GSA Test Equipment
all ItEMs lIstED On EDMO gsa sCHEDulE
# gs-07F-5985r
transPOnDEr & DME bEnCH tEstEr
The ATC-1400A Transponder/DME Bench
Tester provides complete testing capability of
modern ATC transponders and DME equipment.
When used in conjunction with the T-1401,
I-1402, S-1403 or SI-1404; the testing capability
of the ATC-1400A can be expanded for TACAN,
Mode 4/IFF or Mode S transponders... making it the
most versatile pulse RF source in the avionics test
equipment industry.
t-1401 aCCEssOry
The T-1401 provides a user friendly test
solution for TACAN receiver/transmitters.
I-1402 aCCEssOry
The I-1402 provides a friendly test solution for
MK10A and MK12 IFF transponders and
interrogators.
MODE 4 aCCEssOry
P/N: 1402-110-c
s-1403 aCCEssOry
The S-1403DL/MLD provides a complete
test solution for Mode S and Mode S
"Datalink" capable transponders.
sI-1404 aCCEssOry
SI-1404 provides a comprehensive
3rd Line/Depot Level test solution
for next generation MK12/Mode S IFF
transponders.
WEatHEr raDar bEnCH tEstEr
The RD-301A X-Band Weather Radar
tester provides additional enhanced functions
and capabilities to meet and satisfy simula-
tion requirements of non-coherent Weather
RADAR systems. These low power,
narrowband, turbulence processing RA-
DARS demand optimum performance
of the magnetron pulse. The RD-301A
provides the technician with the tools he
needs to ensure correct alignment and
operation.
MICrOWaVE lanDIng systEM bEnCH tEstEr
The MLS-800 is a microprocessor controlled
Ground Station Simulator designed to
operate from a bench test environment.
Test parameters are selected via a 44-position
keyboard and displayed on test
operational menus.
Mls tEstEr
P/N: mls-800
rVsM DIgItal aIr Data tEstEr
The DPS-350 Air Data Tester is a micropro-
cessor based unit using the latest in transduc-
er technology. It operates similar to Barfield's
1811 series testers, but the transducer
technology used is virtually immune to
the costly repairs generally experienced by
analog instruments.
aIr Data tEstEr
P/N: DPs-350
www.edmo.com
12
xPnDr/DME tEstEr
P/N: 1400A-110
taCan aCCEssOry
P/N: 1401-110-c
MODE s aCCEssOry
P/N: 1403-110-c
Mk12 aCCEssOry
P/N: 1404-110-c
raDar tEstEr
P/N: 301A-c
EDMO Distributors, Inc.
GS-07F-5985R
1811D PItOt/statIC tEstEr -2 InstruMEnt
The 1811D is an inexpensive, portable field tester ideal
for leak testing aircraft pitot and static systems or on-board
testing of altimeters and airspeed indicators. It is config-
ured with hand pumps and external pressure ports for
supplying the necessary pressure and vacuum (no external
power required) needed for on-board testing. This pitot/static
tester is very practical for new facilities or those with a lim-
ited budget.
PItOt/statIC tEstEr
P/N: 1811D
1811ga/Ha PItOt/statIC tEstEr -3 InstruMEnt
The 1811GA/HA testers are portable, self-contained units,
used for testing and calibrating aircraft pitot/static systems.
This tester uses three analog instruments (Altimeter,
Vertical Speed and Airspeed) with the appropriate
correction cards to perform aircraft leak tests or instru-
ment calibrations. It is configured with hand pumps only
(1811GA) or hand pumps and AC power (1811HA) capabil-
ity. Either model can be fitted with the digital instru-
ments below for increased accuracy & reliability.
PItOt/statIC tEstEr
DIgItal altIMEtEr & DIgItal aIrsPEED
The aviation industry has an enormous need for
more reliable and cost effective tools for perform-
ing standard pitot/static system leak tests. The
DALT55 Digital Altimeter and the DAS650 Digi-
tal Airspeed indicator were designed to be a direct
replacement to the current analog instruments. The
DALT55 & DAS650 use state-of-the-art
transducer technology for pressure measurements,
making them virtually immune to the frequent
and costly repairs generally associated with ana-
log instruments.
sIgHt COMPass
The SC063 is used to check the mounted aircraft
compass. It is unique in that the compensating
magnets have been removed and a combination
magnifying lens and collimating sight added.
The compass indicates magnetic direction at
all times and is not subject to calibration
offsets. Accurate to ±1º. Includes monopod and
protective carrying case.
Calibration Card Included.
HIgH VOltagE/lOW CurrEnt MEgOHMMEtEr
This megohmmeter is designed to check the insula-
tion breakdown in a variety of applications requiring a
high voltage but low current. Selectable test voltages:
45, 100, 200 and 500 VDC. Meter range: 0.5 to
1000MΩ.
MEgOHMMEtEr
DIgItal turbInE tEMPEraturE tEstEr
The TT1200A is specifically designed to accomplish all
requirements for testing the aircraft Chromel-Alumel (K
type) turbine temperature measuring systems. The tester can
measure resistances down to 0.001 Ω, measure insulation
up to 200 MΩ, perform indicator runouts with a resolution of
.1ºC or 1ºC and a range of 1372ºC, and can also display the
equivalent ºF or millivoltages and may be used as a master
indicator as well.
PrEssurE "DEaD WEIgHt" tEstEr
The 2311FA tests aircraft pressure systems
for both reciprocating and turbine engine
pressure systems. It provides pressure for
testing pressure transmitters, warning
switches pressure-type torque (BMEP)
indicators and system leak testing in the
range of 0-600 PSI. Two types of gauges
are recommended and are available for
standard or inspector accuracy requirements.
Call for Pricing!
P/N: 1811gA
P/N: 1811HA
DIgItal altIMEtEr
P/N: DAlT-55
DIgItal aIrsPEED
P/N: DAs-650
sIgHt COMPass
P/N: sc063
P/N: 2471f
tEMP. tEstEr
P/N: TT1200A
PrEssurE tEstEr
P/N: 2311fA
1-800-235-3300
