Channel Vision Central C-0315 Specifications

C-0315 15dB RF Amplifier
Description
Channel Vision's 15dB power injected inline amplifier provides the lowest induced noise figure available and is
designed with the future in mind. Unlike other RF amplifiers, the C-0315 features a bi-directional return path for
Standard Wiring Layout
12VDC IN RF INPUT
Channel Vision
MULTI-ROOM AUDIO VIDEO TECHNOLOGY
CVT-15PIA C-0315
5-42MHz RETURN PATH PASS
54-1000MHz FORWARD PATH
3dB LOW NOISE AMPLIFIER
15dB GAIN
OUT-PWR
Layout with Power Injector
12VDC IN RF INPUT
Channel Vision
MULTI-ROOM AUDIO VIDEO TECHNOLOGY
C-0315
CVT-15PIA
5-42MHz RETURN PATH PASS
54-1000MHz FORWARD PATH
3dB LOW NOISE AMPLIFIER
15dB GAIN
OUT-PWR
HS-3
CVT-PI
880
DC Blocker
Instructions
Step 1: Mount amplifier.
Step 2: Connect cable or antenna signal to the INPUT jack.
Step 3: Connect OUTPUT jack to distribute signal to all the TV's in the house.
Step 4: Connect power to 12VDC input, or use PIA (power injector) for remote power capability. Note: must use
DC passive splitters.
Please Note:
The unused trunk line connector of the last outlet device in each trunk line MUST BE TERMINATED using a
75Ω terminator (model 2101).

Specifications

Parameter
Gain
Cable or
Antenna
Flatness
Insertion Loss
Return Loss IN
Return loss OUT
Cable or
Antenna
Tap - Tap Isolation
2nd Order Input Intercept
3rd order input intercept
Composite Second Order
Composite Triple Beat
Noise Figure
Hum Modulation
Return Path Level
RFI Isolation
To prevent fire or shock hazard, do not expose this appliance to rain or moisture
234 F A
ISCHER VENUE
(714) 424-6500 (800) 840-0288
http://www.channelvision.com
Condition
f=54MHz
f=1000MHz
54-1000MHz
5-40MHz
5-40MHz
54-750MHz
750-1000MHz
5-40MHz
54-750MHz
750-1000MHz
54-1000MHz
-
-
-
-
54-60MHz
60-750MHz
750-1000MHz
-
5-27MHz
27-40MHz
5-1000MHz
Warning
C M , CA 92626
OSTA ESA
(714) 424-6510
FAX
e-mail: sales@channelvision.com
Min Typ Max
13.5 14.5 15.5
14.0 15.5 17.0
- +/-0.8 -
-1.5 - -0.5
- -18 -14
- -20 -16
- -16 -14
- -18 -14
- -20 -16
- -16 -14
- - -
80 - -
60 - -
- - -60
- -70 -60
- 3 3.5
- 2.4 3.0
- 3 4.0
- - -70
- - 60
- - 40
- - -130
