1
0G7859
1
ENGINE 3.0L G3 LS (RWD) MAKE
2
0F8425
1
ADAPTER ENGINE
3
0F9965C
1
FLEX PLATE 2 POLE
4
0F8931
1
SPACER FLEX PLATE
5
0G7461
1
STARTER MOTOR 12V
6
049821
3
SCREW SHC M8-1.25 X 30 G12.9
7
022129
17
WASHER LOCK M8-5/16
8
022145
13
WASHER FLAT 5/16-M8 ZINC
9
025507
5
WASHER SHAKEPROOF EXT 7/16 STL
10
064416
7
SCREW HHC M10-1.5 X 45 G8.8 FT
11
052243
1
SCREW HHC M10-1.5 X 60 G8.8
12
022131
9
WASHER FLAT 3/8-M10 ZINC
13
0D5417
8
SCREW HHC M10-1.0 X 25 G10.9
14
0F3844
8
WASHER FLAT .45 X 1.00
15
046526
5
WASHER LOCK M10
16
045772
4
NUT HEX M10-1.5 G8 YEL CHR
17
043107
5
SCREW HHC M8-1.25 X 25 G8.8
18
0G3638
1
ADAPTER OIL FILTER 3.0L
19
0D5419
1
OIL FILTER
20
055476
1
BSHG RDCR HEX 3/8 TO 1/8 GALV
21
0A8584
1
SWITCH OIL PRESSURE 10 PSI 2 POL
22
0G3775
1
DIP STICK OIL 3.0L
23
0G0100
2 (REF)
GASKET EXHAUST
24
0F8795A
1
MANIFOLD EXHAUST LH
25
067989
12
NUT HEX FL WHIZ M8-1.25
26
0E7202AAS0R
2
HEAT SHIELD EXHAUST 3.0L
27
0F5966A
2
REFLECTIVE HEAT SHIELD 3.0L
28
022985
6
WASHER FLAT #6 ZINC
29
033472
6
RIVET POP .125 X .400 AL
30
085296
6
SCREW HHC 1/4-20 X 1/2 SS
31
083896
6
WASHER LOCK 1/4-M6 SS
32
084929
6
WASHER FLAT 1/4 SS
33
0F97650202
1
OIL FILLER CAP 3.0L
34
0F5114
1
DECAL REFER TO OWNERS MANUAL
35
0G33090ST03
1
BRACKET COIL
36
049226
6
WASHER LOCK M5
37
051716
3
NUT HEX M5-0.8 G8 CLEAR ZINC
38
055440
3
SCREW HHC M5-0.8 X 25 G8.8
39
0G4262
2
MANIFOLD INTAKE LOWER REWORK
40
0E0992A
6
PLUG EXPANSION 14 OD
41
0F9223
6
GASKET INTAKE MANIFOLD LWR G3
42
083601
4
SCREW HHC M6-1.0 X 80 C8.8
43
022473
13
WASHER FLAT 1/4-M6 ZINC
44
0C7125
4
SCREW HHC M6-1.0 X 120 C8.8
47
0F9222
1
MANIFOLD INTAKE UPPER
48
0G0607
1
ASSEMBLY HOSE PCV VALVE
49
0F9564
1 (REF)
GASKET INTAKE ADAPTER
50
0F9563
1(REF)
GASKET IDLE AIR CONTRL ACT CVR
51
0E6585
1
COVER IAC ACTUATOR
52
022097
4
WASHER LOCK M6-1/4
53
047411
2
SCREW HHC M6-1.0 X 16 G8.8
54
0F7695
1
EGR GASKET
55
0F6658
1
COVER EGR
56
039253
2
SCREW HHC M8-1.25 X 20 G8.8
57
0D3973
1
PLUG, EXPANSION 16MM
58
0G3720A
1
REWORK HARMONIC BAL 3.0L RWD
59
0D3488E
1
BELT SERPENTINE 71.04"
60
0G3643
1(REF)
WATER PUMP 3.0L
61
0G3791A
1
HOSE WATER PUMP 3.0L
62
