i. Gain access at the opposing A-pillar
moving along the bottom to meet the
opposite cut.
j. Remove from the glass.
gripping the tool with the opposite
hand, gain access using the 2
point at the A-pillar and cut upward.
Grip the suction lifter with the
opposite hand and finish the cut
moving inward to meet the opposite
cut.
k. Upon completing the cut, remove the
windshield with the opposite hand by
lifting with the suction lifter and
dispose.

3) CUTTER BLADE REPLACEMENT

a. Remove battery from tool and place to
the side.
b. Remove the cutter blade screws with
the allen key provided with your kit
and place to the side.
c. Remove the cutter blade set from the
shear head and place to the side.
d. Remove replacement cutter blade set
from its packaging and remove any
securements (i.e. wire tie).
e. As a complete unit, insert cutter blade
set as shown back into the shear head
taking caution to align the dynamic
cutting blade fork in the center of the
shear head.
f. Replace cutter blade screws and
tighten about ¼ turn.

REPLACEMENT PARTS

Go to www.RHYNO.com
parts.
Contact info:
We Cut The Glass, LLC.
4960 William Flynn Highway
Suite 6, #350
Allison Park, PA 15101
Toll Free: 800.883.1094 Fax
484.991.1952
Email: info@wecuttheglass.com
While
nd
plunge
for replacement
