KG6111P
KG6192P
KG6111W
Het toestel-identificatieplaatje bevindt zich aan de onderkant van het toestel.
La plaque d'identification de l'appareil se trouve sur le dessus de l'appareil.
Das Gerätetypenschild befindet sich an der Unterseite des Gerätes.
The appliance identification card is located on the bottom of the appliance.
Plak hier het toestel-identificatieplaatje.
Handleiding
Manual
Placez ici la plaque d'identification de l'appareil.
Kleben Sie hier das Gerätetypenschild ein.
Stick the appliance identification card here.
Houd, wanneer u contact opneemt met de serviceafdeling, de productiecode (PCODE)
en het volledige itemnummer (ITEMNR) bij de hand.
En cas de contact avec le service après-vente, ayez auprès de vous le code de production
(PCODE) et le numéro complet de l'article (ITEMNR).
Halten Sie den Produktionscode (PCODE) und die vollständige Itemnummer (ITEMNR)
bereit, wenn Sie mit der Kundendienstabteilung Kontakt aufnehmen.
When contacting the service department, have the production code (PCODE) and
complete item number (ITEMNR) to hand.
Adressen en telefoonnummers van de serviceorganisatie vindt u op de garantiekaart.
Les adresses et les numéros de téléphone du service après-vente se trouvent sur la carte de garantie.
Adressen und Telefonnummern der Kundendienstorganisation finden Sie auf der Garantiekarte.
You will find the addresses and phone numbers of the service organisation on the guarantee card.

Advertisement

loading
Need help?

Need help?

Do you have a question about the KG6111P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Atag KG6111P

