LG E1940S Owner's Manual

Lg led lcd monitor. e40 series
Hide thumbs

Advertisement

OWNER'S MANUAL

LCD MONITOR

Please read this manual carefully before operating
your set and retain it for future reference.
LCD MONITOR MODELS
E1940S/E1940T
E2040S/E2040T
E2240S/E2240T
E2340S/E2340T
www.lg.com

Advertisement

loading

  Also See for LG E1940S

  Related Manuals for LG E1940S

  Summary of Contents for LG E1940S

  • Page 1: Lcd Monitor

    OWNER’S MANUAL LCD MONITOR Please read this manual carefully before operating your set and retain it for future reference. LCD MONITOR MODELS E1940S/E1940T E2040S/E2040T E2240S/E2240T E2340S/E2340T www.lg.com...
  • Page 2: Important Precautions

    Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 3 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
  • Page 4: On Cleaning

    Important Precautions On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.
  • Page 5 Accessories !!! Thank for selecting LGE products !!! Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. User's Guide/Cards Power Cord (Depending on the country) DVI-D Signal Cable (This feature is not available in all countries.) NOTE This accessories may look different from those shown here.
  • Page 6: Connecting The Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connecting the stand Place the monitor with its front facing downward on a soft cloth. Check the direction of the Stand Base, and connect it into the Stand Body.
  • Page 7: Disassembling The Stand

    Connecting the Display Disassembling the stand Place the monitor with its front facing downward on a soft cloth. Nip Latch inside, Take off the stand base from stand body. When you desire to disintegrate the monitor from the stand base, use a coin to turn the screw counterclockwise.
  • Page 8: Positioning Your Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display -After installation, adjust the angle as shown below. Adjust the position of the panel in various ways for maximum comfort. Tilt Range : -5˚...
  • Page 9: Connecting With The Pc

    Connecting the Display Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable of the signal cable. Connect DVI-D(Digital signal) Cable Connect D-sub(Analog signal) Cable NOTE This is a simplified representation of the rear view.
  • Page 10 ‘AUTO’ Function? When you encounter problems such as blurry screen, blurred letters, screen flicker or tilted screen while using the device or after changing screen resolution, press the AUTO function button to improve resolution. E1940S/E2040S/E2240S/E2340S and power cord in order, then tighten the screw...
  • Page 11: Front Panel Controls

    Control Panel Functions Front Panel Controls MENU Button MODE Button E1940T/E2040T/E2240T/E2340T OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds. The message "OSD LOCKED" should appear. You can unlock the OSD controls at any time by pushing the MENU button for several seconds.
  • Page 12: Auto Image Adjustment

    Control Panel Functions AUTO Button INPUT Button (SOURCE Hot key) EXIT Button Power Button & Power Indicator AUTO IMAGE ADJUSTMENT When adjusting your display settings, always press the AUTO button before entering the On Screen Display(OSD). (Only Analog Mode) This will automatically adjust your display image to the ideal settings for the current screen resolution size (display mode).
  • Page 13 Control Panel Functions Front Panel Controls MENU Button MODE Button E1940S/E2040S/E2240S/E2340S OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds. The message "OSD LOCKED" should appear.
  • Page 14 This will automatically adjust your display image to the ideal settings for the current screen resolution size (display mode). The best display mode is E1940S : 1360 x 768 E2040S : 1600 x 900 E2240S/E2340S : 1920 x1080 Exit the OSD(On Screen Display).
  • Page 15: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls.
  • Page 16 Press the discretionary Button, then the main menu of the OSD appears. To access a control, use the corresponding Buttons. Use the Use the Press the EXIT Button to exit from the OSD. Buttons to adjust the image to the desired level. Button to select other sub-menu items. E1940S/E2040S/E2240S/E2340S...
  • Page 17: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu PICTURE BRIGHTNESS CONTRAST SHARPNESS COLOR COLOR TEMP (PRESET / USER) GAMMA HORIZONTAL DISPLAY VERTICAL CLOCK PHASE LANGUAGE OTHERS POWER INDICATOR WHITE BALANCE FACTORY RESET...
  • Page 18 Press the MENU Button, then the main menu of the OSD appears. Menu Name Icons NOTE OSD (On Screen Display) menu languages on the monitor may differ from the manual. E1940T/E2040T/E2240T/E2340T Exit Adjust (Decrease/Increase) Select another sub-menu Restart to select sub-menu E1940S/E2040S/E2240S/E2340S Sub- menus Button...
  • Page 19: Color Temp

