kincrome KP702 Manual

kincrome KP702 Manual

Wet & dry garage vac

Advertisement

Quick Links

WET & DRY
GARAGE VAC
1.5M
20L
HOSE
CAPACITY
1250
WATT
MOTOR
ON
BOARD
ACCESSORY
STORAGE
KP702
STAINLESS
STEEL
SUCTION
TANK
1250
WATT
MOTOR
ON
BOARD
ACCESSORY
STORAGE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KP702 and is the answer not in the manual?

Questions and answers

Del Chapman
February 9, 2025

Why is my machine blowing and not sucking

1 comments:
Mr. Anderson
February 11, 2025

The Kincrome KP702 machine may be blowing instead of sucking because it is connected to the blower port instead of the suction inlet. Check that the hose is correctly attached to the suction port rather than the blower port.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for kincrome KP702

  • Page 1 WET & DRY 1250 GARAGE VAC WATT MOTOR 1.5M STAINLESS STEEL BOARD SUCTION TANK ACCESSORY HOSE CAPACITY STORAGE 1250 WATT MOTOR STAINLESS STEEL BOARD TANK ACCESSORY STORAGE KP702...
  • Page 2: Know Your Product

    17. 3 Micron Filter Cartridge 18. Foam Filter 19. Crevice Tool 20. Brush 21. Blower Port Model No: ........................KP702 Power: ........................1250W Input: ......................... 220 - 240V ~ 50Hz Hose Diameter: ......................32mm Hose Length: ......................1.5m Tank Capacity Dry: ....................20l Tank Capacity Liquid: ....................
  • Page 3: General Power Tools Safety Warnings

    20L WET & DRY GARAGE VAC General Power Tools Safety Warnings Save all warnings and instructions for future reference. WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. 1) Electrical Safety a) Power lead plugs must match the outlet.
  • Page 4 20L WET & DRY GARAGE VAC 4) Risk of Electric Shock Never touch the mains plug and the socket with wet hands. Do not pull the plug from the socket by pulling on the power cable. Check the power cord and mains plug for damage before every use. To avoid accidents due to electrical faults we recommend the use of sockets with a line-side current-limiting circuit breaker (max.
  • Page 5 4. Locate the wet & dry floor tool (8) onto the lower section of the 2pce extension wand (13) (fig 4). 2a) Choosing The Correct Vacuum Filter The KP702 20L Wet & Dry garage vac comes with three filter types. Foam Filter (18): The foam filter (18) should only to be installed when you are using the vacuum to clean up spills or when water is present where you are vacuuming.
  • Page 6 20L WET & DRY GARAGE VAC Wet & Dry GarageVac User Instructions (cont.) 2b) Installation of the Filters - Cloth (16) & 3 Micron Filter Cartridge (17) 1. Remove the motor head (4) from the vacuum tank (10) by releasing the tank retention clips (11) on the side of the vacuum.
  • Page 7 20L WET & DRY GARAGE VAC 3) Operation 3a) Turning ON the Vacuum 1. Plug the vacuum into your wall socket and turn the wall socket ON. 2. To turn ON the motor of the vacuum press the ON/Off switch (12) to the “ON” “I” position (fig 6a).
  • Page 8 20L WET & DRY GARAGE VAC 4) Storage of the Wet & Dry Vacuum WARNING! Ensure the tool is disconnected from the power supply before cleaning or maintaining the appliance. Always ensure that the vacuum is emptied of any debris prior to storage. Ensure that any liquids have been removed from the Vacuum tank (10) and that the tank is completely dry prior to storage.
  • Page 9: Troubleshooting

    ON/Off to Start switch (12) to the “ON” “I” position. Electrical fault Contact Kincrome Customer Service. Vacuum tank full Empty the Vacuum tank (10) Clean all filters as described in Maintenance of your Vacuum.
  • Page 10: Spare Parts

    Kincrome Customer Service on 1300 657 528 for assistance. Spare Parts For a full list of available spare parts for this item visit the Kincrome website kincrome.com.au or alternatively contact Kincrome Customer Service. Warranty given by Kincrome Australia Pty Ltd of 3 Lakeview Drive, Caribbean Park, Scoresby, Victoria (Tel 1300 657 528).
  • Page 11 20L WET & DRY GARAGE VAC NOTE:...
  • Page 12 kincrome.com.au...
