OPERATING INSTRUCTIONS

Front Panel Definition

This Section defines the front panel User Interface for Led Indictor and Key function.
Key Definition:
There are five keys defined in this system and described bellows.
* Adjusting display settings

External Controls

?
1
?
2
Function
?
3
UP/ PLUS
DOWN /
?
4
?
5
Power on/off
POWER
Blue: power on
Orange: in sleep mode
Press to view OSD.
OSD
Press again to exit a selection in OSD.
If OSD is active, press to select or adjust OSD options. If OSD
is inactive, press once, then press the buttons marked
to adjust the volume.
If OSD is active, press to select or adjust OSD options. If OSD
is inactive, press once, then press the buttons marked
MINUS
to adjust the volume.
If OSD is active, press to enter a selection in OSD. If OSD is
AUTO
inactive, press and the monitor will automatically optimize the
position, focus and clock of your display.
- 16 -
Chapter 2
or
or
