SAFETY SYMBOLS

3.
Important safety information
AC(alternating current)
DC(direct current)
DC/AC Voltage or Current

FEATURE DETAILS

4.
1
2
F
3
/
6
8
Ground
Double insulation protection
Fuse
Compliance with EU regulations
4
5
7
6
9
3
1.LCD Display
2.Hold/Backlight Button
Press " " to hold the current reading on the display. Press the button
again to release the hold Hold "
Hold the button again to manually turn off the backlight.
3.Function Switch Button
Press "FUNC" to switch between functions or between AC/DC current.
4.Frequency/Duty Cycle Button (Hz/%)
In AC voltage/current modes, press "Hz%" and the display will show the
frequency measurement. Press the button again to switch to duty cycle.
Press the button a third time to return to normal display.
mode press the"Hz , %" botton and the display will show the duty cycle
Press the button again to switch to the frequency measurement
5.
NCV Button
Press the "NCV" button down in any mode and the meter will activate the
non-contact voltage detection. Hold the meter up to a voltage source and
the buzzer will sound and the NCV indicator will light up if voltage is
detected. Release the "NCV" button to stop NCV detection.
6.Rotary Switch
7.Input Jack (all measurements; current below 600mA)
8.A Jack (current measurements between 600mA-10A only)
9.Common Jack (all measurements)
" to turn on the backlight.
In Hz duty cycle /
.
