Biostar TForce 6100 User Manual

Biostar t-series motherboards

Advertisement

Biostar T-Series
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. There is no guarantee that interference will not occur in a particular
installation.
The vendor makes no representations or warranties with respect to the contents here and specially disclaims any implied warranties of merchantability or fitness for any
purpose. Further the vendor reserves the right to revise this publication and to make changes to the contents here without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and we will not be responsible for any mistakes found in this user's manual. All the brand and product
names are trademarks of their respective companies.
P
C
ACKAGE
HECKLIST
FDD Cable x 1
HDD Cable x 1
SPDIF Cable x 1
User's Manual x 1
Overclock Guide x 1
Serial ATA Cable x 2
Fully Setup Driver CD x 1
Rear I/O Panel for ATX Case x 1
USB 2.0 Cable x 1 (optional)
i
TForce 6100-939/ TForce 6100
User's Manual

Advertisement

Table of Contents
loading

Summary of Contents for Biostar TForce 6100

  • Page 1 SPDIF Cable x 1 User’s Manual x 1 Overclock Guide x 1 Serial ATA Cable x 2 Fully Setup Driver CD x 1 Rear I/O Panel for ATX Case x 1 USB 2.0 Cable x 1 (optional) TForce 6100-939/ TForce 6100 User’s Manual...
  • Page 2: Table Of Contents

    A. BIOS Update... 12 B. CPU Overheated... 13 ... 13 ROUBLESHOOTING GERMAN... 14 FRENCH ... 15 ITALIAN ... 16 SPANISH... 17 PORTUGUESE ... 18 POLAND... 19 RUSSIAN ... 20 ARABIC ... 21 JAPANESE ... 22 TForce 6100-939/ TForce 6100 User’s Manual...
  • Page 3: Chapter 1: Introduction

    Dimensions Micro ATX Form Factor: 21.86cm (W) x 24.4cm (L) Main Memory Supports DDR 266/333/400. Maximum memory space is 2GB, supporting 2 DIMM sockets. TForce 6100-939/ TForce 6100 Chipset North Bridge: NVIDIA Geforce6100. South Bridge: NVIDIA nForce 410. Super I/O Chip: ITE IT8712F.
  • Page 4: Layout And Components : Tf Orce 6100-939

    Note: ■ represents the 1st pin. JCFAN1 CPU1 JATXPWR2 GeForce JNFAN1 6100 BAT1 PCI-EX1_1 JSFAN1 PCI-EX16 JUSBV2 nForce PCI1 JUS B2 JUSB3 PCI2 BIOS FDD1 JSFAN2 TForce 6100-939/ TForce 6100 JDDR_0V>3V JATXPWR1 PWRSW1 RSTSW2 JSATA2 JSATA1 JCI1 JCMOS1 JPANEL1 User’s Manual...
  • Page 5 GeForce JNB FAN1 6100 BAT1 PCI-EX1_1 JSFAN1 PCI-EX16 nForce PCI1 JUS B3 PCI2 JUS BV2 BIOS FDD1 JUS B2 TForce 6100-939/ TForce 6100 JSFAN2 JDDR_0V>3V LED_D1 LED_D2 LED_DIMM LED_PWR JATXPWR1 RSTSW2 PWRSW1 JSATA 2 JSATA 1 JCI1 JCMOS 1 JPANEL1...
  • Page 6: Chapter 2: Hardware Installations

    Step 4: Hold the CPU down firmly, and then lower the lever to locked position to complete the installation. TForce 6100-939/ TForce 6100 Step 5: Put the CPU Fan and heatsink assembly on the CPU and buckle it on the retention frame.
  • Page 7: About Fan Headers

    Ground and should be connected to GND. YSTEM TForce 6100-939 Assignment Ground +12V FAN RPM rate sense (Does not support JSFAN2.) Assignment Ground +12V FAN RPM rate sense (Does not support JSFAN2.) TForce 6100-939/ TForce 6100 EMORY TForce 6100 User’s Manual...
  • Page 8: Ddr Modules

    ADA 3200 A E P 5 AP Table 1: AMD Athlon ™ ™ ™ ™ 64 Processor Part Definition Part Definition Total Memory Size Max is 4 GB. Total Memory Size (MB) Max is 2 GB. TForce 6100-939/ TForce 6100 SS/DS SS/DS SS/DS SS/DS SS/DS SS/DS...
  • Page 9: Peripherals