099502
2
CLAMP HOSE #24 B1.06-2.00
63
0G7856A
1
REWORK BREATHER TUBE 3.0L G3 LS
64
052265
3
SCREW HHC M8-1.25 X 65 G8.8
65
0D8028
2
PULLEY GROOVED ENGINE IDLER
66
0G3842
1
SPACER IDLER PULLEY 3.0L
67
042568
1
SCREW HHC M6-1.0 X 20 G8.8
68
0G3644
1(REF)
SENSOR CRANKSHAFT SPEED 3.0L
69
0G38040ST03
1
WELDMENT IDLER BRACKET 3.0L
70
0D8025
1
BOLT HEX FL HD M8-1.25 X 28
71
0G3896
1
SPACER .34 X 1.00 X .11 STL/ZC
72
039414
1
SCREW HHC M8-1.25 X 35 G8.8
73
0D34540186
6
SPARK PLUG (PLATINUM) .044 GAP
74
027482
1
WASHER SHAKEPROOF EXT 5/16 STL
75
0G3909
1
HARN ENG 3.0L G14 R-200 2P (NOT SHOWN)
76
045771
2
NUT HEX M8-1.25 G8 CLEAR ZINC
77
0G35770ST03
1
BRACKET DC ALTERNATOR LOWER
78
0G38210ST03
1
BRACKET TENSIONER
79
0E9868A
1
ALTERNATOR DC W/OUT PULLEY
80
0F3217
1
SPACER DC ALTERNATOR PULLEY
81
0F3216C
1
PULLEY 132 OD DC ALTERNATOR
82
049814
1
SCREW HHC M10-1.5 X 25 G8.8
83
0G34700ST03
1
BRACKET THERMOSTAT 3.0L
84
049813
1
NUT HEX M6 X 1.0 G8 YEL CHR
85
035685
2
CLAMP HOSE #28 1.32-2.25
86
0F9232
1
HOSE UPPR RAD REAR
87
0A2711A
2
ADAPTER THERMOSTAT
88
048665
2
GASKET THERMOSTAT
89
0F9252
1
MACHINING,THERMOSTAT ADPTR
90
075885
1
THERMOSTAT 195 DEG
91
0A6751
1
SWITCH HI-TEMP 245D X 3/8 NPT
92
049226
1
WASHER LOCK M5
93
074908
1
SCREW HHTT M5-0.8 X 10 BP
94
052207
2
SCREW HHC M8-1.25 X 80 G8.8
95
047527
1
BARBED STR 1/2NPT X 3/4
96
057823
3
CLAMP HOSE #10 .56-1.06
97
050968
1
HOSE COOL 3/4 ID 20R3 (22" LG)
98
069860C
1
HOSE OIL DRAIN ASSY 21"
99
0C7649
1
CLAMP HOSE .38-.87
100
043790
1
BARBED EL 90 3/8 NPT X 3/8
101
077456
1
ADAPTER M12-1.75 X 3/8 NPT
102
052677
1
WASHER NYLON .50 X .87 X .06
103
049541
1
SCREW HHC M10-1.5 X 35 G8.8
104
0G3781
3
RETAINER SPARK PLUG WIRE
105
0G4431
1
RESTRICTOR PCV
106
0G3245
1
SPARK PLUG WIRE SET
107
0F9228
1
COIL IGNITION
108
031919
1
PLUG STD PIPE 3/8 COUNTERSUNK
109
0F8795
1
MANIFOLD EXHAUST RH
110
051751
4 (REF)
SCREW HHC M6-1.0 X 50 G8.8 (INCL. WITH I/N 47)
111
0F9224
6(REF)
GASKET INTAKE MANIFOLD UP G3
112
0G5971
1
RESTRICTOR COOLANT BYPASS
113
026850
1
WASHER SHAKEPROOF EXT 1/4 STL
114
0G8084
1
COOLANT X-OVER CASTING
115
038750
2
SCREW HHC M6-1.0 X 30 C8.8
