SERVICE
WASHING MACHINE (DRUM)
WASHING MACHINE
DRUM TYPE
Basic Model : WF45H6300AG/A2
(WF6000H PROJECT)
Model Name : WF50K7500AV
WF50K7500AW
(WF7500K)
Model Code : WF50K7500AV/A2
WF50K7500AW/A2
(WF7500K)
Manual
1. Safety Instructions
2. Features and Speci ications
3. Disassembly and Reassembly
4. Troubleshooting
CONTENTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WF45H6300AG/A2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung WF45H6300AG/A2

Summary of Contents for Samsung WF45H6300AG/A2

  • Page 1 WASHING MACHINE DRUM TYPE Basic Model : WF45H6300AG/A2 (WF6000H PROJECT) Model Name : WF50K7500AV WF50K7500AW (WF7500K) Model Code : WF50K7500AV/A2 WF50K7500AW/A2 (WF7500K) SERVICE Manual WASHING MACHINE (DRUM) CONTENTS 1. Safety Instructions 2. Features and Speci ications 3. Disassembly and Reassembly 4. Troubleshooting...

  • Page 2: Table Of Contents

    This document can not be used without Samsung's authorization. CONTENTS 1. Safety instructions ..............1 1-1.

  • Page 3: Safety Instructions

    This document can not be used without Samsung's authorization. 1. SAFETy INSTRuCTIONS 1-1. SAFETy INSTRuCTIONS FOR SERVICE ENGINEERS ► Be sure to observe the following instructions to operate the product correctly and safely to prevent possible accidents and hazards while servicing. ► Two types of safety symbols, Warning and Caution, are used in the safety instructions. Hazards or unsafe practices that may result in severe personal injury or death. WARNING Hazards or unsafe practices that may result in minor personal injury or property damage.

  • Page 4: Before Servicing

    This document can not be used without Samsung's authorization. CAuTION BEFORE SERVICING • Do not sprinkle water onto the washing machine directly when cleaning it. √ This may result in electric shock or fire, and may shorten the product lifetime. • Do not place any containers with water on the washing machine. √ If the water is spilled, it may result in electric shock or fire. This will also shorten the product lifetime. • Do not install the washing machine in a location exposed to snow or rain. √ This may result in electric shock or fire, and shorten the product lifetime. • Do not press a control button using a sharp tool or object. √ This may result in electric shock or damage to the product. CAuTION WHILE SERVICING • When wiring a harness, make sure to seal it completely so no liquid can enter. √ Make sure that they do not break when force is exerted. • Check if there is any residue that shows that liquid entered the electric parts or harnesses. √ If any liquid has entered into a part, replace it or completely remove any remaining moisture from it.

  • Page 5: After Servicing

    This document can not be used without Samsung's authorization. WARNING WHILE SERVICING • Check if the power plug and outlet are damaged, flattened, cut or otherwise degraded. √ If faulty, replace it immediately. Failing to do so may result in electric shock or fire. • Completely remove any dust or foreign material from the housing, wiring and connection parts. √ This will prevent a risk of fire due to tracking and electrical hazard. • When connecting wires, make sure to connect them using the relevant connectors and check that they are completely properly. √ If tape is used instead of the connectors, it may cause fire due to tracking. • Make sure to discharge the PBA power terminals before starting the service. √ Failing to do so may result in a high voltage electric shock. • When replacing the heater, make sure to fasten the nut after ensuring that it is inserted into the bracket-heater. √ If not inserted into the bracket-heater, it touches the drum and causes noise and electric leakage. WARNING AFTER SERVICING • Check the wiring. √ Ensure that no wire touches a rotating part or a sharpened part of the electrical harness.
  • Page 6 This document can not be used without Samsung's authorization. CAuTION AFTER SERVICING • Check the assembled status of the parts. √ Now is a good time to inspect your work. Review all connections and wiring, including mounting hardware. • Check the insulation resistance. √ Disconnect the power cord from the power outlet and measure the insulation resistance between the power plug and the grounding wire of the washing machine. The value must be greater than 10MΩ when measured with a 500V DC Megger. • Check whether the washing machine is level the floor with respect to the original position of the washing machine prior to service. By doing this now will reduce for the need of customer dissatisfaction and redo call. √ Vibrations can shorten the lifetime of the product. 4 _ Safety Instructions...

