- Page 1 Instructions for use Upright freezer KA2512C...
- Page 2 We thank you for the confidence you have shown by purchasing our appliance which is designed to simplify your life. To make the use of the product easier, we have supplied detailed instructions for use, and installation instructions supplied on a separate sheet. The instructions should allow you to learn about your new appliance as quickly as possible.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Safety instructions Advice for saving energy with refrigeration appliances Installation and connection Changing the door opening direction Appliance description Appliance description Operating the appliance Appliance interior equipment Storing and freezing food Freezing fresh food and storing frozen food Defrosting and cleaning the appliance Defrosting the appliance Cleaning the appliance... -
Page 4: Introduction
INTRODUCTION Safety instructions Before using the appliance for the first time Before connecting the appliance to the power mains, please read carefully the instructions for use which describe the appliance and its correct and safe use. The instructions apply to several appliance types/models;... - Page 5 INTRODUCTION Safety instructions The appliance must be connected to the power mains and grounded in compliance with the effective standards and regulations. Before cleaning the appliance, unplug it from the power mains (unplug the power cord from the wall outlet). If the power cord is damaged, it must be replaced by a service technician or other adequately trained person.
- Page 6 INTRODUCTION Danger of frostbite Never put frozen food in your mouth and avoid touching frozen food as this may cause frostnip or frostbite. Safety of children and vulnerable persons This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or metal capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning...
- Page 7 INTRODUCTION Warning regarding the refrigerant The appliance contains a small amount of an environmentally friendly yet flammable gas R600a. Make sure that no parts of the cooling system are damaged. A gas leak is not hazardous to the environment, but it could cause eye injury or fire.
- Page 8 INTRODUCTION Important information on the use of appliance WARNING! Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. The appliance may not be used outdoors and it may not be exposed to rain. Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
- Page 9 INTRODUCTION Environment protection The packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment. Removing an obsolete appliance To protect the environment, take the obsolete appliance to an authorized home appliance collection centre.
-
Page 10: Advice For Saving Energy With Refrigeration Appliances
INTRODUCTION Advice for saving energy with refrigeration appliances • Install the appliance as specified in the instruction manual. • Do not open the door more often than necessary. • Occasionally make sure air circulation underneath the appliance is unobstructed. • Condenser unit on the rear wall should be kept clean (see chapter ‘Cleaning the appliance’). •... -
Page 11: Installation And Connection
INTRODUCTION Installation and connection Selecting the room • Install the appliance in a dry and well ventilated room. The appliance will operate correctly if the environment temperature is in the interval specified in the table. The appliance class is indicated on the rating plate / label with the basic information of the appliance. Class Temperature Relative Humidity... - Page 12 INTRODUCTION Installing the appliance Appliance installation should be carried out by at least two persons to avoid any physical injury or damage to the appliance. • Spacers are fitted on the corners of the doors. Remove them. • The appliance must stand level or tilted slightly to the back, stable on a solid base.
- Page 13 INTRODUCTION • The appliance may stand alone or it may be placed next to a cupboard or a wall. Consider the clearance required to fully open the door in order to allow pulling out the drawers and shelves (see installation diagram). min 1220 630 675 1194...
- Page 14 INTRODUCTION 1200 min. 50 mm min. 40 mm 1078 1850 Side-by-side installation: We recommend leaving the side-by-side installation of two appliances to a service technician. If you decide to do this yourself, observe the instructions supplied with the side-by-side installation kit. EN 14...
- Page 15 INTRODUCTION Connecting the appliance • Connect the appliance to the power mains using the power cord. The wall outlet should be fitted with a ground contact (safety socket). Nominal voltage and frequency are indicated on the rating plate/label with basic information of the appliance. •...
-
Page 16: Changing The Door Opening Direction
INTRODUCTION Changing the door opening direction Tools required: socket wrench No. 8, Phillips screwdriver, torx 25, Hex key No. 4 and flat screwdriver. The procedure to change the door opening direction opening should be carried out by at least two persons. Remove the upper hinge cover (A) and the covering cap (G). - Page 17 INTRODUCTION EN 17...
