Atag KU1090A Instructions For Use Manual

Hide thumbs

Quick Links

Download this manual

instructions for use

freezer

Thank you for your trust and for buying this appliance.

We hope it will successfully serve the purpose for

many years.

The freezer for domestic use is intended for freezing

fresh food and for long-term storing of frozen food (up

to one year, depending on the kind of food).

Before putting into use . . . . . . . . . . . . . . . . . . 58-61

Placing and installation . . . . . . . . . . . . . . . . . . . . 62

Description of the appliance . . . . . . . . . . . . . . . . . 63

Operation control . . . . . . . . . . . . . . . . . . . . . . 64-65

Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66-68

Maintenance and cleaning . . . . . . . . . . . . . . . . 69-71

Trouble shooting guide . . . . . . . . . . . . . . . . . . 72-74

Need help?

Do you have a question about the KU1090A and is the answer not in the manual?

Questions and answers

Summary of Contents for Atag KU1090A

Page 1: Table Of Contents
instructions for use freezer Thank you for your trust and for buying this appliance. We hope it will successfully serve the purpose for many years. The freezer for domestic use is intended for freezing fresh food and for long-term storing of frozen food (up to one year, depending on the kind of food).
Page 2: Before Putting Into Use
instructions for use before putting into use · Before connecting the appliance to the mains supply, leave it stand for about 2 hours which will reduce the possibility of malfunctions in the cooling system that might have occurred due to transport handling. ·...
Page 3 instructions for use before putting into use tips for energy savings · This is especially important if you have an upright model. · Check periodically if the appliance is provided with sufficient cooling (undisturbed circulation of air through the bottom rail openings). ·...
Page 4 instructions for use before putting into use · Do not freeze bottled drinks, especially not fizzy ones such as mineral water, sparkling wine, beer, cola etc., because liquid expands during freezing and the glass bottle is very likely to blow up. ·...
Page 5 instructions for use before putting into use ly, you will help prevent potential negative conse- quences for the environment and human health, which could otherwise be caused by inappropriate waste han- dling of thisproduct. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.
Page 6: Placing And Installation
instructions for use placing and installation choosing the right place Place the appliance in dry and well ventilated room. Allowed ambient temperature depends on the model (class) of the appliance and is stated on the rating plate of the appliance. Never place the appliance near heat emitting devices (e.g.
Page 7: Description Of The Appliance
instructions for use description of the appliance Freezing Compartment (1) is used for freezing fresh foods. Storing Basket (2) is used for storing packages of frozen foods. Control Panel (3) See Operation Controls...
Page 8: Operation Control
instructions for use operation control The freezer is controlled with switches and thermostat button, incorporated in the bottom section of the appli- ance. control panel 1 ON/OFF switch (green signal lamp) 2 Continued operation button (yellow signal lamp) 3 Alarm off button (red signal lamp) ON/OFF switch (1) The appliance is switched on - the green light is on.
Page 9 instructions for use operation control alarm off button and the red signal lamp (3) The sound of the alarm is switched off by pressing the Alarm Off button. The alarm goes off because of high temperature inside the freezer (red signal lamp is on), or because of the excessive dust collected at the con- denser (red signal lamp is off).
Page 10: Use
instructions for use starting the empty freezer Switch the freezer on. Sound alarm is on because of inappropriate temperature. It may be switched off by pressing the alarm button Put the mode selection switch to the continuous operation position. All three signal lamps are on. Place fresh food into the freezer several hours after the red signal lamp goes off.
Page 11 instructions for use continued operation button (2) to the uninterrupted operation (yellow lamp is on). At the end of this period load fresh food into the freezing compartment. · After 24 hours move the frozen food to the storage compartment of the freezer and repeat the freezing procedure with new load if required.
Page 12 instructions for use Approximate Storage Time of Frozen Foods Food Storage time (in months) Vegetable Fruit Braed, Pastries Milk Redy-made meals Meat: Beef Veal Pork Poultry Game Minced meat Smoked sausages Fish: lean Offal defrosting of frozen food Partially thawed or defrosted foods should be used as soon as possible.
Page 13: Maintenance And Cleaning
instructions for use maintenance and cleaning freezer defrosting Frost and ice layer, depositing on the inner walls of the freezer should be defrosted when 3-5 mm thick. · 24 hours prior defrosting press the continued operation mode button (2) (yellow lamp is on) to provide extra low temperature of food inside the freezer.
Page 14 instructions for use maintenance and cleaning - replace the condenser dish and the bottom rail in the opposite order. After you have cleaned the appliance, reconnect it to the mains supply and put the food packages back to their place. periodical cleaning of the condenser In order to optimize the operation of the appliance and save energy, it is recommended to clean periodically...
Page 15 instructions for use maintenance and cleaning · Clean the dust and dirt from the condenser. After cleaning return the appliance to its place, plug in the mains power cord and fill with food. switch off the appliance when not in use If you do not intend to use the appliance for a longer period of time, disconnect the power supply, empty the appliance, defrost it and clean it.
Page 16: Trouble Shooting Guide
instructions for use trouble-shooting guide During the service, you can come across some trou- bles that in most cases result from improper handling of the appliance and can easy be eliminated. the appliance fails to operate after connecting to the mains supply ·...
Page 17 instructions for use trouble-shooting guide cooling system is operating continuously · Continued operation mode is on (yellow lamp is on). Press the button (2) and switch the continued operation mode off (yellow lamp goes off). · Insufficient cooling of compressor and condenser. This is signaled by the sound alarm.
Page 18 instructions for use trouble-shooting guide operating, the refrigerant flow is heard. This is a normal condition and it has no influence whatsoever on the lifetime of the appliance. · After starting the appliance, the operation of the compressor and the refrigerant flow may be louder, which does not mean that something is wrong with the appliance and it has no influence on the lifetime of the appliance.
Page 19 gebruiksaanwijzing diepvrieskast notice d'utilisation KU1090CUU congélateur gebrauchsanweisung gefrierschrank instructions for use freezer...
Page 20 postbus 1033 - 6920 BA - Duiven 142029 (12-08)