    On Screen Display(OSD) Selection and Adjustment Main menu E1940T/E2040T/E2240T/E2340T E1940S/E2040S/E2240S/E2340S Exit : Exit : Decrease : Increase : Select another sub-menu : Restart to select sub-menu Exit : Exit : Decrease : Increase : Select another sub-menu : Restart to select sub-menu...
  • Page 20 On Screen Display(OSD) Selection and Adjustment Main menu E1940T/E2040T/E2240T/E2340T E1940S/E2040S/E2240S/E2340S Exit : Exit : Decrease : Increase : Select another sub-menu : Restart to select sub-menu Sub menu Description HORIZONTAL To move image left and right. To move image up and down.
  • Page 21 On Screen Display(OSD) Selection and Adjustment Main menu E1940T/E2040T/E2240T/E2340T E1940S/E2040S/E2240S/E2340S Exit : Exit : Decrease : Increase : Select another sub-menu : Restart to select sub-menu NOTE If this does not improve the screen image, restore the factory default settings. If necessary, execute the WHITE BALANCE function again.
  • Page 22 Press the MODE Button, then the main menu of the OSD appears. Menu Name Icons NOTE OSD (On Screen Display) menu languages on the monitor may differ from the manual. E1940T/E2040T/E2240T/E2340T Exit Adjust (Decrease/Increase) Select another sub-menu Restart to select sub-menu E1940S/E2040S/E2240S/E2340S Sub- menus Button...
  • Page 23 On Screen Display(OSD) Selection and Adjustment Main menu Exit : Exit : Move : Restart to select sub-menu Sub menu Description NORMAL Select this when you want to use the product in the most general using environment. MOVIE Select this when you are watching a video or movie.
  • Page 24 On Screen Display(OSD) Selection and Adjustment Main menu Exit : Exit : Move : Restart to select sub-menu Sub menu Description WIDE Switch to full screen mode according to input image signal. Change the input image signal ratio to ORIGINAL original.
  • Page 25 On Screen Display(OSD) Selection and Adjustment Main menu Exit : Exit : Move : Restart to select sub-menu Sub menu Description NORMAL The PhotoEffect function is disabled. GAUSSIAN This menu changes the screen to be more colorful and smoother. BLUR SEPIA This menu changes the screen to be Sepia tone (brown color).
  • Page 26: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the display connected? Is the power indicator light on? Is the power indicator blinking? Do you see an "OUT OF RANGE" message on the screen? Do you see a "CHECK SIGNAL CABLE"...
  • Page 27: Display Image Is Incorrect

    Troubleshooting Display image is incorrect Display Position is incorrect. On the screen background, vertical bars or stripes are visible. Any horizontal noise appearing in any image or characters are not clearly portrayed. IMPORTANT Check Control Panel --> Display --> Settings and see if the frequency or the resolution were changed.
  • Page 28 Troubleshooting Display image is incorrect The screen color is mono or abnormal. The screen blinks. Do you see an "Unrecognized monitor, Plug&Play (VESA DDC) monitor found" message? Have you installed the display driver? • Check if the signal cable is properly connected and use a screwdriver to fasten if necessary.
  • Page 29: Specifications

    Specifications Display 47.0 cm (18.5 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 47.0 cm 0.300 mm x 0.300 mm (Pixel pitch) Horizontal Freq. Sync Input Vertical Freq. Input Form Signal Input Video Input Input Form Resolution Recommend Plug&Play...
  • Page 30 2.4 kg (5.29 lb) 2.0 A Temperature 10 ˚C to 35 ˚C Humidity 10 % to 80 % non-Condensing Temperature -20 ˚C to 60 ˚C Humidity 5 % to 90 % non-Condensing ), Detached ( O ) E1940S 4.3 cm (1.69 inch)
  • Page 31 Specifications Display 50.8 cm (20.0 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 50.8 cm 0.2766 mm x 0.2766 mm (Pixel pitch) Horizontal Freq. Sync Input Vertical Freq. Input Form Signal Input Video Input Input Form Resolution Recommend Plug&Play...
  • Page 32 Specifications Display 50.8 cm (20.0 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 50.8 cm 0.2766 mm x 0.2766 mm (Pixel pitch) Horizontal Freq. Sync Input Vertical Freq. Input Form Signal Input Video Input Input Form Resolution Recommend Plug&Play...
  • Page 33 Specifications Display 54.6 cm (21.5 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 54.6 cm 0.248 mm x 0.248 mm (Pixel pitch) Horizontal Freq. Sync Input Vertical Freq. Input Form Signal Input Video Input Input Form Resolution Recommend Plug&Play...
  • Page 34 Specifications Display 54.6 cm (21.5 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 54.6 cm 0.248 mm x 0.248 mm (Pixel pitch) Horizontal Freq. Sync Input Vertical Freq. Input Form Signal Input Video Input Input Form Resolution Recommend Plug&Play...
  • Page 35 Specifications Display 58.4 cm (23 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 58.4 cm 0.266 mm x 0.266 mm (Pixel pitch) Horizontal Freq. Sync Input Vertical Freq. Input Form Signal Input Video Input Input Form Resolution Recommend Plug&Play...
  • Page 36 Specifications Display 58.4 cm (23 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 58.4 cm 0.266 mm x 0.266 mm (Pixel pitch) Horizontal Freq. Sync Input Vertical Freq. Input Form Signal Input Video Input Input Form Resolution Recommend Plug&Play...
  • Page 37 Specifications Preset Modes (Resolution) E1940T/E1940S Display Modes (Resolution) 720 x 400 640 x 480 640 x 480 800 x 600 800 x 600 832 x 624 1024 x 768 1024 x 768 1360 x 768 E2040T/E2040S Display Modes (Resolution) 720 x 400...
  • Page 38 Specifications E2240T/E2340T/E2240S/E2340S Display Modes (Resolution) 720 x 400 640 x 480 640 x 480 800 x 600 800 x 600 1024 x 768 1024 x 768 1152 x 864 1280 x 1024 1280 x 1024 1680 x 1050 1920 x 1080 Indicator MODE On Mode...
  • Page 39 Make sure to read the Important Precautions before using the product. Ke e p t h e O w n e r ’ s M a n u a l (C D ) i n a n accessible place for future reference. The model and serial number of the SET is located on the back and one side of the SET.
