL: Set the screen to cool color temperature (more blue).
  • Page 15: Display

    DISPLAY Press MENU button on the bottom of the Monitor set to display the MENU OSD. Select the "NEXT MENU" button to enter the more option settings. Select DISPLAY by pressing the ► button. Enter to DISPLAY by pressing the ▼ button. Set the options by pressing the ◄ or ► or ▼ buttons. Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. Each option is explained below. MENU > NEXT MENU > DISPLAY HORIZONTAL VERTICAL CLOCK PHASE Description To move image left and right. To move image up and down. To minimize any vertical bars or stripes visible on the screen background.The horizontal screen size will also change. To adjust the focus of the display. This item allows you to remove any horizontal noise and clear or sharpen the image of characters. CUSTOMIZING SETTINGS...
  • Page 16: Others

    CUSTOMIZING SETTINGS OTHERS Press MENU button on the bottom of the Monitor set to display the MENU OSD. Select the "NEXT MENU" button to enter the more option settings. Select OTHERS by pressing the ► button. Enter to OTHERS by pressing the ▼ button. Set the options by pressing the ◄ or ► or ▼ buttons. Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. Each option is explained below. MENU > NEXT MENU > OTHERS LANGUAGE POWER INDICATOR WHITE BALANCE Description To choose the language in which the control names are displayed. Use this function to set the power indicator on the bottom side of the monitor to ON or OFF.If you set OFF, it will go off. If you set ON at any time, the power indicator will automatically be turned on. If the output of the video card is different the required specifications,the color level may deteriorate due to video signal distortion. Using this function, the signal level is adjusted to fit into the standard output level of the video card in order to provide the optimal image.Activate this function when white and black colors are present in the screen.
  • Page 17: Super Energy Saving Setting

    SUPER ENERGY SAVING Setting Press ( SUPER ENERGY SAVING ) button on the bottom of the Monitor set to display the SUPER ENERGY SAVING OSD. Set the options by pressing the ◄ or ► or ▼ buttons. Select EXIT to leave the OSD menu. Each option is explained below. SUPER ENERGY SAVING Enables SUPER ENERGY SAVING you can save energy with this energy- efficient function Disables SUPER ENERGY SAVING. RESET Resets the values of total energy consumption reduction and CO2 emission reduction estimates. NOTE TOTAL POWER REDUCTION: How much power is saved while using the monitor. TOTAL CO2 REDUCTION: Change the TOTAL POWER REDUCTION to CO2. SAVING DATA(W/h) 396 mm (15.6 inch) SUPER SAVING 4 W/h Saving Data depends on the Panel. So,those values should be different from each panel and panel vendor. LG calculated these values by using “broadcast video signal” (including broadcast video: IEC 62087) SUPER SAVING refers to how much power can be saved using the SUPER ENERGY SAVING function. Description 470 mm 508 mm 546 mm (18.5 inch) (20 inch) (21.5 inch) 4 W/h 5 W/h 6 W/h CUSTOMIZING SETTINGS...
  • Page 18: Picture Mode Setting

    CUSTOMIZING SETTINGS PICTURE MODE Setting Press MODE button on the bottom of the Monitor set to display the PICTURE MODE OSD . Set the options by pressing the ◄ or ► or ▼ buttons. Select EXIT to leave the OSD menu. Each option is explained below. PICTURE MODE CUSTOM It is a mode that the user can adjust each element. It can adjust the color mode of the Main Menu. TEXT It is a mode that the screen is adjusted to the best for the text works. PHOTO It is a mode that the screen is adjusted to the best to view pictures. CINEMA It is a mode that the screen is adjusted to the best to view the videos. GAME It is a mode that the screen is adjusted to the best to play a game. Description...
  • Page 19: Troubleshooting

    TROUBLESHOOTING Check the following before calling for service. No image appears y Check and see if the power cord is connected properly to the power Is the power cord of the display connected? y Press the Power button. Is the power indicator light on? Is the power on and the power y Adjust the brightness and the contrast. indicator Red? Is the power indicator flickering? y If the display is in power saving mode, try moving the mouse or y Try to turn on the PC. Do you see an "OUT OF RANGE" y This message appears when the signal from the PC (video card) is message on the screen? y When the monitor is on "No-Signal" in 5 minutes, the monitor goes to Do you see a "NO SIGNAL" message on the screen? Do you see a "OSD LOCKED" message on the screen? y You can secure the current control settings, so that they cannot be Do you see “OSD LOCKED” when you push MENU button? Display image is incorrect y Press the AUTO button to automatically adjust your display image to Display Position is incorrect. y Press the AUTO button to automatically adjust your display image to On the screen background, vertical bars or stripes are visible. y Press the AUTO button to automatically adjust your display image to Any horizontal noise appearing in any image or characters are not...
  • Page 20 TROUBLESHOOTING CAUTION Check Control Panel ► Display ► Settings and see if the frequency or the resolution were changed. If yes, readjust the video card to the recommend resolution. If the recommended resolution (optimal resolution) is not selected, letters may be blurred and the screen may be dimmed, truncated or biased. Make sure to select the recommend resolution. The setting method can differ by computer and O/S (Operation System), and resolution mentioned above may not be supported by the video card performance. In this case, please ask to the computer or the video card manufacturer. Display image is incorrect The screen color is mono or y Check if the signal cable is properly connected and use a screwdriver abnormal. y Make sure the video card is properly inserted in the slot. y Set the color setting higher than 24 bits (true color) at Control Panel y Check if the screen is set to interlace mode and if yes, change it to the The screen blinks. Do you see an "Unrecognized monitor, Plug&Play (VESA DDC) monitor found" message? Have you installed the display y Be sure to install the display driver from the display driver CD (or driver? y Make sure to check if the video card supports Plug&Play function. to fasten if necessary. ► Settings. recommend resolution. diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lg.com.
  • Page 21: Specifications