  • Page 7: Features And Specifications

    This document can not be used without Samsung's authorization. 2. FEATuRES AND SPECIFICATIONS 2-1. FEATuRES Features Description The Largest Capacity • Samsung’s extra-large capacity laundry machine can wash a full set of your Bedding PLUS, a kingsize comforter, or up to 31 bath towels in a single load. Since you don’t have to do as many loads, you save time, money, water and energy. Smart Control • Samsung’s innovative Smart Control technology enables you to control your washer through personal technologies such as smart phones. You don’t have to be on standby until the cycle ends. Smart Control allows you to monitor the washing process and let you know when the cycle is complete. Smart Care • Samsung’s Smart Care, an automatic error-monitoring system, detects and diagnoses problems at an early stage and provides a quick and easy solution through LCD navigation. With the innovative Smart Control technology, you can also be alerted when the problem occurs via your smart phones. PowerFoam™...
  • Page 8 This document can not be used without Samsung's authorization. Features Description Pedestal with Storage • An optional 15” pedestal is available to raise the washer Drawers for easier loading and unloading. (Model No : WE357*) It also offers a built-in storage drawer that can hold a 100 oz. bottle of detergent. • Samsung washers and dryers can be stacked to Stacking (Model No : SK-7A/XAA) maximize usable space. An optional stacking kit is available for purchase from your Samsung retailer. 6 _ Features and Specifications...

  • Page 9: Specifications

    This document can not be used without Samsung's authorization. 2-2. SPECIFICATIONS Model WF50K7500A* Wash type FRONT LOADING WASHER A: High-Overall 38.7”(984mm) B: Width 27”(686mm) Dimension (Inches / mm) C: Depth with door open 90º 53.1”(1,350mm) D: Depth 34’’(864mm) Water pressure 20 ~ 116psi(137~800kpa) Weight...

  • Page 10: Comparing Specifications With Existing Models

    This document can not be used without Samsung's authorization. 2-3. COMPARING SPECIFICATIONS WITH EXISTING MODELS Project WF7500K WF6000HA BEST WF45K6500AV Model Name WF45H6300A* WF45K6500AW Image Capacity (cu.ft. IEC) 5.0 cu.ft 4.5 cu.ft DD Motor DD Motor Motor type MAX RPM 1300 1300...

  • Page 11: Options Specifications

    This document can not be used without Samsung's authorization. 2-4. OPTIONS SPECIFICATIONS Item Code Remarks BOLT-SPANER(Wrench) DC60-40146A Default USER : DC68-03667A MANUAL USER Default TECH : DC68-03668A DC67-00307A Default CAP-FIXER HOSE-HANGER DC62-10278A Default Note • Customer can purchase additional water supply and drain hoses from a service center. • The spanner(wrench), water supply and drain hoses are not supplied. Both the water supply and drain hoses are supplied during the installation. Features and Specifications _ 9...

  • Page 12: Disassembly And Reassembly

    This document can not be used without Samsung's authorization. 3. DISASSEMBLy AND REASSEMBLy 3-1. TOOLS FOR DISASSEMBLy AND REASSEMBLy Tool Type Remarks Heater (1) 10mm Socket Wrench with Motor (1), Balance (5), 2 holes of each left and 13mm 6” Extension right of the shock absorber 1 Pulley hole 19mm Replaceable for the box driver. 10mm Open End Since the bolt runs idle when the box driver is 13mm wrench used, use the box driver 17mm. 19mm Tool to protect the idle and abrasion of the bolt Vice pliers for the box driver.

