Connector Information
Phonejack stereo
PIN1. AC power cord
Video signal connector 15P Mini D-Sub connector x 1
16
PIN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
: CEE22 typed connector
MNEMO
SIGNAL
RV
Red Video
GV
Green Video
BV
Blue Video
NC
None
GND
Ground(DDC return)
RG
Red GND
GG
Green GND
BG
Blue GND
+5V
+ 5V (for DDC)
SG
Sync GND
NC
None
SDA
DDC Data
HS
Horizontal Sync
VS
Vertical Sync
SCL
DDC Clock
- 34 -
CN6
DB15HD
17
Chapter 5
