OWNER'S MANUAL
LCD MONITOR
Please read this manual carefully before operating your set and
retain it for future reference.
LCD MONITOR MODEL
E1910T
E2210T
E1910S
E2210S
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E2210S and is the answer not in the manual?

Questions and answers

Related Manuals for LG E2210S

Summary of Contents for LG E2210S

  • Page 1 OWNER’S MANUAL LCD MONITOR Please read this manual carefully before operating your set and retain it for future reference. LCD MONITOR MODEL E1910T E2210T E1910S E2210S www.lg.com...

  • Page 2: Important Precautions

    Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 3 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
  • Page 4 Important Precautions On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.
  • Page 5 Accessories !!! Thank for selecting LGE products !!! Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Power Cord User's Guide/Cards 15-pin D-Sub Signal Cable DVI-D Signal Cable (To set it up, this signal cable may be (This feature is not available in all attached to this product before countries.)

  • Page 6: Connecting The Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connecting the stand Place the monitor with its front facing downward on a soft cloth. Assemble the Stand Body into the Assemble the Stand Base(Front, product in the correct direction as shown in...

  • Page 7: Disassembling The Stand

    Connecting the Display Disassembling the stand Place the monitor face Down on the Put a cushion or soft cloth on aflat cushion or soft cloth. surface. Change your lock on the product as it follows and turn it in the arrow direction. If you can't release the stand base even the locking knob is at a release position, Please push the indicated knob down and retry it.
  • Page 8 Connecting the Display Pull out the Stand to remove. Pushing the PUSH button, Take the stand body from hinge body. Good Position Bad Position Warning: You can hurt your finger.

  • Page 9: Positioning Your Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display -After installation, adjust the angle as shown below. Adjust the position of the panel in various ways for maximum comfort. Tilt Range : -5˚...

  • Page 10: Connecting With The Pc

    Connecting the Display E1910T/E2210T Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable and power cord in order, then tighten the screw of the signal cable.
  • Page 11 Connecting the Display E1910S/E2210S Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable and power cord in order, then tighten the screw of the signal cable.

  • Page 12: Control Panel Functions

    Control Panel Functions Front Panel Controls E1910T/E2210T E1910S/E2210S MENU Button OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds. The message "OSD LOCKED" should appear.
  • Page 13 (display mode). The best display mode is E1910T/E1910S : 1280 x 1024 E2210T/E2210S : 1680 x 1050 When two input signals are connected, you can select the INPUT Button input signal (D-SUB/DVI) you want. When only one signal (SOURCE Hot key) is connected, it is automatically detected.

  • Page 14: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls.

  • Page 15: On Screen Display(Osd) Selection And Adjustment

    MOVIE image settings INTERNET ORIGINAL WIDE DSUB To adjust the image size DVI-D RATIO ORIGINAL (Only E2210T /E2210S) PHOTO NORMAL DSUB To adjust screen color mode EFFECT DVI-D GAUSSIAN BLUR SEPIA MONOCHROME NOTE The order of icons may differ depending on the model (14~23).
  • Page 16 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears.
  • Page 17 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description To adjust the brightness of the screen. BRIGHTNESS To adjust the contrast of the screen. CONTRAST SHARPNESS To adjust the clearness of the screen. Exit : Exit : Decrease : Increase : Select another sub-menu : Restart to select sub-menu...
  • Page 18 CLOCK stripes visible on the screen background. The horizontal screen size will also change. E1910S/E2210S To adjust the focus of the display. PHASE This item allows you to remove any horizontal noise and clear or sharpen the image of characters.
  • Page 19 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description To choose the language in which the LANGUAGE control names are displayed. Use this function to set the power POWER indicator on the front side of the monitor INDICATOR to ON or OFF.
  • Page 20 OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MODE Button, then the main menu of the OSD appears. Menu Name E1910T/E1910S E2210T/E2210S Sub-menus Sub-menus Icons Icons...
  • Page 21 When F-ENGINE is not NORMAL,CONTRAST can not be selected. E1910T/E1910S NORMAL Select this when you want to use the product in the most general using environment. E2210T/E2210S E1910T/E1910S MOVIE Select this when you are watching a video or movie. E2210T/E2210S...
  • Page 22 On Screen Display(OSD) Selection and Adjustment (Only E2210T/E2210S) Main menu Sub menu Description WIDE Switch to full screen mode according to input image signal. ORIGINAL Change the input image signal ratio to original. * This function works only if input resolution is lower than monitor ratio (16:10).
  • Page 23 NORMAL and CONTRAST can be selected now. PHOTO EFFECT and F-ENGINE should not be unnormal at the same time. E1910T/E1910S NORMAL The Photo Effect function is disabled. E2210T/E2210S E1910T/E1910S GAUSSIAN This menu changes the screen to be more colorful and smoother.
  • Page 24 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description E1910T/E1910S SEPIA This menu changes the screen to be Sepia tone (brown color). E2210T/E2210S E1910T/E1910S MONOCH This menu changed the screen to be Gray tone(black-and-white Picture) . -ROME E2210T/E2210S Exit : Exit...

  • Page 25: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the ● • Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator •...

  • Page 26: Display Image Is Incorrect

    Troubleshooting Display image is incorrect Display Position is ● • Press the AUTO button to automatically adjust incorrect. your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display.
  • Page 27 • Be sure to install the display driver from the display display driver? driver CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lg.com. • Make sure to check if the video card supports Plug&Play function.

  • Page 28: Specifications

    Specifications E1910T Display 48.2 cm (19 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 48.2 cm 0.294 x 0.294 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq. 56 Hz to 75 Hz (Automatic) Input Form Separate Sync.
  • Page 29 Specifications E1910S Display 48.2 cm (19 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 48.2 cm 0.294 x 0.294 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq. 56 Hz to 75 Hz (Automatic) Input Form Separate Sync.
  • Page 30 Specifications E2210T Display 55.8 cm (22 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 55.8 cm 0.282 x 0.282 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq. 56 Hz to 75 Hz (Automatic) Input Form Separate Sync.
  • Page 31 Specifications E2210S Display 55.8 cm (22 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 55.8 cm 0.282 x 0.282 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq. 56 Hz to 75 Hz (Automatic) Input Form Separate Sync.

  • Page 32: Preset Modes (Resolution)

    60.123 1024 x 768 67.500 1152 x 864 63.981 1280 x 1024 79.976 1280 x 1024 *Recommend Mode E2210T/E2210S Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.468 720 x 400 31.469 640 x 480 37.500 640 x 480 37.879...

  • Page 33: Installing The Wall Mount Plate

    Installing the Wall mount plate This monitor satisfies the specifications of the Wall mount plate or the interchange device. Place the monitor with its front facing downward on a soft cloth. Separate the stand by pushing the PUSH button. Good Position Bad Position Warning: You can hurt your finger.
  • Page 34 Installing the Wall mount plate Install the Wall mount plate. Wall mount plate(Separate purchase) This is stand-type or wall mount type and is connectable with Wall mount plate. Please refer to the installation guide for more details, which is provided when Wall mount plate is purchased.
  • Page 35 Make sure to read the Safety Precautions before using the product. Keep the OWNER’S MANUAL(CD) in an accessible place for furture reference. The model and serial number of the SET is ENERGY STAR is a set of power-saving located on the back or one side of the SET. guidelines issued by the U.S.Environmental Record it below should you ever need service.
