Summary of Contents for Tripp Lite DisplayPort B156-002

  • Page 1 Splitter/Expander Model: B156-002 Product Features System Requirements Package Contents Mounting Instructions Installation Instructions Troubleshooting Warranty & Product Registration 1111 W. 35th Street, Chicago, IL 60609 • www.tripplite.com/support Copyright © 2014 Tripp Lite. All rights reserved. 14-07-262-933310.indd 1 8/12/2014 9:49:29 AM...
  • Page 2 Product Features • Split or expand a DisplayPort signal on two DisplayPort monitors • DisplayPort v1.2 compliant* • Supports video resolutions up to 4K UHD, 3840 x 2160 @ 60Hz • Supports up to 48-bit Deep Color (16 bits per channel) • Supports HDCP , EDID and DDC • Locate a monitor up to 25 ft.
  • Page 3 Package Contents • B156-002 Splitter • Mounting Hardware • External Power Supply (Input: 100-240V, 50/60Hz, 0.5A; Output: 5V, 2A) • Owner’s Manual Optional Accessories: • P583-Series Mini DisplayPort to DisplayPort Cables • P580-Series DisplayPort Cables Mounting Instructions The B156-002 comes with mounting hardware that allows it to be mounted in a variety of ways.
  • Page 4 Installation Instructions UP TO 25 ft. (7.6m) Source UP TO 6 ft. (1.8m) B156-002 Notes: 1. Prior to installation, make sure that your graphics driver is up-to-date by installing the latest driver available. 2. DisplayPort splitter is backward compatible with most DisplayPort 1.1a equipment running current graphics drivers, with the feature set being limited to that of your equipment (e.g.
  • Page 5 Connect the included external power supply to the splitter, and plug it into a Tripp Lite Surge Suppressor, Power Distribution Unit (PDU), or Uninterruptible Power Supply (UPS). The Green Power LED on the splitter will illuminate to indicate the unit is receiving power.
  • Page 6 It is recommended that you use the Tripp Lite cables shown in the Optional Accessories listing in this manual, as they have been tested to work with the B156- Series Splitters.
  • Page 7 Warranty & Product Registration 1-Year Limited Warranty TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center.
  • Page 8 Do not use this equipment in the presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide. Tripp Lite follows a policy of continuous improvement. Product specifications are subject to change without notice.