    SPECIFICATIONS E1642C Display Screen Type Pixel Pitch Sync Input Horizontal Frequency Vertical Frequency Input Form Video Input Signal Input Input Form Resolution Recommend Plug & Play DDC 2B(Analog) Power On Mode : 15 W(Typ.) Consumption Sleep Mode ≤ 0.3 W Off Mode ≤ 0.3 W Power Input 19 V 1.2 A AC-DC Adapter Type ADS-40SG-19-3 19032G, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19032GPG-1, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19032GPBR-1, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19032GPI-1,manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19032GPCU-1, manufactured by SHENZHEN HONOR ELECTRONIC or Type LCAP21A, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26A-A, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26A-E, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26A-I, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26A-B, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE OUTPUT: 19 V Dimensions With Stand (Width x Height x Without Stand Depth) Weight 1.2 kg...
  • Page 22: E1942C

    SPECIFICATIONS S PECIFICATIONS E1942C Display Screen Type Pixel Pitch Sync Input Horizontal Frequency Vertical Frequency Input Form Video Input Signal Input Input Form Resolution Recommend Plug & Play DDC 2B(Analog) Power On Mode : 15 W(Typ.) Consumption Sleep Mode ≤ 0.3 W Off Mode ≤ 0.3 W Power Input 19 V 1.2 A AC-DC Adapter Type ADS-40SG-19-3 19025G, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19025GPG-1, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19025GPBR-1, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19025GPI-1,manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19025GPCU-1, manufactured by SHENZHEN HONOR ELECTRONIC or Type LCAP21, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26-A, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26-E, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26-I, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26-B, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE OUTPUT: 19 V Dimensions With Stand (Width x Height x Without Stand Depth)
  • Page 23: E2042C

    S PECIFICATIONS E2042C Display Screen Type Pixel Pitch Sync Input Horizontal Frequency Vertical Frequency Input Form Video Input Signal Input Input Form Resolution Recommend Plug & Play DDC 2B(Analog) Power On Mode : 20 W(Typ.) Consumption Sleep Mode ≤ 0.3 W Off Mode ≤ 0.3 W Power Input 19 V 1.2 A AC-DC Adapter Type ADS-40SG-19-3 19025G, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19025GPG-1, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19025GPBR-1, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19025GPI-1,manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19025GPCU-1, manufactured by SHENZHEN HONOR ELECTRONIC or Type LCAP21, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26-A, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26-E, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26-I, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26-B, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE OUTPUT: 19 V Dimensions With Stand (Width x Height x Without Stand Depth) Weight...
  • Page 24: E2242C

    SPECIFICATIONS S PECIFICATIONS E2242C Display Screen Type Pixel Pitch Sync Input Horizontal Frequency Vertical Frequency Input Form Video Input Signal Input Input Form Resolution Recommend Plug & Play DDC 2B(Analog) Power On Mode : 23 W(Typ.) Consumption Sleep Mode ≤ 0.3 W Off Mode ≤ 0.3 W Power Input 19 V 1.2 A AC-DC Adapter Type ADS-40SG-19-3 19025G, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19025GPG-1, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19025GPBR-1, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19025GPI-1,manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-40FSG-19 19025GPCU-1, manufactured by SHENZHEN HONOR ELECTRONIC or Type LCAP21, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26-A, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26-E, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26-I, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE or Type LCAP26-B, manufactured by LIEN CHANG ELECTRONIC ENTERPRISE OUTPUT: 19 V Dimensions With Stand (Width x Height x Without Stand Depth)
  • Page 25: Preset Modes (Resolution)

    Preset Modes (Resolution) E1642C Horizontal Display Modes (Resolution) Frequency(kHz) 640 x 480 31.5 800 x 600 35.2 800 x 600 37.9 1024 x 768 48.363 1280 x 720 1366 x 768 E1942C Horizontal Display Modes (Resolution) Frequency(kHz) 720 x 400 31.468 640 x 480 31.469 640 x 480 37.500 800 x 600 37.879 800 x 600 46.875 832 x 624 49.725 1024 x 768 48.363 1024 x 768 60.123 1366 x 768 47.712 E2042C Horizontal Display Modes (Resolution) Frequency(kHz) 720 x 400 31.468...
  • Page 26: Indicator

    SPECIFICATIONS Preset Modes (Resolution) E2242C Horizontal Display Modes (Resolution) Frequency(kHz) 720 x 400 31.468 640 x 480 31.469 640 x 480 37.500 800 x 600 37.879 800 x 600 46.875 1024 x 768 48.363 1024 x 768 60.023 1152 x 864 67.500 1280 x 1024 63.981 1280 x 1024 79.976 1680 x 1050 65.290 1920 x 1080 67.500 Indicator Mode LED Color On Mode Sleep Mode Blinking Red Off Mode Vertical Polarity(H/V) Frequency(Hz) Recommend Mode...
  • Page 27: Proper Posture

    PROPER POSTURE Proper posture for using the Monitor set. Adjust the Monitor set and your posture to allow you to view images at the optimal viewing angle. Place your hands gently on the keyboard, keeping your arms bent at the elbows and horizontally outright. PROPER POSTURE Adjust the location of the Monitor set to avoid it reflecting light.
  • Page 28 Make sure to read the Safety Precautions before using the product. Keep the Owner’s Manual (CD) in an accessible place for future reference. The model and serial number of the SET is located on the back and one side of the SET. Record it below should you ever need service.
