Washing Machine
user manual
imagine
Thank you for purchasing a Samsung product.
To receive a more complete service,
please register your product at
www.samsung.com/global/register
the possibilities
WF7522S8(S/V/C)
WF7520S8(S/V/C)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WF7520S8S and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung WF7520S8S

Summary of Contents for Samsung WF7520S8S

  • Page 1 WF7522S8(S/V/C) WF7520S8(S/V/C) Washing Machine user manual imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/global/register...
  • Page 2 • Silver Wash - Silver Nano Health System Samsung’s silver Nano feature uses silver nano particles to sanitize and disinfect your laundry and your machine’s drum. Delicates as well as smelly socks will get odor-free from human sweat at temperature as low as 30˚C.
  • Page 3 It’s your resposibility to use common sense, caution, and care when installing, maintaining, and operation your washer. Samsung is not liable for damages resulting from improper use. IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS...
  • Page 4 safety information The glass door becomes very hot during the washing cycle. Keep children away from the appliance while it is in use. Do not attempt to repair the appliance yourself. Repairs made by inexperienced or unqualified persons may cause injury and/or make more serious repairs to the appliance necessary.

  • Page 5: Table Of Contents

    contents INSTALLING THE WASHING Unpacking the Washing Machine MACHINE Overview of the washing machine Selecting a location Adjusting the leveling feet Removing the shipping bolts Connecting the water supply hose Connecting the water supply hose (Option) Positioning the drain hose WASHING A LOAD OF LAUNDRY Washing for the first time Putting detergent in the washing machine...

  • Page 6: Installing The Washing Machine

    Unpack your washing machine and inspect it for shipping damage. Also make sure that you have received all of the items shown below. If the washing machine was damaged during shipping or you do not have all of the items, contact your Samsung dealer immediately. OVERVIEW OF THE WASHING MACHINE...

  • Page 7: Selecting A Location

    SELECTING A LOCATION Before you install the washing machine, select a location with the following characteristics: • A hard, level surface (if the surface is uneven, see “Adjusting the leveling feet,” below) • Away from direct sunlight. • Adequate ventilation •...

  • Page 8: Connecting The Water Supply Hose

    installing the washing machine CONNECTING THE WATER SUPPLY HOSE The water supply hose must be connected to the washing machine at one end and to the water faucet at the other. Do not stretch the water supply hose. If the hose is too short replace the hose with a longer, high pressure hose.

  • Page 9: Connecting The Water Supply Hose (Option)

    The drain pipe branch must be above the sink siphon so that the end of the hose is at least 60 cm above the ground. ln a drain pipe Samsung recommends that you use a 65 cm high vertical pipe; it must be no shorter than 60 cm and no longer than 90 cm. Installing the washing machine _9...

  • Page 10: Washing A Load Of Laundry

    washing a load of laundry WASHING FOR THE FIRST TIME Before washing clothes for the first time, you must run a complete cycle without clothes. To do this: 1. Press the (On/Off) button. 2. Pour a little detergent into compartment ( ) in the detergent drawer.
  • Page 11 Digital graphic Displays the remaining wash cycle time, all of washing information and error display messages. Silver Nano water is supplied in washing as well as the last rinse, featuring Silver Wash sterilization and antibacterial coating. (You can select ‘Sterilization’ or selection button ‘Protection’, ‘Sterilization’...

  • Page 12: Washing Clothes Using Fuzzy Logic

    WASHING CLOTHES USING FUZZY LOGIC Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Logic” automatic control system. When you select a wash programme, the machine will set the correct temperature, washing time, and washing speed.

  • Page 13: Washing Clothes Manually

    Pause Option (Stop & Adding laundry Function) If push Start/Pause button, the door is unlocked immediately. In case of too hot or too much water in washer, the door can not be opened. After closed the door, one more push Start/Pause button to make washing process going on continuously.

  • Page 14: Using Delay Start

    washing a load of laundry USING DELAY START You can set the washing machine to finish your wash automatically at a later time, choosing from 3 to 24 hour delay (in 1 hour increments). Displayed hours means the time of finished washing-cycle. To do this: 1.

  • Page 15: Maintaining The Washing Machine

    maintaining the washing machine DRAINING THE WASHING MACHINE IN AN EMERGENCY 1. Unplug the washing machine from the power supply. 2. Open the filter-cover by using a coin or a key. 3. Unscrew the emergency drain cap by turning left. Grip the cap on the end of the emergency drain tube and slowly pull it out about 15 cm.

  • Page 16: Cleaning The Detergent Drawer And Recess

    maintaining the washing machine CLEANING THE DETERGENT DRAWER AND RECESS 1. Press the release lever on the inside of the detergent drawer and pull it out. 2. Remove the cap from compartment ( ). 3. Wash all of the parts under running water. 4.

  • Page 17: Cleaning The Water Hose Mesh Filter

    CLEANING THE WATER HOSE MESH FILTER You should clean the water hose mesh filter at least one time per year, or when you see the following error message on the display: To do this: 1. Turn off the water source to the washing machine. 2.

  • Page 18: Troubleshooting

    troubleshooting PROBLEMS AND SOLUTIONS PROBLEM SOLUTION The washing machine • Make sure the door is firmly closed. • will not start Make sure the washing machine is plugged in. • Make sure the water source faucet is turned on. • Make sure to press the Start/Pause button.

  • Page 19: Programme Chart

    programme chart PROGRAMME CHART user option)  Temperature Options Rinse Spin Speed rpm (˚C) Programme Less 1200 1000 stan- pre- Inten- stan- lron- dard wash sive dard standard standard Cotton 1200 1200 1000 1000     Coloureds 1200 1200 1000 1000...
  • Page 20 programme chart user option)  Temperature Options Rinse Spin Speed rpm (˚C) Programme Less 1200 1000 stan- pre- Inten- stan- lron- dard wash sive dard standard standard Silk  Heavy Soil 1200 1200 1000 1000     Mixed Load ...

  • Page 21: Appendix

    appendix FABRIC CARE CHART Resistant material Can be ironed at 100˚C max Delicate fabric Do not iron Can be dry cleaned using any Item may be washed at 95˚C solvent Dry clean with perchloride, lighter Item may be washed at 60˚C fuel, pure alcohol or R113 only Dry clean with aviation fuel, pure Item may be washed at 40°C...

  • Page 22: Declaration Of Conformity

    appendix DECLARATION OF CONFORMITY This appliance complies with European safety standards, EC directive 93/68 and EN Standard 60335. SPECIFICATION TYPE FRONT LOADING WASHER DIMENSION W600mm X D450mm X H850mm WATER PRESSURE 50 kPa ~ 800 kPa WATER VOLUME 49 L (STANDARD COURSE) NET WEIGHT 66 kg MODEL...
  • Page 23 memo...
  • Page 24 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country CALL OR VISIT US ONLINE AT RUSSIA 8-800-200-0400 www.samsung.ru Code No. DC68-02410E_EN...