    TForce 6100-939 TForce 6100 Hard Disk Connectors: IDE1/IDE2 The motherboard has two 32-bit Enhanced PCI IDE Controllers that provide PIO Mode 0~4, Bus Master, and Ultra DMA 33/66/100/133 functionality. It has two HDD connectors IDE1 (primary) and IDE2 (secondary). The IDE connectors can connect a master and a slave drive, so you can connect up to four hard disk drives.
  • Page 10 Biostar T-Series Peripheral Component Interconnect Slots: PCI1~PCI2 This motherboard is equipped with 2 standard PCI slots. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards. This PCI slot is designated as 32 bits. TForce 6100-939...
  • Page 11: Connectors And Headers

    Before setting memory voltage overclocking, please ensure that your DDR supports up to 3V. (Consulting your DDR supplier) LED Indicators and Buttons There are 4 LED indicators on the motherboard to show system status. TForce 6100-939 Pin1-2 closed TForce 6100 LED_D1 and LED_D2: These 2 LED indicate system power on diagnostics.
  • Page 12 USB devices, like USB card reader. TForce 6100-939 TForce 6100 Assignment +5V (fused) +5V (fused) USB- USB- USB+ JATXPWR1 JATXPWR2: Assignment +12V +12V Ground Ground TForce 6100-939/ TForce 6100 TForce 6100 JUSB3 JUSB2 JUSB3 JUSB2 Assignment USB+ Ground Ground User’s Manual...
  • Page 13 TForce 6100-939 TForce 6100 Assignment Speaker HDD LED (+) HDD LED (-) Ground Reset control IRTX TForce 6100-939/ TForce 6100 TForce 6100 JPANEL1 Function Pin Assignment Function Sleep control Sleep button Ground Speaker Connector Power LED (+)
  • Page 14 Right line-out/ Speaker-out Right Right line-out/ Speaker-out Right Reserved Serial ATA Connectors: JSATA1~JSATA2 The motherboard has an SATA Controller in nForce410 with 2 channels SATA interface, it satisfies SATA 2.0 spec with transfer rate of 3.0 Gb/s. TForce 6100-939 TForce 6100...
  • Page 15 Note: In order to support this function “Power-on system via keyboard and mouse”, “JKBMSV1” jumper cap should be placed on Pin 2-3. Pin 2-3 Close Clear CMOS data. TForce 6100-939/ TForce 6100 voltage. Pin 1-2 Close JKBMSV1 Pin 2-3 Close...
  • Page 16 This connector allows system to monitor PC case open status. If the signal has been triggered, it will record to the CMOS and show the message on next boot-up. TForce 6100 TForce 6100-939 TForce 6100-939/ TForce 6100 TForce 6100 Assignment JCI1 Case open signal Ground User’s Manual...
  • Page 17: Chapter 3: Useful Help

    BIOS contents are corrupted. In this case, please follow the procedure below to restore the BIOS: Make a bootable floppy disk. Download the Flash Utility “AWDFLASH.exe” from the Biostar website: www.biostar.com.tw Confirm motherboard model and download the respective BIOS from Biostar website.
  • Page 18: Cpu Overheated

    If the system shuts down automatically after power on of system for a few seconds that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid damaging the CPU, and the system will not power on again.
  • Page 19: German

    Chip: ITE IT8712F. Systemumgebungskontrolle, Hardwareüberwachung Lüfterdrehzahl-Controller "Smart Guardian"-Funktion von ITE TForce 6100-939/ TForce 6100 Zwei integrierte Anschlüsse für 4 Geräte. Unterstützt PIO-Modus 0~4, Blockmodus und Ultra DMA 33/66/100/133 Bus-Mastermodus. Serial ATA II nForce 410 unterstützt die Serial ATA 2.0-Spezifikation, datentransferrate von bis zu 3GB/s.
  • Page 20: French

    Moniteur matériel Contrôleur de vitesse de ventilateur Fonction "Smart Guardian" d'ITE TForce 6100-939/ TForce 6100 Deux connecteurs sur carte permettant la prise en charge de 4 périphériques. Prise en charge PIO mode 0~4, Block Mode et mode bus maître Ultra DMA 33/66/100/133.
  • Page 21: Italian

