- Page 1 PT Range Operators Handbook PT models Covering Models:- PT5 / PT8 / PT15 / PT24 / PT50D BAMBI AIR COMPRESSORS LTD 152 Thimble Mill Lane Heartlands Birmingham B7 5HT Tel: 0121 322 2299 Fax: 0121 322 2297 Email: sales@bambi-air.co.uk www.bambi-air.co.uk...
-
Page 2: Technical Specification
Bambi reserves the right to modify the contents of this operating booklet without notice and the information is in no way binding on the company. -
Page 3: Safety Precautions
1) Safety Precautions 2) Siting The Compressor What you must do: What you must do: • Read these instructions before using • Provide adequate protection from the your air compressor. weather. • Ensure the compressor has been • Site the compressor level in both installed, electrically connected... -
Page 4: Operation
Operation Starting & Stopping Plug the compressor into an outlet socket of nominal voltage. All models: Switch the compressor on by turning the red control on top of the pressure switch to the “Auto” position. The compressor will run until the pressure in the receiver is at 8 bar. -
Page 5: Routine Maintenance
Routine Maintenance Refer to preventative maintenance section for frequency. [Page 4] Draining the Air Receiver Drain water condensate from air receiver at a pressure of no more than 2 Bar. Slowly open the drain tap provided to allow water to flow out. Close drain tap when all water has drained off. - Page 6 Ref No. Description Part no. 40mm line pressure gauge BPB1077 Pump motor BPB1238 Elbow M/F BPB1139 Pump motor filter BPB1259 Extension BPB0150 Pump motor filter element BPB1263 Connector BPB0810 Frame BPB1262 50mm tank pressure gauge BPB1081 Motor support BPB1261 Delivery pipe BPB1258 Elbow BPB1257...
- Page 7 Ref No. Description Part no. Elbow M/F BPB1139 Pump motor BPB1238 Tee piece MFF BPB1109 Pump motor filter BPB1259 Connector BPB0810 Pump motor filter element BPB1263 50mm tank pressure gauge BPB1081 Frame BPB1249 Delivery pipe BPB1258 Motor support BPB1261 Connector BPB1242 Insert BPB0078...
- Page 8 PT 15 / 24 40mm line pressure gauge BPB1077 Ref No. Description Part no. Elbow M/F BPB1139 Pump motor BPB1238 Elbow BPB1257 Pump motor filter BPB1259 Connector BPB0810 Pump motor filter element BPB1263 50mm tank pressure gauge BPB1081 Tank [PT15] BPB0470 Delivery pipe BPB1258...
- Page 9 PT50D Ref No. Description Part no. Regulator BPB1080 Pump motor BPB1238 40mm line pressure gauge BPB1077 Pump motor filter BPB1259 Siphon tube BPB0028 Pump motor filter element BPB1263 Connector BPB0152 Tank BPB0474 50mm tank pressure gauge BPB1081 Inspection plug BPB0243 Delivery pipe BPB1258 Inspection plug seal...
- Page 10 PT Pump spares Ref No. Description Part no. Cylinder head seal BPB1250 Valve plate assembly BPB1251 Cylinder BPB1253 Connecting rod BPB1254 Top washer BPB1254 Piston ring BPB1254 Airway tube, inc. O ring seal BPB1252 Motor fan LH BPB1255 Motor fan RH BPB1264 Fan cover BPB1256...
-
Page 11: Maintenance Work
SERVICE RECORD Date installed____________________________ Date Maintenance work Signature / Company SERVICE KITS BPPT 1 Service Kit covers all models. PT50D requires two kits. BPB0655 required to change the Coalescing Filter Element... - Page 12 EC Declaration of Conformity - Declaration de Conformite CE – EG Konformitatserklarung Declaracion de Conformidad CE - EG Verklaring van Overeenstemming Bambi Air Compressors declares that this product conforms to the European Directives listed below. Bambi Air Compressors declare que ce produit est conforme aux directives europeennes enumerees ci-dessous.