  • Page 1 KG6111P KG6192P KG6111W Het toestel-identificatieplaatje bevindt zich aan de onderkant van het toestel. La plaque d’identification de l’appareil se trouve sur le dessus de l’appareil. Das Gerätetypenschild befindet sich an der Unterseite des Gerätes. The appliance identification card is located on the bottom of the appliance.
  • Page 2 Gebruiksaanwijzing 3 - 14 Installatievoorschrift 15 - 20 Instructions for use 3 - 14 Installation guide 15 - 20...
  • Page 3 Inhoud HANDLEIDING Uw gaskookplaat Inleiding Beschrijving Veiligheidsvoorschriften Bediening Ontsteken en instellen Comfortabel koken De kookplaat optimaal gebruiken 8 - 9 Onderhoud Algemeen 10 - 11 - 12 Storingen Storingstabel 13 - 14 Installatievoorschrift Algemeen 15 - 16 Afmetingen 17 - 18 Gastechnische gegevens Bijlage Afvoeren toestel en verpakking...
  • Page 4 Inleiding UW GASKOOKPLAAT Deze gaskookplaat is ontworpen voor de echte kookliefhebber. De verschillen in brandercapaciteit zorgen ervoor dat u ieder gerecht kunt bereiden. Dankzij de in de knoppen geïntegreerde vonkontsteking ontsteekt èn bedient u de branders met één hand. Dit toestel voldoet aan alle eisen die gelden voor het Kookkeurmerk. Dit betekent dat de gaskookplaat hoog rendement koppelt aan een minimum aan onvolledige verbrandingsgassen.
  • Page 5 Beschrijving UW GASKOOKPLAAT KG6111P KG6111W KG6192P Sudderbrander Sudderbrander Sterkbrander Wokbrander Normaalbrander Normaalbrander RVS-vangschaal RVS-vangschaal Pandrager Pandrager NL 5...
  • Page 6 Veiligheidsvoorschriften UW GASKOOKPLAAT Waar u op moet letten Zorg voor voldoende ventilatie tijdens het gebruik. • Houd natuurlijke ventilatieopeningen open. º Bij langdurig gebruik van de kookplaat is extra ventilatie º noodzakelijk. Zet bijvoorbeeld een raam open of installeer een mechanische ventilator.
  • Page 7 Ontsteken en instellen BEDIENING Ontsteken en instellen Elke brander kan traploos worden geregeld tussen vol- en kleinstand. 1. 0-stand 2. Branderaanduiding 3. Kleinstand 4. Volstand Bediening Druk de bedieningsknop in en draai hem linksom. De brander ontsteekt. Houd de bedieningsknop ongeveer 5 seconden ingedrukt om de vlambeveiliging in te schakelen.
  • Page 8 De kookplaat optimaal gebruiken COMFORTABEL KOKEN De kookplaat optimaal gebruiken Zorg er altijd voor dat de vlammen onder de pan blijven. Als vlammen om de pan heen spelen gaat veel energie verloren. Bovendien kunnen de handgrepen dan te heet worden. Gebruik geen pannen met een kleinere bodemdiameter dan 12 cm.
  • Page 9 De kookplaat optimaal gebruiken COMFORTABEL KOKEN Gebruik van het wok-hulprooster Het hulprooster dat ten behoeve van de wokbrander is meegeleverd of als accessoire verkrijgbaar is zorgt voor extra stabiliteit bij een wok met een platte bodem. Plaats het hulprooster volgens de illustratie op het wokrooster. NL 9...
  • Page 10 Algemeen ONDERHOUD Uw toestel is vervaardigd uit hoogwaardige materialen, die u eenvoudig reinigt. Branderdelen mogen niet in de vaatwasser gereinigd worden. • De onderdelen kunnen door het vaatwasmiddel aangetast worden! Gebruik niet te veel vocht, aangezien dit de brander of ventilatieopeningen kan binnendringen.
  • Page 11 Wanneer de vlekken met de hierboven beschreven methode niet • te verwijderen zijn kunt u de kookplaat reinigen met ATAG Shine. Houd er echter rekening mee dat u de hele vangschaal moet behandelen om “kleur”verschil te voorkomen. U moet de vangschaal bovendien nabehandelen met een glans- of onderhoudsmiddel voor roestvaststaal.
  • Page 12 ATAG Shine Atag Nederland heeft een serie schoonmaakmiddelen samen- • gesteld onder de naam ATAG Shine. Deze zijn te verkrijgen via de website www.hps.nl. Hier vindt u ook diverse schoonmaak- en gebruikerstips. NL 12...
  • Page 13 Storingstabel STORINGEN Storingstabel Wanneer u twijfelt over de goede werking van uw kookplaat betekent dit niet automatisch dat er een defect is. Controleer in elk geval de volgende punten in onderstaande tabel of kijk voor meer informatie op de website www.hps.nl. SYMPTOOM MOGELIJKE OORZAAK OPLOSSING...
  • Page 14 Storingstabel STORINGEN SYMPTOOM MOGELIJKE OORZAAK OPLOSSING Een brander ontsteekt niet. Verkeerde soort gas gebruikt Controleer of het gebruikte (bij flessengastoepassing). gas geschikt is voor het toestel. Bedieningsknop niet lang of Houd de bedieningsknop diep genoeg ingedrukt. lang genoeg en voldoende diep ingedrukt tussen vol- en kleinstand.
  • Page 15 Algemeen INSTALLATIEVOORSCHRIFT Dit toestel mag alleen door een erkend installateur worden aangesloten. Let op De gassoort en het land waarvoor het toestel is ingericht staan vermeld op het gegevensplaatje. Dit is een klasse 1 toestel. Gasaansluiting De gasaansluiting moet voldoen aan de nationale en lokale •...
  • Page 16 Algemeen INSTALLATIEVOORSCHRIFT Indien de aansluitkabel beschadigd is mag deze alleen worden vervangen door de fabrikant, zijn serviceorganisatie of gelijkwaardig gekwalificeerde personen, teneinde gevaarlijke situaties te voorkomen. Kookplaat voorbereiden Monteer de bijgeleverde knie op de gasaansluiting van het toestel. 1/2 inch ISO 228 (recht) 1/2 inch EN 10226-1 (conisch) NL 16...
  • Page 17 Afmetingen INSTALLATIEVOORSCHRIFT Inbouwmaten NL 17...
  • Page 18 20mm min. 20mm min. 600 mm min. 650 mm . 650 mm min. 450 mm min. 20mm KG6111P, KG6192P min. 60mm KG6111W min. 20mm min. 450 mm De kookplaat mag naast slechts één verticale wand ingebouwd worden. Toestel plaatsen en aansluitingen maken Plaats het toestel op een stevige, vlakke ondergrond.
  • Page 19 Gastechnische gegevens INSTALLATIEVOORSCHRIFT G25/25 mbar Brander-type (kW) Sudder 1.00 Normaal 2.00 Sterk 3.00 4.00 NL 19...
  • Page 20 Afvoeren toestel en verpakking BIJLAGE Afvoeren toestel en verpakking Bij de vervaardiging van dit toestel is gebruik gemaakt van duurzame materialen. Dit toestel moet aan het eind van zijn levenscyclus op verantwoorde wijze worden afgevoerd. De overheid kan u hieromtrent informatie verschaffen.
  • Page 23: Table Of Contents

    Contents MANUAL Your gas hob Introduction Description Safety instructions Controls Igniting and adjusting Comfortable cooking Optimal use of the hob 8 - 9 Maintenance General 10 - 11 - 12 Faults Faults table 13 - 14 Installation instructions General 15 - 16 Dimensions 17 - 18 Gas information...
  • Page 24: Your Gas Hob

