M7NCD Pro Features

CPU
- Supports the AMD
- Running at 200/266/333/400 MHz Front Side Bus.
Chipset
- North Bridge: nForce2 SPP.
- South Bridge:
Main Memory
- Supports up to 3 DDR devices.
- Supports 200/266/333/400MHz(without ECC) DDR devices.
- High performance 128-bit DDR400 Twin Bank Memory Architecture.
- The largest memory capacity is 3GB.
Slots
- Five 32-bit PCI bus master slots.
- One AGP slot:
On Board IDE
- Supports four IDE disk drives.
- Supports PIO Mode 4, Master Mode and Ultra DMA 33/66/100/133 Bus
Master Mode.
Audio
- AC97 2.2 interface.
- PC99 complaint.
- Supports 6 channels.
On Board Peripherals
- Supports 360K, 720K, 1.2MB, 1.44MB and 2.88MB floppy disk drivers.
- Supports 2 serial ports.
- Supports 1 multi-mode parallel port. (SPP/EPP/ECP mode)
- Supports 1 LAN port. (optional)
- Supports PS/2 mouse and PS/2 keyboard.
- Supports 2 rear USB2.0 ports and 4 front USB2.0 ports.
BIOS
- AWARD legal Bios.
- Supports APM1.2.
- Supports ACPI.
M o t h e r b o a r d D e s
M o t h e r b o a r d D e s
M o t h e r b o a r d D e s
®
Socket 462 processor up to XP 3000+.
MCP.
High Speed 800Mb/s Hyper-Transport interface to the MCP.
AGP3.0 8X interface at 533Mb/s.
Supports AGP 2X, 4X, 8X.
1
c r i p t i o n
c r i p t i o n
c r i p t i o n
