- Page 1 Model: B156-002-DVI Product Features System Requirements Package Contents Mounting Instructions Installation Instructions Troubleshooting Warranty & Product Registration 7 1111 W. 35th Street, Chicago, IL 60609 • www.tripplite.com/support Copyright © 2014 Tripp Lite. All rights reserved. 14-08-005-93-3358.indd 1 8/11/2014 10:33:35 AM...
- Page 2 Product Features • Display the same image on both monitors, extend the desktop across them, or display in video wall mode, where both monitors are combined to display one image* • DisplayPort v1.2 compliant* • Supports computer video resolutions up to 1920 x 1200, HD video resolutions up to 1080p @ 60 Hz • Supports up to 48-bit Deep Color (16 bits per channel) • Supports HDCP , EDID and DDC...
- Page 3 Package Contents • B156-002-DVI Splitter • Mounting Hardware • External Power Supply (Input: 100-240V, 50/60 Hz, 0.5A; Output: 5V, 2A) • Owner’s Manual Optional Accessories: • P583-Series Mini DisplayPort to DisplayPort Cables • P561-Series DVI-D Single Link Cables Mounting Instructions The B156-002-DVI comes with mounting hardware that allows it to be mounted in a variety of ways.
- Page 4 Installation Instructions UP TO 35 ft. (10.6 m) Source UP TO 6 ft. (1.8 m) B156-002-DVI Notes: 1. Prior to installation, make sure that your graphics driver is up-to-date by installing the latest driver available. 2. DisplayPort splitter is backward compatible with most DisplayPort 1.1a equipment running current graphics drivers, with the feature set being limited to that of your equipment (e.g.
- Page 5 Installation Instructions Connect the included external power supply to the splitter, and plug it into a Tripp Lite Surge Suppressor, Power Distribution Unit (PDU), or Uninterruptible Power Supply (UPS). The Green Power LED on the splitter will illuminate to indicate the unit is receiving power.
- Page 6 It is recommended that you use the Tripp Lite cables shown in the Optional Accessories listing in this manual, as they have been tested to work with the B156- Series Splitters.
- Page 7 1-Year Limited Warranty TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products.
- Page 8 1111 W. 35th Street, Chicago, IL 60609 • www.tripplite.com/support 14-08-005 • 93-3358_revB 14-08-005-93-3358.indd 8 8/11/2014 10:33:37 AM...
