RHYNO Windshield Cutter RWC-1 Operator's Manual page 11

with a brake. The blades will stop when
the trigger switch if fully released.
c. The variable-speed trigger switch allows
you to start cutting at a slow speed. The
further you squeeze the trigger, the
faster the tool will operate.
maximum tool life, use variable speed
during starts, stops and cornering.
d. Your tool is equipped with a single work
light (9). The work light will be activated
when the trigger switch is squeezed.
e. Your tool is equipped with a Motor
Control switch (10). This switch locks the
trigger while in the center position and
permits motor drive when to the left.
WARNING: Work light is for providing
light to the immediate work surface and is
not intended to be used as a flashlight.
f. Your tool is equipped with three cutting
blades, one dynamic (1) and two
stationary or static (2). The middle blade
reciprocates up and down between the
two static blades to cut the glass.
g. To remove the battery (7), from the
handle (6) of the tool, press both
unlocking buttons and firmly pull the
battery outward from the handle.
h. Align the battery pack with the rails of the
tool's handle and slide it firmly into the
handle until you hear the lock snap into
place.
WARNING: SHEAR HAZARD. ALWAYS
keep hands, fingers, hair, clothing and/or
other body parts clear and away from
between or near cutting blades. Severe
injury will result.
i. WARNING: SHEAR HAZARD. To reduce
the risk of serious personal injury,
disconnect the battery pack before making
any adjustments,
removing/installing
accessories.
2) CUTTING LAMINATED GLASS
a. Don personal protective equipment
including
maintenance
attachments
ANSI approved
goggles, respirator and cut-resistant
gloves.
b. Place suction lifters on laminated glass
to be cut and activate the suction by
lifting the movable handle.
For c. Grasp tool handle with the right hand
with a pistol grip and place left hand
along motor housing.
d. Impact the glass moderately with the
cutter blades at a 90° angle or
perpendicular.
e. If the glass in that location is curved
significantly or is very close to the
edge near support like the A-pillar,
move your purchase point to a new
location which is flat or near flat and
try 2-3 more impacts.
f. Once purchase has been achieved,
place dynamic cutting blade inside
glass hole and activate the trigger
switch to begin cutting.
g. Ensure tool is positioned with glass
parallel to the angle tool on the shear
head while cutting. DO NOT PUSH
HARD. Let the tool do the cutting.
or
h. Remove from the glass and begin
or
again in the original location cutting
along the bottom to the mid-line.
safety
