ALL-IN-ONE SMALL
POND FILTER
SYSTEM
CUP-311
2500 LITRES PER HOUR PUMP
11W UV CLARIFICATION
COMPLETELY SUBMERSIBLE
FOR PONDS UP TO 4000 LITRES
INCLUDES COARSE FILTER FOAM
& BIO FILTER MEDIA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CUP-311 and is the answer not in the manual?

Questions and answers

Summary of Contents for All Pond Solutions CUP-311

  • Page 1 ALL-IN-ONE SMALL POND FILTER SYSTEM CUP-311 2500 LITRES PER HOUR PUMP 11W UV CLARIFICATION COMPLETELY SUBMERSIBLE FOR PONDS UP TO 4000 LITRES INCLUDES COARSE FILTER FOAM & BIO FILTER MEDIA...
  • Page 2 To ensure your new pond filter system is set up and running correctly, and to prevent any accidental damage or injury, please read and follow the below instructions carefully before using your product. SAFETY IMPORTANT! Disconnect the mains electricity supply before attempting any installation / maintenance of any kind.
  • Page 3 To avoid injury, do not touch hot or moving parts such as, but not limited to · UV bulbs or impellers. During maintenance ensure all O-rings are present and intact. · If the appliance shows any signs of water leakage or the RCD unit switches ·...
  • Page 4 ELECTRIC This unit comes complete with a generous supply of 3 core cable, however should any additional cable be required, the use of an approved waterproof cable connector with a proper rating is essential. A cord rated for less amperes or watts than the appliance rating may overheat.
  • Page 5: Installation And Use

    INSTALLATION & USE Please read the below instructions carefully before beginning to set up your filter system. DO NOT CONNECT THE UNIT TO THE MAINS UNTIL SET UP IS COMPLETE AND UNIT IS FILLED WITH WATER. 1. Prior to installing the unit, examine the quartz sleeve and UV bulb to make sure these have not been damaged in transportation (see maintenance section).
  • Page 6: Maintenance

    UVC OPERATION Always ensure that the filter has water flowing through the unit prior to · operating the UV. Never look directly at the UV light when operational. · Check that the UV is operational visually using the UV indicator. ·...
  • Page 7: Filter Maintenance

    O-rings It is vital that O-rings are regularly inspected and replaced as the rubber watertight seal will perish over time, which may cause your unit to leak. Before replacing your o-rings, ensure they are well lubricated to ensure the seal is kept water tight.
  • Page 8: General Maintenance

    General Maintenance It is recommended that every 3-4 weeks you perform maintenance on the CUP-311. Filter casing - can be removed by unfastening the casing clips on the side of the filter body and removing the filter casing. Please note you need to remove any attached outlets before opening the casing.
  • Page 9 Clean body and all attachments. Reassemble. Adding All Pond Solutions Filter Start Bacteria Treatment after filter maintenance will help replenish beneficial populations of bacteria and is highly recommended during the first two months of operation when the filter is slowly...
  • Page 10: Replacing The Uv Bulb

    We recommend to replace your bulb every 6 months if used for aquarium and 12 months if used for pond. The CUP-311 uses a 11w two pin PLS UV bulb.
  • Page 11: Parts Diagram

    PARTS DIAGRAM FILTER BOTTOM HOSETAIL OUTLET PUMP ADAPTOR PUMP HOSETAIL ELBOW FILTER CASING T OUTLET CASING CLIP FOUNTAIN ADAPTOR FOUNTAIN NUT COARSE FOAM UV CLARIFIER FOUNTAIN PIPE PUMP > UV ELBOW FOUNTAIN HEAD CONNECTOR FILTER BASKETS FOUNTAIN HEAD 1 FILTER PLATE FOUNTAIN HEAD 2 FILTER BODY FOUNTAIN HEAD 3...
  • Page 12: Water Pump

    PARTS DIAGRAM UV Clarifier UV BODY QUARTZ CONNECTOR FILTER BOTTOM QUARTZ O-RING 2 UV HELIX UV BULB UV QUARTZ UV QUARTZ NUT UV BALLAST QUARTZ O-RING 1 BALLAST LATCH Water Pump PUMP CASING IMPELLER O-RING FILTER BOTTOM SHAFT IMPELLER RUBBER PUMP MOTOR IMPELLER...
  • Page 13: Troubleshooting

    TROUBLESHOOTING UV Indicator is not Lighting Up If the UV indicator on the top of the filter casing is not lighting up follow these troubleshooting steps: 1. Clean the UV indicator. 2. If you find that the UV light is still not operational, check that you have power from the mains supply.
  • Page 14 1. Make sure the unit is turned on 24 hours a day. Continuous running is needed to maintain a clean and healthy pond. 2. Remove pond waste and leaves and carry out a partial water change. If sludge is present treat your pond with All Pond Solutions Anti Sludge treatment.
  • Page 15 3. Reduce feeding. Overfeeding introduces a lot of organic waste and is one of the main causes for cloudy water problems. 4. Make sure to perform regular water changes, check your unit is clean and adequate for your pond size and do not overstock it. My Unit is Cutting Out 1.
  • Page 16: Specifications

    SPECIFICATIONS CUP-311 MODEL: UV POWER (WATTAGE): 4000 L/H FLOW RATE: 387 x 275 x 136 DIMENSIONS (LxWxH) (mm): HEIGHT MAX: 2.5m MAX DEPTH OF USE: 10m (Plug not included) CABLE LENGTH: 220-240v / 50Hz VOLTAGE: POWER:...
  • Page 17: Warranty

    No liability is assumed with respect to loss or damage to livestock or personal property irrespective of the cause thereof. Please ensure that only genuine All Pond Solutions components are used when completing a replacement or repair. Spare parts are available at our official website or from your local supplier.
