Carton Inventory

Your garage door opener is packaged in two cartons
which contain the motor unit and all parts illustrated
below. Accessories will depend on the model
Multi-Function
Door Control Panel
2-Conductor Bell Wire
White & White/Red
Belt
Pulley Bracket
Safety Sensor
Bracket (2)

INSTALLATION HARDWARE

Hex Screw 5/16"-18x7/8" (4)
Hex Screw #8 x 3/8" (2)
Lag Screw 5/16"-9x1-5/8" (2)
Lag Screw 5/16"-18x1-7/8" (2)
Clevis Pin 5/16"x2-3/4" (1)
Clevis Pin 5/16"x1-1/4" (1)
Clevis Pin 5/16"x1" (1)
Nut 5/16"-18 (4)
Lock Washer 5/16" (4)
Screw 6ABx1-1/4" (2)
Self-Threading Screw 1/4"-14x5/8" (2)
SECURITY
3-Channel Remote Control
Light Lens (2)
Trolley
Header Bracket
(2) Safety Reversing Sensors
(1 Sending Eye and 1 Receiving Eye)
with 2-Conductor White & White/Black
Bell Wire attached
5
purchased. If anything is missing, carefully check the
packing material. Parts may be stuck in the foam.
Hardware for installation is also listed below.
Remote Control
Transmitter Visor Clip
Belt
One-Piece
T-rail
Door Bracket
Curved Door
Arm Section
Safety Labels
and
Literature
Screw 6-32x1" (2)
Insulated Staples (10)
Ring Fastener (3)
Dry Wall Anchors (2)
Rope
Handle
Rail Grease
SAFETY REVERSING SENSOR
INSTALLATION HARDWARE
Carriage Bolt 1/4"-20x1/2" (2)
Wing Nut 1/4"-20 (2)
Insulated Staples (20)
Belt Cap Retainer
Styrofoam
Straight Door
Arm Section