  • Page 13: Standard Disassembly Drawings

    This document can not be used without Samsung's authorization. 3-2. STANDARD DISASSEMBLy DRAWINGS ► This is a standard disassembly diagram and may differ from the actual product. Use this material as a reference when disassembling and reassembling the product. Part Figure Description 1. Remove the 2 screws holding the Back-Cover at the back of the washing machine and separate the Back-Cover pushing it downwards. (Assemble it by lifting it upwards) 2. After separating the Back-Cover, remove the M19 nut holding the Motor. To remove it, turn it counter- clockwise. As the Motor also rotates if the nut is turned slowly, torque it quickly and firmly in a single action. Do not remove the nut by inserting a screwdriver into the Motor, as this may result in a problem with the motor. 3. Remove the M19 nut and washer and then separate the Rotor. Since removing the rotor requires a lot of strength due to the magnetic force of the Rotor and it may come off suddenly, your hand or arm may be injured by the edge of the Stator or Frame. Therefore take precaution when separating it.
  • Page 14 This document can not be used without Samsung's authorization. Part Figure Description 1. Separate the Assy Thermistor and Guide Wire-T while pulling the Assy Thermistor. 2. Separate the Assy Thermistor and Assy Wire Harness while pressing the navel of the Housing. Disassembling and Repairing the 3. Pull the Assy Thermistor from Tub Back. Thermistor When disassembling Assy Thermistor , leave the rubber packing. CAUTION 1. When assembling Assy Thermistor, push to the end. If assembling like NG picture, water leakage possibility is high. 2. When assembling and disassembling Assy Thermistor , rubber Packing should be checked. If the gap existed between rubber packing and tub- back, water leakage possibility is high. 12 _ Removal and Reassembly...
  • Page 15 This document can not be used without Samsung's authorization. Part Figure Description 1. Remove the 2 hexagon screws, which are at the back, fixing the COVER-TOP. 2. Disassemble the COVER-TOP by sliding it backwards. 3. Press the Separate button to separate the ASSY DRAWER. Separating the Cover_Top and Panel-Control (Check Sub-PCB) 4. Pull the PANEL-CONTROL towards and then lift it upwards to separate. 5. Carefully disconnect the two wiring connectors by hand. 6. Disassemble the ASSY KNOB-ENKODER by pulling it upwards. 7. Remove the all screws holding the PCB and release the hooks on both sides to remove the PCB for repair / replacement.
  • Page 16 This document can not be used without Samsung's authorization. Part Figure Description 1. Separate Dongle from gender 2. Separate Cover Dongle from Panel. (Push left direction and pull out right side.) Separating the Panel-control and Housing Dongle 3. Carefully disconnect wiring connector. (Dongle – gender) 4. Remove the screws holding the Housing Dongle and separate from Panel Control. 14 _ Removal and Reassembly...
  • Page 17 This document can not be used without Samsung's authorization. Part Figure Description 1. Remove the 2 screws holding the ASSY PCB- MAIN at the back of the washing machine. 2. Separate the 2 Hooks by pushing it rightwards. 3. Remove the 2 screw and 2 Connectors for separating Guide Wire-T Separating the Main 4. Push the TUB upside to separate ASSY PCB- MAIN. and separate the ASSY PCB-MAIN lifting it 5. Separate the 4 Hooks. 6. Disconnect All Connectors on main PBA. Lift up Main PBA, Change SVC Part. After SVC, Certainly check the all Hooks on COVER-PCB(M) Otherwise COVER-PCB(M) will be disassembled during washing machine running. Removal and Reassembly _ 15...
  • Page 18 This document can not be used without Samsung's authorization. Description Part Figure 1. Open the Add door. 2. Remove Inlays. 3. Remove 4 screws. ASSY DOOR (Cont.) 4. Use (-) driver, separate the cover door. 5. Remove 2 screws and then separate the latch. 16 _ Removal and Reassembly...
  • Page 19 This document can not be used without Samsung's authorization. Description Part Figure 6. Remove 5 screws and then separate the support hinge. ASSY DOOR (Cont.) 7. Remove 1 screw, separate Add door. Removal and Reassembly _ 17...
