Chamberlain WIRELESS GATE ACCESS RGAIPI User Manual

Overview
The Wireless Gate Access Intercom allows
homeowners to communicate with guests at the gate
and operate the gate from inside the house. The
Indoor Intercom emits a doorbell sound and
establishes a secure 900 Mhz digital radio link with
the Outdoor Intercom. The Wireless Gate Access
Intercom is compatible with various Chamberlain
Wireless Products and all Chamberlain Gate
Operators.
Carton Inventory
Indoor Intercom
Outdoor Intercom
Operation & Features
Indoor Intercom
Volume Button
Talk
(Power - On)
Select Button
Learn Button
On/Off: To turn Indoor Intercom ON, press any
button. To turn Indoor Intercom OFF, hold down the
Volume button for 5 seconds.
Rubber Pads
Mounting Tape
Alcohol Wipe
AC Adapter
Dipswitch #1
Dipswitch #2
®
Wireless Gate Access Intercom
Talk Button: Following the ringing
of the doorbell by a guest, press
and hold the Talk button to talk to
the guest. Once the link to the
Outdoor Intercom is made, any
other intercoms in the network
cannot hear the conversation.
Select Button: During a conversation, the Select
button can be pressed to open the gate. A beep will
be heard and the gate will open. To open the gate
when not in a conversation, press and hold the Select
Button for 10 seconds.
Volume: Pressing the Volume
button repeatedly will cycle through
volume levels.
Battery: The AA Alkaline batteries
(not provided) will last up to a year
depending on use (Lithium batteries
recommended for colder
environments). When batteries are
low intercom will emit two beeps
every ten minutes.
An AC Adapter (not provided) can
also be used to power the
intercom. In this case, both the
power and channel lights will
remain on.
Outdoor Intercom
Call Button
Speaker
Call Button: To communicate with the Indoor
Intercom, press and release the Call button. A
doorbell sound will be heard on the Indoor Intercom.
Once a secure link is made, the Call button on the
Outdoor Intercom does not need to be pressed to
speak again.
Battery: The AA Alkaline batteries (not provided) will
last up to a year depending on use. (Lithium batteries
recommended for colder environments.)
Volume: To increase the Outdoor Intercom volume,
set Dipswitch #4 to OFF.
Sensitivity: To increase sensitivity on
the Outdoor Intercom set Dipswitch #3
to OFF.
NOTE: Dipswitch #1 must always
remain ON. Dipswitch #2 is not used.
1
Model RGAIPI
OPTIONAL
Learn Button
Dipswitch
Block