-
Page 18: Appliance Description
APPLIANCE DESCRIPTION Appliance description Control unit LED lighting NO FROST freezing unit Storage compartment Drawers for freezing and storage EN 18... -
Page 19: Operating The Appliance
APPLIANCE DESCRIPTION Operating the appliance Temperature settings and extra function key Temperature display The indicator for the selected temperature will be lit. Intensive freezing (boost) function indicator Symbol C will be lit when the intensive freezing function is activated. Switching the appliance on/off To switch on the appliance, plug the power cord into the power mains outlet. - Page 20 APPLIANCE DESCRIPTION Adjusting the temperature in the appliance • Adjust the temperature as desired using the A key. • Press the A key (several times) until the desired temperature indicator lights up. • The numbers -24, -22, -20, -18 and -16 indicate the degrees Celsius (°C) in the appliance.
- Page 21 APPLIANCE DESCRIPTION Intensive freezing (boost) function To activate the intensive freezing (boost) function, press the A key several times until symbol C lights up. • Use this setting after switching on the appliance for the first time, before cleaning, or 24 hours before adding a large amount of food. •...
-
Page 22: Appliance Interior Equipment
APPLIANCE DESCRIPTION Appliance interior equipment • The MultiBox is convenient for storing food with a strong or pungent smell. • If the tray is used as an ice tray, fill it with water and place it in the freezer in a horizontal position. -
Page 23: Storing And Freezing Food
STORING AND FREEZING FOOD Freezing fresh food and storing frozen food Freezing procedure Maximum amount of fresh food that may be inserted at once is specified on the appliance rating plate. If the amount of food to be frozen exceeds the indicated amount, the quality of freezing will be inferior;... - Page 24 STORING AND FREEZING FOOD Important warnings on freezing • Only use the freezer to freeze food appropriate for freezing. Always use quality and fresh food. • Select the most suitable packaging for the food and use the packaging correctly. • Make sure the packaging is air and water tight so that the food does not dry out and loose its vitamins.
- Page 25 STORING AND FREEZING FOOD Frozen food storage time Recommended storage time in the freezer Type of food Time fruit, beef from 10 to 12 months vegetables, veal, poultry from 8 to 10 months venison from 6 to 8 months pork from 4 to 6 months finely chopped or ground meat 4 months...
-
Page 26: Defrosting And Cleaning The Appliance
DEFROSTING AND CLEANING THE APPLIANCE Defrosting the appliance Defrosting a No Frost freezer • The No Frost freezer will defrost automatically. Occasional frost that may appear on the walls will disappear automatically. • Build-up of ice or frost in the freezer compartment can be a result of abnormal use of the appliance (door opened too frequently and/or too long, door not properly closed etc.). -
Page 27: Cleaning The Appliance
DEFROSTING AND CLEANING THE APPLIANCE Cleaning the appliance Before cleaning, unplug the appliance from the power mains – switch off the appliance (see chapter ‘Operating the appliance’) and unplug the power cord from the wall outlet. • Use a soft cloth to clean all surfaces. Cleaners that contain abrasive substances, acids, or solvents are not suitable for cleaning as they may damage the surface. -
Page 28: Other
OTHER Troubleshooting Problem Cause or remedy: Appliance is • Make sure there is voltage in the power outlet and that the appliance is switched on. connected to the power mains but it does not work. Cooling system • Too high ambient temperature. •... -
Page 29: Information About Appliance Noise
OTHER Information about appliance noise Cooling in freezers is made possible by a cooling system that also includes a compressor (and a fan with some appliances), which generates some noise. The level of noise depends on installation, proper use, and age of the appliance. •... - Page 30 EN 30...
- Page 32 The appliance identification card is located on the bottom of the appliance. Stick the appliance identification card here. When contacting the service department, have the complete type number to hand. You will find the addresses and phone numbers of the service organisation on the warranty card. en (09-18)
