Summary of Contents for All Pond Solutions CUP-305
- Page 1 ALL-IN-ONE SMALL POND FILTER SYSTEM CUP-305 1000 LITRES PER HOUR PUMP 5W UV CLARIFICATION COMPLETELY SUBMERSIBLE FOR PONDS UP TO 2000 LITRES INCLUDES COARSE FILTER FOAM & BIO FILTER MEDIA...
- Page 2 To ensure your new pond filter system is set up and running correctly, and to prevent any accidental damage or injury, please read and follow the below instructions carefully before using your product. SAFETY IMPORTANT! Disconnect the mains electricity supply before attempting any installation / maintenance of any kind.
- Page 3 To avoid injury, do not touch hot or moving parts such as, but not limited to · UV bulbs or impellers. During maintenance ensure all O-rings are present and intact. · f the appliance shows any signs of water leakage or the RCD unit switches ·...
- Page 4 ELECTRIC This unit comes complete with a generous supply of 3 core cable, however should any additional cable be required, the use of an approved waterproof cable connector with a proper rating is essential. A cord rated for less amperes or watts than the appliance rating may overheat.
-
Page 5: Installation And Use
INSTALLATION & USE Please read the below instructions carefully before beginning to set up your filter system. DO NOT CONNECT THE UNIT TO THE MAINS UNTIL SET UP IS COMPLETE AND UNIT IS FILLED WITH WATER. 1. Prior to installing the unit, examine the quartz sleeve and UV bulb to make sure these have not been damaged in transportation (see maintenance section). -
Page 6: Maintenance
UVC OPERATION Always ensure that the filter has water flowing through the unit prior to · operating the UV. Never look directly at the UV light when operational. · Check that the UV is operational visually using the UV indicator. ·... -
Page 7: Filter Maintenance
O-rings It is vital that O-rings are regularly inspected and replaced as the rubber watertight seal will perish over time, which may cause your unit to leak. Before replacing your o-rings, ensure they are well lubricated to ensure the seal is kept water tight. -
Page 8: General Maintenance
General Maintenance It is recommended that every 3-4 weeks you perform maintenance on the CUP-305. Filter casing - can be removed by unfastening the casing clips on the side of the filter body and removing the filter casing. Remove and clean filter sponge and filter media - remove the filter media plate and clean through the... - Page 9 Gently pull it out to remove it. Clean body and all attachments. Reassemble. Adding All Pond Solutions Filter Start Bacteria Treatment after filter maintenance will help replenish beneficial populations of bacteria and is highly recommended during the first two months of operation when the filter is slowly...
-
Page 10: Replacing The Uv Bulb
We recommend to replace your bulb every 6 months if used for aquarium and 12 months if used for pond. The CUP-305 uses a 5w two pin PLS UV bulb. -
Page 11: Parts Diagram
PARTS DIAGRAM 14 14 HOSETAIL OUTLET CERAMIC MEDIA FILTER BOTTOM PUMP HOSETAIL ELBOW FOUNTAIN HEAD 1 FILTER CASING COARSE FOAM FOUNTAIN HEAD 2 UV CLARIFIER FOUNTAIN HEAD 3 FOUNTAIN HEAD CONNECTOR PUMP > UV ELBOW FOUNTAIN PIPE FILTER MEDIA PLATE FILTER BODY FOUNTAIN NUT K1 MEDIA... -
Page 12: Water Pump
PARTS DIAGRAM UV Clarifier UV BODY QUARTZ CONNECTOR FILTER BOTTOM QUARTZ O-RING 2 UV HELIX UV BULB UV QUARTZ UV QUARTZ NUT UV BALLAST QUARTZ O-RING 1 BALLAST LATCH Water Pump PUMP CASING IMPELLER O-RING FILTER BOTTOM SHAFT IMPELLER RUBBER PUMP MOTOR IMPELLER... -
Page 13: Troubleshooting
TROUBLESHOOTING UV Indicator is not Lighting Up If the UV indicator on the top of the filter casing is not lighting up follow these troubleshooting steps: 1. Clean the UV indicator. 2. If you find that the UV light is still not operational, check that you have power from the mains supply. - Page 14 Algae growth is very likely to require a treatment to resolve the growth. Consider purchasing the All Pond Solutions Green Water treatment or Blanketweed treatment.
-
Page 15: Specifications
2. Remove pond waste and leaves and carry out a partial water change. If sludge is present treat your pond with All Pond Solutions Anti Sludge treatment. 3. Reduce feeding. Overfeeding introduces a lot of organic waste and is one of the main causes for cloudy water problems. -
Page 16: Warranty
No liability is assumed with respect to loss or damage to livestock or personal property irrespective of the cause thereof. Please ensure that only genuine All Pond Solutions components are used when completing a replacement or repair. Spare parts are available at our official website or from your local supplier. - Page 17 All Pet Solutions Limited Trading as All Pond Solutions Unit 203 Riverside Way, Uxbridge, Middlesex, England, UB8 2YF...