  • Page 20 This document can not be used without Samsung's authorization. Part Figure Description 1. Remove the 2 hexagonal screw holding the hinge door. 2. Putting and pressing hard a flat-head screwdriver or into the furrow between COVER-FILTER and FRAME-FRONT and then pull it towards to open the COVER-FILTER. Disassembling and Reassembling the Door Part 3. Remove the screw holding the cover filter. 5. Separate the Connector of assy wire harness. 18 _ Removal and Reassembly...
  • Page 21 This document can not be used without Samsung's authorization. Part Figure Description 1. Pull the DIAPHRAGM upside, and finish disassembling along the circle. 2. Remove the 2 screws to separate the DOOR LOCK S/W. 3. Remove the 5 screws at the top of FRAME- Disassembling the FRONT. Front Cover/Frame Front (Check the Door Lock S/W) 4. Push the lever and pull it towards to open the COVER-FILTER. 5. Separate the remaining WATER REMOVAL HOSE (BLUE) from the hook. 6. Remove the 2 screw down under Frame Front. 7. Press the UPPER-PLATE slightly with the screwdriver to separate the FRAME-FRONT.
  • Page 22 This document can not be used without Samsung's authorization. Part Figure Description 1. Remove the Top Assy-Plate. 2. Disconnect the water supply valve wire connector. Disassembling and 3. Remove the 4 screws holding the water supply Repairing the Water valve. Supply Valve 4. Remove the hose connected to the valves. (Use the plier to remove the hose.) 1. Separate the wire connected the SENSOR- PRESSURE. 2. Adjust the plastic clip( of pressure sensor) between two nose of plier, then grip and pull the plastic clip with caution. (Use the long nose plier to push the hook). Disassembling and Repairing the Water Level Sensor 3. Remove the hose from the SENSOR-PRESSURE.
  • Page 23 This document can not be used without Samsung's authorization. Part Figure Description 1. Remove the 2 screws holding the ASSY PUMP DRAIN. 2. Separate the Clamp of the hose connected to the PUMP and then pull the DRAIN-HOSE. 3. Separate the Clamp of the hose connected to the Disassembling the PUMP and then pull the HOSE-AIR. Pump Motor Part 4. Separate the Clamp of the hose connected to the PUMP and then pull the HOSE-DRAIN. 5. Separate the wire connected to the PUMP. • If the washing machine works, drain the water in the wash tub by selecting the Spin course. Removing the If the washing machine does not work, remove Remaining Water the laundry from the wash tub and scoop the remaining water out of the tub using a cup.
  • Page 24 This document can not be used without Samsung's authorization. Part Figure Description 1. Remove the 2 screws fixing GUIDE-WIRE, 6 screws fixing FRAME-PLATE(U). 2. Remove the 6 bolts fixing WEIGHT BALANCER and then pull it towards with caution. Disassembling the 3. Remove the 4 bolts fixing DAMPER to take ASSY TUB out. 4. Remove all wire and hose connected the ASSY- TUB. 5. Open the cap of SPRING-HANGER to take ASSY- TUB out. 6. Lift the ASSY-TUB with two people carefully with holding SPRING-HANGER. 22 _ Removal and Reassembly...
  • Page 25 This document can not be used without Samsung's authorization. Part Figure Description Disassembling the 7. Remove the M10 bolt from the middle of the TUB and separate the TUB-FRONT and TUB-BACK. 1. Separate the ASSY DRUM from TUB, remove 6 M10 bolts from the upper ASSY DRUM, disassemble the ASSY FLANGE SHAFT. 2. Remove 12 screws from the outer sides and then remove the two upper and lower BALL BALANCERS. Disassembling the DRuM 3. Remove 3 screws from the outer sides and then remove the 3 DRUM-LIFTERS. - In order to disassemble the drum lifter in the assembly condition, pierce a hole with the drill. - Remove a screw from the outer sides and then remove the DRUM-LIFTERS. - Block a hole with a silicon after replacing the drum lifter. Removal and Reassembly _ 23...
  • Page 26 This document can not be used without Samsung's authorization. Part Figure Description 1. Disassemble the Front-Frame. 2. Separate the connection wire. - Separate the Thermostat fixed at the bottom of the Tub. (Take precaution as there may be water remaining.) Make sure to separate the Thermostat first and then separate the Heater. If you fail to observe this order, it may result in a shock and be damaged. 3. Release the nut holding the Heater with an M10 tool and then separate the Heater. Do not completely release the nut. Separating the Pull the Heater forward after releasing the nut. If Heater at the Bottom the Heater is damaged, it may cause a problem. Front Therefore unfasten the nut using spanner or wrench manually without using pincers or tweezers.

