ALL-IN-ONE
POND FILTER
SYSTEM
CUP-7000
FOR PONDS UP TO 7000L
BUILT IN 11W UV CLARIFICATION
5200 LITRES PER HOUR PUMP
QUICK RELEASE CASING FOR EASY
MAINTENANCE
CLEAN AND CLEAR WATER FOR
HEALTHY FISH
INCLUDES COARSE & MEDIUM FILTER
FOAMS & BIOLOGICAL FILTER MEDIA
ADDITIONAL MEDIA BASKETS
CAN BE ADDED (AVAILABLE
TO BUY SEPARATELY)
HANDLE FOR EASIER LIFTING
Advertisement
Table of Contents
Related Manuals for All Pond Solutions CUP-7000
Summary of Contents for All Pond Solutions CUP-7000
- Page 1 ALL-IN-ONE POND FILTER SYSTEM CUP-7000 FOR PONDS UP TO 7000L BUILT IN 11W UV CLARIFICATION 5200 LITRES PER HOUR PUMP QUICK RELEASE CASING FOR EASY MAINTENANCE CLEAN AND CLEAR WATER FOR HEALTHY FISH INCLUDES COARSE & MEDIUM FILTER FOAMS & BIOLOGICAL FILTER MEDIA...
- Page 2 To ensure your new pond filter system is set up and running correctly, and to prevent any accidental damage or injury, please read and follow the below instructions carefully before using your product. SAFETY IMPORTANT! Disconnect the mains electricity supply before attempting any installation / maintenance of any kind.
- Page 3 To avoid injury, do not touch hot or moving parts such as, but not limited to · UV bulbs or impellers. During maintenance ensure all O-rings are present and intact. · If the appliance shows any signs of water leakage or the RCD unit switches ·...
- Page 4 ELECTRIC This unit comes complete with a generous supply of 3 core cable, however should any additional cable be required, the use of an approved waterproof cable connector with a proper rating is essential. A cord rated for less amperes or watts than the appliance rating may overheat.
-
Page 5: Installation And Use
6. Switch on your unit at the mains - turn on the operation by switching on the unit at the mains. 7. Add an extra basket to your CUP-7000 system (available to buy separately) for extra filtration. It includes 1 coarse and 1 fine foam. -
Page 6: Maintenance
UVC OPERATION Always ensure that the filter has water flowing through the unit prior to · operating the UV. Never look directly at the UV light when operational. · Check that the UV is operational visually using the UV indicator. ·... -
Page 7: Filter Maintenance
O-rings It is vital that O-rings are regularly inspected and replaced as the rubber watertight seal will perish over time, which may cause your unit to leak. Before replacing your o-rings, ensure they are well lubricated to ensure the seal is kept water tight. -
Page 8: General Maintenance
General Maintenance It is recommended that every 3-4 weeks you perform maintenance on the CUP-7000. Filter casing - can be removed by unfastening the casing clips on the side of the filter body and removing the filter casing. Remove and clean filter sponge and filter media - remove the filter sponges and sponge filter cage to access the media plate. - Page 9 Clean body and all attachments. Reassemble. Adding All Pond Solutions Filter Start Bacteria Treatment after filter maintenance will help replenish beneficial populations of bacteria and is highly recommended during the first two months of operation when the filter is slowly being colonised.
-
Page 10: Replacing The Uv Bulb
We recommend to replace your bulb every 6 months if used for aquarium and 12 months if used for pond. The CUP-7000 uses an 11w two pin PLS UV bulb. -
Page 11: Parts Diagram
PARTS DIAGRAM 21 22 24 NOZZLE CONNECTOR FILTER MEDIA PLATE COARSE SPONGE DIVIDER FOUNTAIN PIPE FOUNTAIN NET FINE SPONGE UV CLARIFIER BODY T OUTLET SPONGE FILTER CAGE SCREW O-RING 1 O-RING 2 QUARTZ SLEEVE HOSETAIL O-RING 3 WATER FLOW ADJUSTER UV BULB HOSETAIL NUT CERAMIC MEDIA... -
Page 12: Troubleshooting
TROUBLESHOOTING UV Indicator is not Lighting Up If the UV indicator on the top of the filter casing is not lighting up follow these troubleshooting steps: 1. Clean the UV indicator. 2. If you find that the UV light is still not operational, check that you have power from the mains supply. - Page 13 1. Make sure the unit is turned on 24 hours a day. Continuous running is needed to maintain a clean and healthy pond. 2. Remove pond waste and leaves and carry out a partial water change. If sludge is present treat your pond with All Pond Solutions Anti Sludge treatment.
- Page 14 3. Reduce feeding. Overfeeding introduces a lot of organic waste and is one of the main causes for cloudy water problems. 4. Make sure to perform regular water changes, check your unit is clean and adequate for your pond size and do not overstock it. My Unit is Cutting Out 1.
-
Page 15: Specifications
SPECIFICATIONS CUP-7000 MODEL: MAX HEIGHT (cm) 5200 L/H MAX FLOW RATE: 350 x 310 x 198 DIMENSIONS (LxWxH) (mm): 20mm and 25mm hose OUTLET FITS: WATTAGE: UV WATTAGE: 10m (Plug not included) CABLE LENGTH: 220-240V/50Hz VOLTAGE: PONDS WITH: SUITABLE FOR:... -
Page 16: Warranty
No liability is assumed with respect to loss or damage to livestock or personal property irrespective of the cause thereof. Please ensure that only genuine All Pond Solutions components are used when completing a replacement or repair. Spare parts are available at our official website or from your local supplier. - Page 18 All Pet Solutions Limited Trading as All Pond Solutions Unit 203 Riverside Way, Uxbridge, Middlesex, England, UB8 2YF...
