- Page 1 Serial Number GATOR EK622PLU ® Battery-powered Crimping Tool Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. Register this product at www.greenlee.com 52066131 REV 1 © 2014 Greenlee Textron Inc. 3/14...
-
Page 2: Table Of Contents
For recycling information, go to www.greenlee.com. All specifications are nominal and may change as design improve- ments occur. Greenlee Textron Inc. shall not be liable for damages resulting from misapplication or misuse of its products. GATOR is a registered trademark of Textron Innovations Inc. -
Page 3: Important Safety Information
Failure to observe this warning could result in severe injury or death. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 4 • Use this tool for the manufacturer’s intended purpose only. Failure to observe these precautions may result in injury or property damage. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 5: Identification
18 V, 3 Ah lithium-ion battery 52054992 Li (18 V) to NiCd, NiMH (12 V) charger adapter 52049201 120 VAC, 18 V charger 50122746 Carrying strap Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 6: Operation
• If the tool is unable to reach the required crimp force, the red LED, work light, and an audible beep will pulse until after the trigger is released. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 7 Failure to observe these warnings could result in severe injury or death. First Compression Crimping Direction SIDE B First Compression SIDE A First Compression SIDE B Crimping Direction SIDE A Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 8: Die And Connector Selection
2/0 to 3/0 AWG: 3 crimps 95R7 4/0 AWG to 350 kcmil: 4 crimps 4/0 AWG to 600 kcmil: 4 crimps ** 6 AWG to 350 kcmil Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 9: Maintenance
Failure to observe these warnings could result in severe injury or death. Relief valve adjustments must be done by an authorized service center. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 10: Troubleshooting
Tool loses oil. Damaged internal seal. Return tool to a Greenlee Utility Authorized Service Center. Note: For Warranty Service or Repair, contact Greenlee customer service at 800-435-0786. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 11 EK622PLU Battery-powered Crimping Tool Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
