REFRIGERATOR FEATURES

Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.

Glass Shelves

Remove and Replace the Shelf
1. Lift the front of the shelf up and away from the ledge on the
front of the shelf support.
2. Pull the shelf forward and lift it up and out of the shelf
supports.
3. Replace the shelf by inserting the back edge of the shelf
against the rear support in the back of the compartment.
4. Align the front of the shelf to the ledge on the front of the shelf
support.
5. Gently place the shelf into place.

DOOR FEATURES

Door Bin

Your refrigerator has two door bin locations for maximum storage
capacity.
Reposition the Door Bin
1. Remove the door bin by tilting it forward and pulling it out.
2. Replace the bin by placing the rear of the bin under the
support on the door and sliding into place.
8 8 8 8 8 8

Lighting the Refrigerator

The refrigerator has an interior light that comes on any time the
door is opened.
NOTE: The light is an LED which does not need to be replaced. If
the LED does not illuminate when the door is opened, call Service
to replace the light. See Assistance or Service for contact
information.

REFRIGERATOR CARE

Base Grille

You must remove the base grille to access the condenser coils
for cleaning.
To Remove the Base Grille:
1. Open the refrigerator door.
2. Using a Phillips screwdriver, remove the two screws.
3. Push both tabs in toward the center to release the base grille
from the cabinet and remove.
A
To Replace the Base Grille:
1. Open the refrigerator door.
Position the base grille so that both tabs align and snap the base
grille into place. Replace the two screws. Tighten the screws.

Cleaning

WARNING
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.
Clean the refrigerator about once a month to avoid buildup of
odors. Wipe up spills immediately.
To Clean Your Refrigerator:
1. Unplug refrigerator or disconnect power.
2. Remove all removable parts from inside, such as shelves, etc.
B A
A. Tabs
B. Screws
