Tone Selection

Fig 2) to the tone setting shown in the table below. The table also shows which 2
stage tones are available for use with the selected first stage tone if more than one tone
output stage is required.
Tone
Number
Tone 1 Continuous 340Hz
Tone 2 Alternating 800/1000Hz @ 0.25s intervals
Tone 3 Slow whoop 500/1200Hz @ 0.3Hz with 0.5s gap repeated
Tone 4 Sweeping 500/1000Hz @ 1Hz
Tone 5 Continuous 2400Hz
Tone 6 Sweeping 2400/2900Hz @ 7Hz
Tone 7 Sweeping 2400/2900Hz @ 1Hz
Tone 8 Siren 500/1200/500Hz @ 0.3Hz
Tone 9 Sawtooth 1200/500Hz @ 1Hz - D.I.N.
Tone 10 Alternating 2400/2900Hz @ 2Hz
Tone 11 Intermittent 1000Hz @ 1Hz
Tone 12 Alternating 800/1000Hz @ 0.875Hz
Tone 13 Intermittent 2400Hz @ 1Hz
Tone 14 Intermittent 800Hz 0.25s ON, 1s OFF
Tone 15 Continuous 800Hz
Tone 16 Intermittent 660Hz 150Ns ON, 150ms OFF
Tone 17 Alternating 544Hz (100ms) / 440Hz (400ms) – NFS 32-001
Tone 18 Intermittent 660Hz 1.8s ON, 1.8s OFF
Tone 19 Sweep 1400Hz to1600Hz up 1s 1600Hz to 1400Hz down 0.5s
Tone 20 Continuous 660Hz
Tone 21 Alternating 554/440Hz @ 1Hz
Tone 22 Intermittent 544Hz @ 0.875Hz
Tone 23 Intermittent 800Hz @ 2Hz
Tone 24 Sweeping 800/1000Hz @ 50Hz
Tone 25 Sweeping 2400/2900Hz @ 50Hz
Tone 26 Simulated bell
Tone 27 Continuous 554Hz
Tone 28 Continuous 440Hz
Tone 29 Sweeping 800/1000Hz @ 7Hz
Tone 30 Continuous 300Hz
Tone 31 Sweeping 660/1200 @ 1Hz
Tone 32 Two Tone Chime
Tone 33 Intermittent 745Hz
Tone 34 Alternating 1000/2000Hz @ 0.5s – Singapore
Tone 35 420Hz @ 0.625s - Australian Alert
Tone 36 500-1200Hz 3.75s / 0.25s - Australian Evacuate
Tone 37 Continuous 1000Hz
Tone 38 Continuous 2000Hz
Tone 39 Intermittent 800Hz 0.25s ON 1s OFF
Tone 40 Alternating 544Hz (100ms) / 440Hz (400ms) – NFS 32-001
Tone 41 Motor Siren – Slow rise to 1200Hz
Tone 42 Motor Siren – Slow rise to 800Hz
Tone 43 Continuous 1200Hz
Tone 44 Motor Siren – Slow rise to 2400Hz
Tone 45 Intermittent 1000Hz 1s ON, 1s OFF
Tone 46 Sawtooth 1200/500Hz @ 1Hz - D.I.N. (PFEER P.T.A.P)
Tone 47 Intermittent 1000Hz 1s ON, 1s OFF – PFEER General Alarm
Tone 48 420Hz @ 0.625s - Australian Alert
Tone 49 500-1200Hz 3.75s / 0.25s - Australian Evacuate
_______________________________________________________________________________________________________________________________
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
Document No. IS 4501 Issue G
– To select the required first stage tone set the tone switches 1 to 6 (see
Tone Description
13-01-20
Switch
Settings
1 2 3 4 5 6
0 0 0 0 0 0
1 0 0 0 0 0
0 1 0 0 0 0
1 1 0 0 0 0
0 0 1 0 0 0
1 0 1 0 0 0
0 1 1 0 0 0
1 1 1 0 0 0
0 0 0 1 0 0
1 0 0 1 0 0
0 1 0 1 0 0
1 1 0 1 0 0
0 0 1 1 0 0
1 0 1 1 0 0
0 1 1 1 0 0
1 1 1 1 0 0
0 0 0 0 1 0
1 0 0 0 1 0
0 1 0 0 1 0
1 1 0 0 1 0
0 0 1 0 1 0
1 0 1 0 1 0
0 1 1 0 1 0
1 1 1 0 1 0
0 0 0 1 1 0
1 0 0 1 1 0
0 1 0 1 1 0
1 1 0 1 1 0
0 0 1 1 1 0
1 0 1 1 1 0
0 1 1 1 1 0
1 1 1 1 1 0
0 0 0 0 0 1
1 0 0 0 0 1
0 1 0 0 0 1
1 1 0 0 0 1
0 0 1 0 0 1
1 0 1 0 0 1
0 1 1 0 0 1
1 1 1 0 0 1
0 0 0 1 0 1
1 0 0 1 0 1
0 1 0 1 0 1
1 1 0 1 0 1
0 0 1 1 0 1
1 0 1 1 0 1
0 1 1 1 0 1
1 1 1 1 0 1
0 0 0 0 1 1
sales@e2s.com
www.e2s.com
Sheet 4 of 6
nd and 3 rd
Second Third
Stage Stage
Alarm alarm
Tone 2 Tone 5
Tone 17 Tone 5
Tone 2 Tone 5
Tone 6 Tone 5
Tone 3 Tone 20
Tone 7 Tone 5
Tone 10 Tone 5
Tone 2 Tone 5
Tone 15 Tone 2
Tone 7 Tone 5
Tone 2 Tone 5
Tone 4 Tone 5
Tone 15 Tone 5
Tone 4 Tone 5
Tone 2 Tone 5
Tone 18 Tone 5
Tone 2 Tone 27
Tone 2 Tone 5
Tone 2 Tone 5
Tone 2 Tone 5
Tone 2 Tone 5
Tone 2 Tone 5
Tone 6 Tone 5
Tone 29 Tone 5
Tone 29 Tone 5
Tone 2 Tone 15
Tone 26 Tone 5
Tone 2 Tone 5
Tone 7 Tone 5
Tone 2 Tone 5
Tone 26 Tone 5
Tone 26 Tone 15
Tone 2 Tone 5
Tone 38 Tone 45
Tone 36 Tone 5
Tone 35 Tone 5
Tone 9 Tone 45
Tone 34 Tone 45
Tone 23 Tone 17
Tone 31 Tone 27
Tone 2 Tone 5
Tone 2
Tone 5
Tone 2 Tone 5
Tone 2 Tone 5
Tone 38 Tone 34
Tone 47 Tone 37
Tone 46 Tone 37
Tone 49 Tone 5
Tone 26 Tone 37