    Introduction YOUR GAS HOB This ATAG gas hob has been designed for the real lover of cooking. The differences in burner capacity mean that you can cook any type of dish. Thanks to the integration of the spark ignition in the knobs, you can ignite and control the burners with one hand.
  • Page 25 Description YOUR GAS HOB KG6111P KG6111W KG6192P Simmer burner Simmer burner Rapid burner Wok burner Semi-rapid burner Semi-rapid burner Stainless steel drip tray Stainless steel drip tray Pan supports Pan supports GB 5...
  • Page 26 Safety instructions YOUR GAS HOB What you should pay attention to Ensure that there is adequate ventilation during use. • Keep natural ventilation openings open. º When using the hob for long periods, extra ventilation is º necessary. Open a window for instance or install a mechanical fan.
  • Page 27: Controls

    Igniting and adjusting CONTROLS Igniting and adjusting Each burner can be adjusted continuously between the high and low positions. 1. 0-setting 2. Burner indication 3. Low setting 4. High setting Controls Press the control knob in and turn it anti-clockwise. The burner ignites.
  • Page 28: Comfortable Cooking

    Optimal use of the hob COMFORTABLE COOKING Optimal use of the hob Always ensure that the flames remain below the pan. If flames play around the pan, a lot of energy is lost. In addition, the handles can get too hot. Do not use pans with a base diameter less than 12 cm. Smaller pans will not be stable.
  • Page 29 Optimal use of the hob COMFORTABLE COOKING Use of the wok auxiliary support The auxiliary support supplied for the wok burner or available as an accessory provides additional stability in case of a wok with a flat base. Place the auxiliary support on the wok support as indicated in the illustration.
  • Page 30: Maintenance

    General MAINTENANCE Your appliance has been manufactured from high-grade materials, which are easy for you to clean. Burner parts should not be cleaned in the dishwasher. The parts • may be damaged by the dishwasher detergent! Do not use too much water as this can penetrate into the burner or ventilation openings.
  • Page 31 If the above methods do not remove the stains, clean the plate • with ATAG Shine. Remember to treat the entire drip tray in order to avoid discolouring. Also, as a follow-up treat the drip tray with a polish or maintenance agent for stainless steel. Please note that over the years the surface will slightly discolour.
  • Page 32 ATAG Shine Atag Nederland supplies a range of cleaning agents under the • name ATAG Shine. These can be obtained at the website at www.hps.nl, where you will also find various cleaning and operating tips. GB 12...
  • Page 33: Faults Table

    Faults table FAULTS Faults table If the appliance does not work properly, this does not always mean that it is defective. Try to deal with the problem yourself first by checking the points mentioned below in the table or visit our website www.hps.nl for more information.
  • Page 34 FAULTS Faults table FAULT CAUSE SOLUTION The burner does not burn Burner parts incorrectly Assemble the burner parts evenly. installed. using the centring ridges. Burner parts dirty or damp. Clean and dry the burner parts, making sure that the outflow holes are open. Wrong type of gas used Check that the gas used is (where bottled gas is used).
  • Page 35: General

    General INSTALLATION INSTRUCTIONS This appliance should only be connected up by a registered installer! Please note The type of gas and the country for which the appliance has been designed are indicated on the application identification card. This is a category 1 appliance. Gas connection The gas connection must comply with national and local •...
  • Page 36 General INSTALLATION INSTRUCTIONS manufacturer, the manufacturer’s service organisation or equivalently qualified persons, in order to avoid dangerous situations. Preparing the hob Fit the elbow supplied on the appliance’s gas connection. 1/2 inch ISO 228 (recht) 1/2 inch EN 10226-1 (conisch) GB 16...
  • Page 37 Dimensions INSTALLATION INSTRUCTIONS Building in dimensions GB 17...
  • Page 38 20mm min. 600 mm min. 650 mm . 650 mm min. 450 mm min. 20mm KG6111P, KG6192P min. 60mm KG6111W min. 20mm min. 450 mm The gas hob may only be built in next to one vertical wall. Install appliance and make connections Place the appliance on a flat sturdy surface.
  • Page 39: Gas Information

    Gas information INSTALLATION INSTRUCTIONS G25/25 mbar Burner type (kW) Simmer 1.00 Normal 2.00 Strong 3.00 4.00 GB 19...
  • Page 40: Disposal Of Packaging And Appliance

    Disposal of packaging and appliance APPENDIX Disposal of packaging and appliance In the manufacturing of this appliance use has been made of durable materials. Make sure to dispose of this equipment responsibly at the end of its lifecycle. Ask the authorities for more information regarding this.