    Funzioni di controllo dell’ambiente, Monitoraggio hardware Controller velocità ventolina Funzione "Smart Guardian" di ITE TForce 6100-939/ TForce 6100 Due connettori integrati supportano 4 dispositivi. Modalità: PIO 0-4, bus master Block e Ultra DMA 33/66/100/133. Serial ATA II nForce 410 supporto specifiche Serial ATA 2.0, velocità di trasferimento dei dati fino 3GB/s.
  • Page 22: Spanish

    Supervisor H/W Controlador de la velocidad del ventilador Función "Guardián inteligente" de ITE TForce 6100-939/ TForce 6100 Dos conectores integrados que admiten 4 dispositivos. Admite el modo PIO 0~4, el modo de bloque y el modo de bus maestro Ultra DMA 33/66/100/133.
  • Page 23: Portuguese

    Controlador da velocidade da ventoinha ­ ­ Função "Smart Guardian" da ITE TForce 6100-939/ TForce 6100 Dois conectores na placa para 4 dispositivos. Suporta o modo PIO 0~4, o modo Block e o modo bus master Ultra DMA 33/66/100/133. Serial ATA nForce 410 suporta a especificação Serial ATA 2.0, velocidade de transferência...
  • Page 24: Poland

    1 port drukarki 1 port szeregowy 1 gniazdo LAN RJ-45 1 port myszy PS/2 1 port klawiatury PS/2 1 pionowy port audio zawierający 1 złącze wejścia liniowego, 1 złącze wyjścia liniowego i 1 złącze wejścia mikrofonu. TForce 6100-939/ TForce 6100 User’s Manual...
  • Page 25: Russian

    Супер ввод-вывод Контроллер: ITE IT8712F. Функции управления режимом эксплуатации, Монитор состояния оборудования Контроллер скорости вентиляторов TForce 6100-939/ TForce 6100 Два встроенных разъема поддерживают подключение четырех жестких дисков IDE. Поддержка режимов PIO 0–4, Block Mode и Ultra DMA 33/66/100/133. Serial ATA nForce 410 Поддерживает...
  • Page 26: Arabic

    ‫ﺗﺪﻋﻢ‬ ‫ﻣﺠﻤﻮﻋﺔ اﻟﺸﺮاﺋﺢ‬ ‫ﻃﺮف‬ ‫ﻃﺮف ﺗﻮﺻﻴﻞ ﺧﻂ ﺧﺎرج و‬ ‫اﻟﺠ‬ ‫ﺧﺮج ﻓﺎﺋﻖ‬ ‫دﺧﻞ‬ ‫اﻟﺸﺮﻳﺤﺔ‬ TForce 6100-939/ TForce 6100 ‫ﻣﻮﺻﻼن ﻋﻠﻰ اﻟﻠﻮﺣﺔ ﻳﺪﻋﻤﺎن أرﺑﻌﺔ أﺟﻬﺰة‬ ‫، ووﺿﻊ اﻟﻘﻔﻞ واﻷو‬ ‫اﻟﺨﺮج اﻟﻤﺒﺮﻣﺞ‬ ‫وﺿﻊ اﻟﺪﺧﻞ‬ ‫دﻋﻢ‬ ‫اﻟﻮﺻﻮل اﻟﻔﺎﺋﻖ ﻟﻠﺬاآﺮة ﻣﺒﺎﺷﺮة‬ ATA II ‫ﺳﻠﺴﻠﺔ‬...
  • Page 27: Japanese

    スーパー スーパー チップ: ITE IT8712F。 環境コントロールイニシアチブ、 H/W モニタ ­ ­ ファン速度コントローラ ­ ITE「スマート・ガーディアン」機能 TForce 6100-939/ TForce 6100 チップセット チップセット チップセット チップセット ノースブリッジ: NVIDIA Geforce6100。 サウスブリッジ: NVIDIA nForce 410。 2 つのオンボードコネクタが 4 つのデバイスをサポート。 PIO モード 0~4、ブロックモード、ウルトラ DMA 33/66/100/133 バス・マス ターモードに対応。 シリアル ATA II シリアル...