  • Page 27: Troubleshooting

    This document can not be used without Samsung's authorization. 4. TROuBLESHOOTING 4-1. ERROR MODES ► This is a washer integrated error mode. For detailed information, refer to the general repair scripts. Error Type For uSA Causes Remarks - The part of the hose where the water level sensor is located is damaged (punctured).

  • Page 28: 26 _ Troubleshooting

    This document can not be used without Samsung's authorization. Error Type For uSA Causes Remarks The signals between the sub and main PBAs are not sensed because of commuication error. Check the connector connections between the sub and main PBAs carefully. → Check for incorrect or loose connections, etc. Remove the sub PBA C/Panel and check for any faulty soldering. The signals between The DR Module and main PBAs are not sensed because of commuication error. Check The connector connections between The DR Module and main PBAs carefully. → Check for incorrect or loose connections, etc. Remove The DR Module and Check for any faulty soldering. The signals between The WIFI Module and main PBAs are not sensed because of commuication error. Check The connector connections between The WIFI Module Communication and main PBAs carefully. Error → Check for incorrect or loose connections, etc. Remove the WIFI Module and Check for any faulty soldering. The signals between The LCD Module and main PBAs are not sensed because of commuication error.
  • Page 29 This document can not be used without Samsung's authorization. Error Type For uSA Causes Remarks The washing heater is short-circuited or has a wire disconnected. The washing heater in the tub has an error. If the heater has no (Contact error, temperature sensor fault) error, this occurs Heater Error HC,HC1 If the water level sensor operates without water because water because of a PBA relay is frozen or for any other reason and the temperature sensor malfunction. engaged at the bottom to prevent overheating for the washing heater detects a temperature of 100 to 150 ˚C, the washing machine turns the input power off. Heater engagement fault. (out of place) The air hose is out of place and water leakage occurs during the spin cycle. The tub back at the safety bolts fixing part is broken. Water leakage occurs at the front with foaming because of too much detergent. Water leakage occurs because the connecting hose to the detergent drawer is connected incorrectly. Water Leakage Error The drain pump filter cover is engaged incorrectly.

  • Page 30: 28 _ Troubleshooting

    This document can not be used without Samsung's authorization. Error Type For uSA Causes Remarks System Error Micro Controller Operation Fail. Replace Assy PCB. 28 _ Troubleshooting...

  • Page 31: Corrective Actions For Each Error Code

    This document can not be used without Samsung's authorization. 4-2. CORRECTIVE ACTIONS FOR EACH ERROR CODE Troubleshooting _ 29...

  • Page 32: 30 _ Troubleshooting

    This document can not be used without Samsung's authorization. 30 _ Troubleshooting...
  • Page 33 This document can not be used without Samsung's authorization. Troubleshooting _ 31...

  • Page 34: 32 _ Troubleshooting

    This document can not be used without Samsung's authorization. 32 _ Troubleshooting...
  • Page 35 This document can not be used without Samsung's authorization. Troubleshooting _ 33...

  • Page 36: 34 _ Troubleshooting

    This document can not be used without Samsung's authorization. 34 _ Troubleshooting...
  • Page 37 This document can not be used without Samsung's authorization. This Service Manual is a property of Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under applicable © 2016 Samsung Electronics Co.,Ltd. All International and/or domestic law. rights reserved.
